- Page 1 M1505_EVB User Manual M1505_EVB User Manual Smart Module Series Version： V1.1 Date： 2016-10-31 Copyright © Shanghai Mobiletek Communication Ltd Shanghai Mobiletek Communication Ltd...
- Page 2 Thus, the descriptions herein may not exactly match the product or its accessories which you purchase. Shanghai Mobiletek Communication Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice and without any liability.
- Page 3 M1505_EVB User Manual Version History Date Version Modify records Author 2016-07-14 V1.0 Initial Rongchun.dong 2016-10-31 V1.1 Reformat Tianpan.lin Copyright © Shanghai Mobiletek Communication Ltd...
-
Page 4: Table Of Contents
3.3 UART Interface ..........................8 3.4 TF Card ............................8 3.5 Audio Interface ..........................9 3.6 USB Interface ..........................10 3.7 Functional Test ..........................10 3.7.1 Machine Test ......................... 11 3.7.2 A Single Test.......................... 13 Copyright © Shanghai Mobiletek Communication Ltd... -
Page 5: Overview
M1505_EVB is designed for valuation and test of M1505 module to help developers to debug and test M1505 module. The following figure shows the label of the main functions of M1505_EVB. This article will describe the various parts of its functions in later chapters. Figure 1 M1505 _EVB Front view Copyright © Shanghai Mobiletek Communication Ltd... - Page 6 M1505_EVB User Manual Figure 2 M1505_EVB Rear view Figure 3 M1505_EVB Downward view Figure 4 M1505_EVB Upward view Copyright © Shanghai Mobiletek Communication Ltd...
- Page 7 Figure 6 M1505_EVB Right view Table 1 Label illustrate 1.LCD(HD1280*720) 2.Speaker 3.Flashlight 4.Sub Camera(2MP) 5.Flashlight 6.Mian Camera（5MP） 7.USB Interface 8.UART Interface 9.Battery 10. Headset Interface 11.TF Card 12.Main MIC 13.Powerkey 14.SYSRSTB 15.Volume+ 16.Volume+ 17.Volume- 18.Sub MIC Copyright © Shanghai Mobiletek Communication Ltd...
-
Page 8: M1505_Evb External Device And Functional Test
SOM. In the boot state, pressing "13, Powerkey" can enter standby mode. In the boot state, pressing "13, Powerkey" 2 to 3 seconds can choose to Shutdown SOM. If you press the “14, SYSRSTB” key, you can make the SOM power off. Figure 8 Powerkey and SYSRSTB Copyright © Shanghai Mobiletek Communication Ltd... -
Page 9: Uart Interface
Figure 9 M1505 UART interface 3.4 TF Card Such as figure 10, the M1505_EVB provides a TF interface. The "11, TF card" can support maximum capacity of 128 GB TF card. Figure 10 TF card Copyright © Shanghai Mobiletek Communication Ltd... -
Page 10: Audio Interface
The audio interfaces include one headset interface, one Speaker and two MIC interfaces. Such as figure 11“10, Headset interface”, it can support the 3.5mm earphone interface. Figure 11 3.5mm Headset interface When pull out earphone, the M1505_EVB default use figure 12 "2, Speaker". Figure 12 Speaker Copyright © Shanghai Mobiletek Communication Ltd... -
Page 11: Usb Interface
OTG function. Figure 14 USB interface 3.7 Functional Test Such as figure 15, enter the test mode: Click Settings → Choose about tablet → Consecutive click 6 times on model number. Copyright © Shanghai Mobiletek Communication Ltd... -
Page 12: Machine Test
Such as figure 16, click item at the top of the machine test, then began to test. Figure 16 Test mode interface Such as figure 17, if the test item is success, the test items displayed as blue. If the test item is failed, Copyright © Shanghai Mobiletek Communication Ltd... - Page 13 Figure 17 Such as figure 18, in the process of test, touch the prompt dialog box to choose "success" or "failed", and then enter the next test. Figure 18 Copyright © Shanghai Mobiletek Communication Ltd...
-
Page 14: A Single Test
Choose one option in individual test. Such as figure 19, click the Success interface if TF card is normal. Figure 19 Such as figure 20, if the test is success, the test items displayed as blue. If the test is failed, the test items displayed as red. Figure 20 Copyright © Shanghai Mobiletek Communication Ltd...
