FUTUREROBOT S100 Quick Start Manual

Dual/quad core x86 smart camera

Advertisement

Quick Links

S100
Getting Started
know the I/O array
Connecting Cables
Package Contents
Your package should contain:
.
.
 S100 unit
.
 Power/IO/DP/UART cable
.
 Ethernet cable
.
 USB cable
 Qucik Start Guide(this document)
Quick Start Guide
S100
Dual/Quad Core x86 Smart Camera
Features
.
Intel Atom Dual/Quad core
processor E3930/E3950
.
1MP,120fps,monochrome
global shutter CMOS sensor
.
IP67-rated housing and
M12 connectors
.
Advanced image processing
support
.
Intel VT-x,VT-d and Open GL
compatible with image acquisition
I/O Array
Power/IO/DP/UART
Ethernet
Rev.1.00
.
4xDIO,1xUSB2.0 port,
1xRS232 port,1xMIPI CSI,
1xGbE Ethernet
.
120L x 55W x 37H mm
(4.73x2.17x1.46 in)
.
Flexible software support
.
Compact, rugged form factor
USB
Oct 8,2018

Advertisement

loading
Need help?

Need help?

Do you have a question about the S100 and is the answer not in the manual?

Questions and answers

Summary of Contents for FUTUREROBOT S100

  • Page 1 Compact, rugged form factor Connecting Cables support Intel VT-x,VT-d and Open GL compatible with image acquisition I/O Array Package Contents Power/IO/DP/UART Your package should contain:  S100 unit Ethernet  Power/IO/DP/UART cable  Ethernet cable  USB cable  Qucik Start Guide(this document) Oct 8,2018...
