- Page 1 M1506_EVB User Manual M1506_EVB User Manual Smart Module Series Version： V1.3 Date： 2017-03-31 Copyright © Shanghai Mobiletek Communication Ltd Shanghai Mobiletek Communication Ltd...
- Page 2 Thus, the descriptions herein may not exactly match the product or its accessories which you purchase. Shanghai Mobiletek Communication Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice and without any liability.
- Page 3 Version Modify records Author 2016-10-12 V1.0 Initial Jason.liao The machine pictures and instructions; Functional 2016-10-22 V1.1 Tianpan.lin testing of instructions 2016-10-29 V1.2 The introduction of the TF card Tianpan.lin 2017-03-31 V1.3 Change logo Jason.liao Copyright © Shanghai Mobiletek Communication Ltd...
-
Page 4: Table Of Contents
3.3 UART Interface ............................ 8 3.4 SIM Card and TF Card ........................8 3.5 Audio interface ........................... 10 3.6 USB ..............................11 3.7 Functional Test ..........................11 3.7.1 Machine test ..........................11 3.7.2 A single test ..........................13 Copyright © Shanghai Mobiletek Communication Ltd... -
Page 5: Overview
M1506_EVB is designed for the development of M1506 module to help developers to debug and test M1506 module. The following figure shows the label of the main functions of M1506_EVB. This article will describe the various parts of its functions in later chapters. Figure 1 M1506 _EVB FRONT VIEW Copyright © Shanghai Mobiletek Communication Ltd... - Page 6 M1506_EVB User Manual Figure 2 M1506_EVB REAR VIEW Figure 3 M1506_EVB DOWNWARD VIEW Figure 4 M1506_EVB UPWARD VIEW Copyright © Shanghai Mobiletek Communication Ltd...
- Page 7 Table 1 Label Illustrate 1.LCD(HD1280*720) 2.Speaker 3.Flashlight 4.Sub Camera(2MP) 5.Flashlight 6.Mian Camera（5MP） 7.USB Interface 8.UART Interface 9.Battery 10. Headset Interface 11.SIM1 12.TF Card 13.SIM2 14.Main MIC 15.POWKEY 16.SYSRSTB 17.Volume+ 18.Volume+ 19. Volume- 20.Sub MIC Copyright © Shanghai Mobiletek Communication Ltd...
-
Page 8: M1506_Evb External Device And Functional Test
SOM. In the boot state, pressing "15, POWKEY" can enter standby mode. In the boot state, pressing "15, POWKEY" 2 to 3 seconds can choose to Shutdown/Restart SOM. If you press the “16， SYSRSTB” key, you can make the SOM power off. Figure 8 POWKEY and SYSRSTB Copyright © Shanghai Mobiletek Communication Ltd... -
Page 9: Uart Interface
The "11, SIM1" supports 3G WCDMA network and GSM 2G network. The "13, SIM2" supports 3G WCDMA network and GSM 2G network. The "12, TF Card" can support maximum capacity of 128 GB TF card. Copyright © Shanghai Mobiletek Communication Ltd... - Page 10 Note: When use less than 32 GB TF card, there is no compatibility problems. If TF cards more than 32GB have been formatted by Windows system, they should be formatted again by Android system before used. Under the Android system format of TF card, have no this problem. Copyright © Shanghai Mobiletek Communication Ltd...
-
Page 11: Audio Interface
When pull out headphones, the M1506_EVB default use figure 12 "2, speaker". Figure 12 Speaker The M1506_EVB supports two MIC. There is noise reduction in handset mode, not in hands-free mode. It is only stereo recording in recording mode. Copyright © Shanghai Mobiletek Communication Ltd... -
Page 12: Usb
In dial-up panel, input "* #*# 88 #* # *" and enter the test mode. 3.7.1 Machine test Such as figure 15, click item at the top of the machine test, then began to test. Figure 15 Test mode interface Copyright © Shanghai Mobiletek Communication Ltd... - Page 13 Figure 16 Such as figure 17, in the process of test, touch the prompt dialog box to choose "success" or "failed", and then enter the next test. Figure 17 Copyright © Shanghai Mobiletek Communication Ltd...
-
Page 14: A Single Test
Choose one option in individual test. Such as figure 18, click the Success interface if TF card is normal. Figure 18 Such as figure 19, if the test is success, the test items displayed as blue. If the test is failed, the test items displayed as red. Figure 19 Copyright © Shanghai Mobiletek Communication Ltd...
