Sminn BOX H VF20 Instruction Manual

Universal control panel for gates with 1 three-phase 230vac motor with frequency converter
Hide thumbs

Advertisement

Quick Links

Download this manual
BOX H VF20
UNIVERSAL CONTROL PANEL
For gates with 1 three-phase 230VAC motor with frequency converter
INSTRUCTION MANUAL
innovative in electronics

Advertisement

loading
Need help?

Need help?

Do you have a question about the BOX H VF20 and is the answer not in the manual?

Questions and answers

Related Manuals for Sminn BOX H VF20

Summary of Contents for Sminn BOX H VF20

  • Page 1 BOX H VF20 UNIVERSAL CONTROL PANEL For gates with 1 three-phase 230VAC motor with frequency converter INSTRUCTION MANUAL innovative in electronics...
  • Page 2 COMPONENTS SITUATION Fig.1 1. WBAND card socket 8. AC power input fuse 2. TRSH radio card socket 9. High voltage zone 230VAC 3. TEST Run button 10. Bus capacitors 4. Connection terminals 11. Bus load relays 5. Double 24VDC power supply 12.
  • Page 3 Fig.2 SMINN BXH-VF20 STOP INDUSTRIAL GATE CONTROL 1. LCD display 2. Option selection keypad 3. STOP and movement button panel 4. Disconnector 5. Stop button 6. Status LEDs...
  • Page 5 INDEX Features ............. 2 Symbols Limitations on the use of motor controllers ..........2 ......Encoder pulses Warnings ........... 2 Installation ..........3 Important safety instructions for installation ..........3 . Relay output (NO contact) Important safety instructions for usage ............3 Wiring ............
  • Page 6 230V output dedicated to of children. Observe applicable local, braking. national and European regulations. The Socket for SMINN radio card (6 pins). information contained in this document Socket for WBAND card. may contain errors which will be corrected Independent inputs for two strips in subsequent editions.

  • Page 7: Installation

    INSTALLATION The box is xed to the wall with four commercial, garage doors and gates. The screws, all of them external (See Fig.3). moving door must be prevented from making contact with any object or limiting Drill four holes in the wall, respecting the the contact force (e.g.
  • Page 8 WIRING The panel has four potential-free relay The panel is supplied with 230VAC 50Hz contacts normally open to perform via terminals 1 and 2. The earth connection different functions such as lamp control, is made at terminal 3. traf c lights, electric lock, etc... These relays can withstand 16A over 24VDC or 230VAC.
  • Page 9 27 28 29 30 The radio card socket allows a SMINN ENCODER radio card (6 pins) to be plugged in, enabling the opening command to be The panel supports the connection of an given via radio transmitters. RS485 absolute encoder via a quick connector or a 4-terminal terminal block.
  • Page 10 Force diagram of a value, and the BACK key is used to cancel the modi cation of a parameter Fd: Dynamic force and, in general, to go backwards. Fs: Static force SMINN BOX H VF20...
  • Page 11 MANOEUVER PROG. The control panel has a con guration the panel will indicate that after pressing wizard that allows you to select the most ENTER again, the learning manoeuvre will important parameters and start up the begin. control panel quickly. From here you can carry out the following To start the wizard, with the door closed, steps using the ENTER key, the LL1 key...
  • Page 12 MANOEUVER ACTIVATION OPEN/CLOSE The OPEN/CLOSE mode uses LL1 as the The key inputs (marked LL1, LL2 and LL3) opening command and LL2 as the closing and a radio card installed in the radio command. When the door is in motion the socket can be used to start a manoeuvre opposite direction input will cause a when the control panel is idle.
  • Page 13 PHASES MOVEMENT The movement phase comprises the SAFETY TESTS actual gate movement and management The safety tests phase is performed in the of the safety devices. First the red semap- beginning of every maneuver before hore light is activated if any relay is set as moving the gate.
  • Page 14 Soft stop ramp: If the SOFT STOP closing. When the maneuver is inverted parameter is set, when the gate reaches the controller calculates the needed time the position set as a percentage of the using the current gate position as referen- OP SOFT STOP ce, If the gate does not reach its end point gate limits (...
  • Page 15 TEST BEAM 1 SAFETIES To activate the safety test the TEST BEAM 2 parameter or the parameter The controller supports many safety must be used. Once set, the default testing devices that can affect the maneuver: strategy is to test both before opening STOP, light barriers, safety edges, FSS, and closing.
  • Page 16 SHORT INV. T. parameter and then stops and cancels the maneuver. CURRENT SENSOR Overcurrent protection: If the contro- ller detects that the motor current draw The BOX H Vf20 controller rises above a limit set in the OC LIMIT monitors the current draw on...
  • Page 17 OBSTACLE DETECTION MOTOR The controller has many means to detect The BOX H VF20 allows independent an obstacle. The behaviour of the gate control of speed and power for a 230VAC when one is encountered is set by the three-phase motor (delta wiring). Speed PUSH SEC.

  • Page 18: Electrical Wiring Diagram

    ELECTRICAL WIRING DIAGRAM Fig.3 230VAC phase 230VAC neutral Earth terminal U motor phase V motor phase W motor phase Motor earth terminal 4-5 Brake output contact 230V 6-7 RL2 output relay 8-9 RL3 output relay 10-11 RL4 output relay 12-13 RL5 output relay 24VAC 12V.A.
  • Page 19 ACCESORIES AND PERIPHERALS Radio card Transmitter-receiver light barrier set Beacon light and light barrier stand ust be connected to pin 18 of the terminal block...
  • Page 20 MANOEUVER OUTPUTS RELAY - SAFETY TEST SEC. TEST mode performs a safety The panel has four independently con gu- test on devices that are powered exter- rable outputs that allow the appropriate nally or that need a test signal. The contro- external elements to be con gured for ller will activate the relay to perform the each installation.
  • Page 21 When entering the menu the controller will show one by one the logged error, waiting for ENTER to be pressed n between. NOTE: The controller will still work normally even if there are logged errors. SMINN BXH-VF20...
  • Page 22 OPTIONS VALOR TEXTO LCD PAGINAS POR DEFECTO AUTOMATIC CLOSING AUTO CLOSE 8, 10 Enables automatic closing after the pause phase FAST LIGHT BARRIER CLOSING The pause after a photocell reversal lasts for the FAST PHOTO CLOSE time set as photocell closure.Only visible if CLOSE ON BEAM is not NO OPTIONAL AUTO OPTIONAL AUTO...
  • Page 23 If the safety test phase detects any failure the mode swtiches to dead man temporally. ENCODER ENCODER Enables maneuver control via encoder. Options: NO / SMINN / MFZ / SOMMER / GFA ENCODER POLARITY ENC POLARITY NORMAL Establishes the spin direction interpreted by the encoder.
  • Page 24 TIMINGS DEFAULT LCD TEXT ADJUSTMENT PAGES VALUE OPEN TIME Opening time 15 sec. 0-1800 sec. 7,10 CLOSE TIME Closing time 15 sec. 0-1800 sec. 7,10 AUTO CLOSE T Automatic closing time 15 sec. 1-60000 sec. PEDEST LIM. End position of pedestrian maneuver 0-100 % AUTO C PED T Pedestrian automatic closing time...
  • Page 25 DEFAULT LCD TEXT ADJUSTMENT PAGES VALUE OP ACCEL RAMP Opening acceleration ramp time 1,5 sec. 0-100 sec. CL ACCEL RAMP Closing acceleration ramp time 1,5 sec. 0-100 sec. OP SOFT RAMP Opening soft stop ramp time 1,5 sec. 0-100 sec. CL SOFT RAMP Closing soft stop ramp time 1,5 sec.

  • Page 26: Maintenance

    MAINTENANCE This menu allows checking maneuver ENCODER counters, input status, setting a mainte- Shows the current gate position in form of nance password and loading default encoder pulses. values. MAX CONS. VERSION Shows the maximum current draw regis- S h o w s t h e r m w a r e v e r s i o n o f t h e tered during normal maneuvers.

  • Page 27: Error Log

    ERROR LOG The BOX H VF20 controller stores while it LEARNING MISSING is powered the errors that occur during It is mandatory to perform a learning maneuvers. When there are errors to maneuver before operating the gte check the board will display an E in each normally.
  • Page 28 ABSOLUTE ENCODER WIRING The BOX H VF20 control unit can be these also carry the motor power signal. connected to the absolute encoder of - Use the correct size of motor power GFA-ELEKTROMATEN, SOMMER and cable and avoid making loops with it.
  • Page 29 BOX H VF20 EXPLOSION Fig.4 1. Vacuum rubber gasket 2. Stop button 3. Captive screws 4. Removable cable glands 5. Fixed cable glands 6. Circuit breaker 7. Plug-in terminal blocks 8. Power relays 9. Bus load relays...

  • Page 30: Warranty

    WARRANTY This product has undergone a complete W A S T E O F E L E C T R I C A L A N D TEST during its manufacturing process ELECTRONIC DEVICES (WEEE) that guarantees its reliability and proper operation.

  • Page 31: Technical Characteristics

    CE DECLARATION OF CONFORMITY The company ELSON ELECTRÓNICA, S. A. Pol. Torrelarragoiti, P6 – A3 48170 Zamudio – Vizcaya (SPAIN) Declares: The product BOX H VF20 motor controller Manufactured Under the trademark SMINN For use in Residential, Commercial or light industry environments.
  • Page 32 NOTES...
  • Page 33 NOTES...
  • Page 34 NOTES...
  • Page 35 NOTES...
  • Page 36 innovative in electronics...
