TYPE 2 FEMALE CONNECTOR
ASSEMBLING PN.20011
Features:
Charging plug meet: IEC 62196-2
Operating temperature: -30ºC to +50ºC
Excellent protection performance
Protection Grade IP65-Working condition.
Mechanical Properties
Mechanical life: no-load plug in / pull out >
10000times
Impact of external force: can afford 1m drop
Warnings:
﹒Carefully read these instructions and
Page | 1
Type 2 Mennekes IEC 62196-2
User manual for evplug Type 2 connector PN. EV20012
and 2T vehicle run over pressure
Electric Performance
Rated Current and Voltage: as table
attached below
﹒Insulation Resistance: >1000MΩ (DC500V)
﹒Terminal Temperature Rise: < 50K
﹒Contact impedance: 0.5 mΩ Max
your vehicle owner's handbook before
charging your EV.
www.evplugchargers.com
