RVS-2100
Getting Started
know the I/O array
Connecting Cables
Package Contents
Your package should contain:
.
.
RVS-2100 unit
.
Power/IO/USB/UART cable
.
Ethernet cable
.
DP cable
Qucik Start Guide(this document)
Quick Start Guide
RVS-2100
Dual/Quad Core x86 Smart Camera
Features
.
Intel Atom Dual/Quad core
processor E3930/E3950
.
1MP,120fps,monochrome
global shutter CMOS sensor
.
IP67-rated housing and
M12 connectors
.
Advanced image processing
support
.
Intel VT-x,VT-d and Open GL
compatible with image acquisition
I/O Array
Power/IO/USB/UART
Ethernet
Rev.1.00
.
4xDIO,1xUSB2.0 port,
1xRS232 port,1xMIPI CSI,
1xGbE Ethernet
.
120L x 55W x 37H mm
(4.73x2.17x1.46 in)
.
Flexible software support
.
Compact, rugged form factor
DP
Nov 18,2018
Advertisement
Table of Contents
Related Manuals for FUTUREROBOT RVS-2100
Summary of Contents for FUTUREROBOT RVS-2100
- Page 1 Compact, rugged form factor Connecting Cables support Intel VT-x,VT-d and Open GL compatible with image acquisition I/O Array Package Contents Power/IO/USB/UART Your package should contain: RVS-2100 unit Ethernet Power/IO/USB/UART cable Ethernet cable DP cable Qucik Start Guide(this document) Nov 18,2018...
- Page 2 Tighten the threaded collar (cable side) to fix the connection. Ethernet cable Power/IO/USB/UART cable DP cable Installing the OS and Device Driver Download the latest driver from the Futurerobot website. http://www.futurerobottech.com Run. Follow the installation instructions. When prompted,restart your system.
