S100
Getting Started
know the I/O array
Connecting Cables
Package Contents
Your package should contain:
.
.
S100 unit
.
Power/IO/Light Control/UART cable
.
Ethernet cable
.
VGA cable
Quick Start Guide(this document)
Quick Start Guide
S100
Quad Core x86 Smart Camera
Power/IO/Light Control/UART
Rev.1.00
Features
.
Intel Atom Quad core processor N4200
.
1MP/90fps,5MP/35fps,monochrome
global shutter CMOS sensor
.
IP67-rated housing and
M12 connectors
.
Advanced image processing
support
.
Intel VT-x,VT-d and Open GL
compatible with image acquisition
I/O Array
VGA/USB
.
2xDIO,1xUSB2.0 port,
1xRS232 port,1xMIPI CSI,
1xGbE Ethernet
.
124L x 58W x 36.2H mm
.
Flexible software support
.
Compact, rugged form factor
Ethernet
Nov 18,2018
