- Page 1 BOX L VF1L EI/EA UNIVERSAL CONTROL PANEL For gates with 1 three-phase 230VAC motor with frequency converter INSTRUCTION MANUAL innovative in electronics...
- Page 2 COMPONENTS SITUATION Fig.1 SMINN BXL-VF1L 1. LED connector for panel cover 7. Auxiliary output relays 2. TEST Run button 8. AC power input fuse 3. TRSH radio card socket 9. Bus load relay 4. LCD display 10. Bus capacitor 5. Options selection keypad 11.
-
Page 3: Table Of Contents
INDEX Symbols Description ..........2 Limitation on the use of the panel. 2 Warnings ........... 2 ......Encoder pulses Installation ..........3 Important safety instructions for installation ..........3 Important safety instructions for . Relay output (NO contact) use ..............3 Wiring ............ -
Page 4: Description
Socket for SMINN radio card (6 pins). Independent inputs for one photocell and one strip (resistive or contact) or a S M I N N C O N T R O L P A N E L S A R E second photocell. -
Page 5: Installation
INSTALLATION The box is xed to the wall with only three in single-family dwellings and communal screws, all of them external (see Fig.3). and public facilities. The moving door must be prevented from making contact Drill three holes in the wall according to with any object or limiting the contact the cut-out template printed on the force (e.g. -
Page 6: Wiring
WIRING ENCODER VF1L: Terminals 12 and 15 provide an The panel is supplied with 230VAC 50Hz incremental encoder with 12VDC power via terminals 1 and 2. The earth connection supply. Terminal 13 is used to connect the is made at terminal 3. incremental encoder signal. - Page 7 WIRING The radio card socket allows a SMINN radio card (6 pins) to be plugged in, enabling the opening command to be The panel has inputs for opening and given via radio transmitters. closing limit switches. The contacts are normally closed and have a common for ease of installation.
-
Page 8: Setup
Fd: Dynamic force select an element or validate the selection Fs: Static force of a value, and the BACK key is used to cancel the modi cation of a parameter and, in general, to go backwards. SMINN BXL-VF1L BACK ENTER BACK ENTER... -
Page 9: Maneuver Programming
MANOEUVER PROG. The control panel has a con guration opening and closing points using the <- wizard that allows you to select the most and -> keys to memorise their positions. important parameters and start up the After con guring the basic parameters, control panel quickly. -
Page 10: Maneuver
MANOEUVER ACTIVATION OPEN/CLOSE The OPEN/CLOSE mode uses LL1 as the The key inputs (marked LL1 and LL2) and a opening command and LL2 as the closing radio card installed in the radio socket can command. When the door is in motion the be used to start a manoeuvre when the opposite direction input will cause a control unit is idle. -
Page 11: Phases
MANOEUVER PHASES MOVEMENT The movement phase comprises the SAFETY TESTS actual gate movement and management The safety tests phase is performed in the of the safety devices. First the red semap- beginning of every maneuver before hore light is activated if any relay is set as moving the gate. - Page 12 MANOEUVER Soft stop ramp: If the SOFT STOP succesfully, the red semaphore light is parameter is set, when the gate reaches deactivated and the green semaphore the position set as a percentage of the light is activated. OP SOFT STOP gate limits ( for opening LOCKING...
-
Page 13: Safeties
MANOEUVER SAFETY viour. To activate the safety test the TEST BEAM 1 The control panel has several safety TEST BEAM 2 parameter or the parameter devices that can affect the operation must be used. Once set, the default testing during operation: STOP, photocells, safety strategy is to test both before opening edge, amperometric sensor and encoder. -
Page 14: Safety Edges
MANEUVER SAFETY EDGES open or resistive contact strips. In the case of resistive strips, the panel only supports SAFETY EDGESThe panel has a safety two connected in parallel on the same edge input that can be enabled and input, con guring the input for 4K1. con gured. -
Page 15: Encoder
MANOEUVER ENCODER MOTOR When the encoder is enabled it can be The BOX L VF1L allows independent used as a safety measure too. The contro- control of speed and power for a 230VAC ller monitors the time lapse between three-phase motor (delta wiring). Speed position changes and implements two can be set between 10Hz (Hertz) and protections::... -
Page 16: Electrical Wiring Diagram
ELECTRICAL WIRING DIAGRAM Fig.2 230VAC phase 230VAC neutral Earth terminal Motor earth terminal U motor phase V motor phase W motor phase Flashing lamp output Garage light output contact Encoder power positive ENC1 or B encoder input (VF1L-EA) A encoder input (VF1L-EA) Encoder power negative Negative 15VDC power output for... -
Page 17: Accesories And Peripherals
ACCESORIES AND PERIPHERALS Radio card SMINN BXL-VF1L Transmitter-receiver light barrier set Beacon light and light barrier stand ust be connected to pin 18 of the terminal block... -
Page 18: Outputs
MANOEUVER OUTPUTS RELAY - SAFETY TEST SEC. TEST mode performs a safety The panel has two relay outputs, one test on devices that are powered exter- precon gured as a ashing lamp and the nally or that need a test signal. The contro- other con gurable. -
Page 19: Display
When entering the menu the controller will show one by one the logged error, waiting for ENTER to be pressed n between. NOTE: The controller will still work normally even if there are logged errors. SMINN BXL-VF1L... -
Page 20: Options
OPTIONS VALOR TEXTO LCD PAGINAS POR DEFECTO AUTOMATIC CLOSING AUTO CLOSE 8, 10 Enables automatic closing after the pause phase FAST LIGHT BARRIER CLOSING The pause after a photocell reversal lasts for the FAST PHOTO CLS time set as photocell closure.Only visible if CLOSE ON BEAM is not NO OPTIONAL AUTO OPTIONAL AUTO... - Page 21 ENCODER Enables maneuver control via encoder. ENCODER Options (VF1L): YES / NO Options (VF1L-EA): NO / SMINN / MFZ / SOMMER / ENCODER POLARITY ENC POLARITY NORMAL Establishes the spin direction interpreted by the encoder. Options : NORMAL / INVERTED...
-
Page 22: Timings
TIMINGS DEFAULT LCD TEXT ADJUSTMENT PAGES VALUE OPEN TIME Opening time 15 sec 0-1800 sec 7, 10 CLOSE TIME Closing time 15 sec 0-1800 sec 7, 10 AUTO CLOSE T Automatic closing time 15 sec 1-60000 sec PEDEST LIM. End position of pedestrian maneuver 0-100 % AUTO C PED T Pedestrian automatic closing time... - Page 23 TIMINGS DEFAULT LCD TEXT ADJUSTMENT PAGES VALUE OP SOFT VEL Opening motor soft speed 25Hz 10-100Hz 9, 10, 13 CL SOFT VEL Closing motor soft speed 25Hz 10-100Hz 9, 10, 13 OP ACCEL RAMP Opening acceleration ramp time 1,5 sec 0-100 sec CL ACCEL RAMP Closing acceleration ramp time...
-
Page 24: Maintenance
MAINTENANCE This menu allows checking maneuver MAX CON LEARN counters, input status, setting a mainte- Shows the maximum current draw regis- nance password and loading default t e r e d d u r i n g a l e a r n i n g m a n e u v e r . values. -
Page 25: Error Log
ERROR LOG The BOX L VF1L controller stores while it is LEARNING MISSING powered the errors that occur during It is mandatory to perform a learning maneuvers. When there are errors to maneuver before operating the gte check the board will display an E in each normally. -
Page 26: Light Barrier Shielding
LIGHT BARRIER SHIELDING Many light barriers are particularly If the problem persists : sensitive to electromagnetic noise - Supply the light barrier receiver with generated by inverters or modulating direct current either from the control electronics. If the light barrier installed is panel power supply output (terminals 16 working correctly when the motor is and 17) or from an external power supply. -
Page 27: Warranty
WARRANTY This product has undergone a complete W A S T E O F E L E C T R I C A L A N D TEST during its manufacturing process ELECTRONIC DEVICES (WEEE) that guarantees its reliability and proper operation. -
Page 28: Notes
NOTES... - Page 29 NOTES...
-
Page 30: Technical Characteristics
Directive 2014/30/EU - Electromagnetic compatibility Directive 2014/35/EU - Low voltage Directive 2006/42/EC - Machinery Directive 2011/65/EU - RoHs Directive 2012/19/EU - WEEE Zamudio - 02.21.2020 José Miguel Blanco Pérez Chief technical of cer www. sminn.com info@sminn.com innovative in electronics... -
Page 31: Parts Exploded View
VF1L EXPLOSION Fig3 1. Captive screws 7. Pass-throughs for 16 / 24mm pipes 2. Power status LED 8. Plug-in terminal blocks 3. Traf c light card (optional) 9. Power relays 4. Vacuum rubber gasket 10. Bus load relays 5. External xing with just three screws 11. - Page 32 innovative in electronics...
