U-Line H-2510 Assembly Instructions Manual

SHELF BIN ORGANIZER
39" TALL

TOOLS NEEDED

7/16" (11 mm) Phillips Head
Wrench Screwdriver
Lock Nut x 43
Shelf x 7
1. Install Side Braces
For 12" deep units, attach side braces to the longer
side of the posts. From the bottom up, locate the 4th
hole. From the top down, locate the 3rd hole. Insert
bolts through side braces and posts. Tighten bolts with
nuts. (See Figure 1)
For 18" deep units, attach side braces to the
longer side of the posts. From the bottom up,
locate the 4th hole. From the top down, locate the
6th hole. Insert bolts through side braces and
posts. Tighten bolts with nuts. (See Figure 1)
PAGE 1 OF 6

PARTS

Bolt x 43
Side Brace x 4 (2 Sets)

ASSEMBLY

Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Post x 4
Back Brace x 2 (1 Set)
Longer
Shorter
Side
Side
Figure 1
