Mode 3 Charging Cable manual
Type 1 SAE J1772
Features:
Charging plug meet:
Operating temperature: -30ºC to +50ºC
Excellent protection performance
Protection Grade IP55-Working
condition.
Mechanical Properties
Mechanical life: no-load plug in / pull out
> 10000times
Impact of external force: can afford 1m
Page | 1
User manual for evplug changing cables PN. EV210XX
Type 2 Mennekes IEC 62196-2
drop and 2T vehicle run over pressure
Electric Performance
Rated Current and Voltage: as table
attached below
﹒Insulation Resistance: >1000MΩ
(DC500V)
﹒Terminal Temperature Rise: < 50K
﹒Contact impedance: 0.5 mΩ Max
www.evplugchargers.com
Advertisement
Table of Contents
Related Manuals for evplug EV21011
Summary of Contents for evplug EV21011
- Page 1 Mechanical Properties ﹒Terminal Temperature Rise: < 50K Mechanical life: no-load plug in / pull out ﹒Contact impedance: 0.5 mΩ Max > 10000times Impact of external force: can afford 1m Page | 1 User manual for evplug changing cables PN. EV210XX www.evplugchargers.com...
- Page 2 ﹒If the unit does not work properly in ﹒Before charging, make sure the power accordance with the operating plug and outlet are compatible. instructions, do not use this unit. Contact Page | 2 User manual for evplug changing cables PN. EV210XX www.evplugchargers.com...
- Page 3 Changes or modifications to this product by a service center other than the authorized one may void the product warranty. Page | 3 User manual for evplug changing cables PN. EV210XX www.evplugchargers.com...
