U-Line WIRE SHELF BIN ORGANIZER Quick Start Manual

WIRE SHELF BIN
ORGANIZER
Post x 4

INSTALLATION OF SELF-LEVELERS AND OPTIONAL CASTERS

Figure 1
Figure 2
Figure 3
PAGE 1 OF 6
1-800-295-5510
uline.com
PARTS
Shelf x 12
TO INSTALL SELF-LEVELERS
NOTE: If installing casters, do not install self-levelers.
1. Make sure post is positioned as shown. (See Figure 1)
2. Insert self-leveler into open end of post.
3. Tap on ground until self-leveler slides into post.
4. Repeat steps 2 and 3 for other posts.
TO INSTALL OPTIONAL CASTERS
1. Make sure post is positioned as shown. (See Figure 2)
2. Engage the wheel brakes to keep casters from rolling during
assembly. Use a rubber mallet to tap caster stems into posts.
(See Figure 2)

INSTRUCTIONS FOR UNIT ASSEMBLY

1. Start with the lowest shelf. Snap the interlocking pieces of a
shelf support (wide end down) around the post at the lowest
groove where shelf is to be located. Slide the support up or
down until it snaps onto the groove. Add a shelf support to the
same place on the remaining posts. (See Figure 3)
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Shelf Support x 48 Sets Self-Leveler x 4
0321 IH-8476
