GET RX1 PRO Installation Manual page 5

6.
To protect the fuel tank, glue
the special sponge pad (included
in the kit) on the side of the GET
ECU, as shown in the figure.
7.
Connect the GET RX1 Pro
ECU to the original connector.
Make sure that the connector is
inserted correctly and that the
latch is fully engaged.
8.
Reinstall the battery tray now equipped with the GET
ECU. Reconnect the starter relay, reposition the battery in the
tray and secure it with the previously removed original rubber
band. Reconnect the battery.
9.
Connect the special cable
(included in the kit) to the GET ECU
main connector. Pass the cable up
to the front of the bike, attaching it
to the frame using the clamps (not
included in the kit).
10.
Reposition the tank and re-install the side panels, seat,
and all other components which were removed during the
preliminary steps.
EN
5
