CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS
IN THE AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD INSERT. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
BLUE RIDGE 500-I
INSERT
(ESW0014 Model)
Wood Insert
Owner's Manual
Part 2 of 2
INSTALLATION AND
OPERATION REQUIREMENTS
Safety tested according to
ULC S628, UL 1482 and
UL 737 by an accredited
US Environmental Protection
Agency phase II certified
wood insert compliant with
2020 cord wood standard.
laboratory.
EPA
< ≤
2.5
g/h
46325_IA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLUE RIDGE 500-I and is the answer not in the manual?

Questions and answers

Related Manuals for Englander BLUE RIDGE 500-I

Summary of Contents for Englander BLUE RIDGE 500-I

  • Page 1 Wood Insert Owner's Manual Part 2 of 2 INSTALLATION AND OPERATION REQUIREMENTS BLUE RIDGE 500-I INSERT (ESW0014 Model) Safety tested according to ULC S628, UL 1482 and UL 737 by an accredited laboratory. US Environmental Protection Agency phase II certified wood insert compliant with 2020 cord wood standard.
  • Page 2 It is also highly recommended to register the warranty online at https://www.englander-stoves.com/ca/en/warranty-registration/ Registering the warranty will help to quickly find the information needed on the unit.
  • Page 3 CERTIFICATION PLATE...

  • Page 4: Table Of Contents

    Optional Fire Screen Installation ..................23 Air Tubes and Baffle Installation ..................24 Log retainers installation .....................27 Removal Instructions ....................28 3.10 Exploded Diagram and Parts List ................29 ENGLANDER LIMITED LIFETIME WARRANTY ................. 32 Page 4 Product Specification Manual - Blue Ridge 500-I...

  • Page 5: General Information

    This appliance is officially tested and certified by an independent agency. Tested and certified in compliance with CFR 40 part 60, subpart AAA, section 60.534(a)(1(ii) and ASTM E3053 based on the ATM send by EPA on October 12th, 2017. Carbon monoxide. Product Specification Manual - Blue Ridge 500-I Page 5...

  • Page 6: Specifications

    CAN/CSAZ240 MH standard. Tested and certified in compliance with CFR 40 part 60, subpart AAA, section 60.534(a)(1(ii) and ASTM E3053 based on the ATM send by EPA on October 12th, 2017. Page 6 Product Specification Manual - Blue Ridge 500-I...

  • Page 7: Dimensions

    586mm 699mm 586mm 24 1/2" 623mm 28 7/8" 732mm 50" Figure 3 : Front View Figure 4 : Side View - Minimum Insert Projection 1269mm 11 3/4" 298mm Product Specification Manual - Blue Ridge 500-I Page 7 16 5/8" 422mm...
  • Page 8 13" 330mm 22 7/8" 330mm 22 7/8" 581mm 581mm 17 7/8" 17 7/8" 453mm 453mm Figure 6 : Front View - Combustion Chamber Figure 7 : Side View - Combustion Chamber Page 8 Product Specification Manual - Blue Ridge 500-I...

  • Page 9: Epa Loading

    For better results, close the air control gradually from the closing of the door to the complete closing of the air control. Product Specification Manual - Blue Ridge 500-I Page 9...
  • Page 10 1.4.4 Logs placement The images below show how to place the logs in the combustion chamber as described previously. SECTION E SECTION E-E Page 10 Product Specification Manual - Blue Ridge 500-I...

  • Page 11: Clearances To Combustible Material

    31" (787 mm) 18 3/8" (457 mm) If a fresh air intake is required, it is recommended to add at least 4" to the width of the minimum opening of the hearth. Product Specification Manual - Blue Ridge 500-I Page 11...

  • Page 12: Floor Protection

    (406 mm USA) and at least 18" (457 mm Canada) without an R value. If the hearth elevation is lower than 6" (152 mm), the non-combustible (B) floor protection in front of the insert should have an R value equal or greater than 2.00 and shall extend 27" (686 mm) in front of the unit. Page 12 Product Specification Manual - Blue Ridge 500-I...

  • Page 13: R Value

    RESISTANCE (R) PER INCH PER INCH THICKNESS Micore® 160 0.39 2.54 Micore® 300 0.49 2.06 Durock® 1.92 0.52 Hardibacker® 1.95 0.51 Hardibacker® 500 0.44 Information as reported by manufacturers and other resources. Product Specification Manual - Blue Ridge 500-I Page 13...
  • Page 14 K value = 0.75 Thickness = 1 R value = Thickness/K = 1/0.75 = 1.33 Horizontal still air can’t be «stack» to accumulate R-values; each layer must be separated with another non-combustible material. Page 14 Product Specification Manual - Blue Ridge 500-I...

  • Page 15: Installing Options On Your Product And Replacing Parts

    The test must be performed all around the door. If the paper slips out easily anywhere, either adjust the door or replace the gasket. Product Specification Manual - Blue Ridge 500-I Page 15...
  • Page 16 Using a flat screwdriver, turn the adjustable hinge rods in the direction shown to adjust the doors. Tighten all door hinge pressure screws when they are at the desired positions. Configurations 1-2-3-4-5-6, show in which direction these act on the adjustment of the door. Page 16 Product Specification Manual - Blue Ridge 500-I...

  • Page 17: Mandatory Installation

    • Empty the combustion chamber and install the air control handle (A) with the set screw (B) as shown below: Figure 8 : Empty the combustion chamber Figure 9 : Installing the air control wood handle Product Specification Manual - Blue Ridge 500-I Page 17...
  • Page 18 Once the insert is properly positioned in the fireplace opening, secure the pipe with the pipe connectors (B) and screws (C) provided. Then tighten the floor fixing bolts located on each side of the unit (D). DETAIL C Page 18 Product Specification Manual - Blue Ridge 500-I...

  • Page 19: Blower And Ash Lip Installation

    Install the ash lip on the insert with four Center the blower on the ash lip and push screws. it against the firebox. Then push it until it clips. Product Specification Manual - Blue Ridge 500-I Page 19...

  • Page 20: Faceplate And Trims Installation

    Lay the panels on a flat and non abrasive surface. Align the top panel holes (A) with the left and right panels (B). Secure together using the bolts (D) and nuts (C) provided. Page 20 Product Specification Manual - Blue Ridge 500-I...
  • Page 21 Then install one faceplate retainer spring on each side of the faceplate and attach the other end of the spring to the brackets on the left and right sides of the insert. Push the faceplate against the fireplace’s front. Product Specification Manual - Blue Ridge 500-I Page 21...

  • Page 22: Optional Fresh Air Intake Kit Installation

    Install the plate (K) with four screws (L) on the unused side of the insert. The pipe must be HVAC type, insulated, and must comply with ULC S110 and/or UL 181, Class 0 or Class 1. Page 22 Product Specification Manual - Blue Ridge 500-I...

  • Page 23: Optional Fire Screen Installation

    In the United States or in provinces with a particulate emissions limit (e.g.: US EPA), the use of open-door wood stoves with a rigid firescreen is prohibited. Open the door. Hold the fire screen by the two handles and bring it close to the door opening. Product Specification Manual - Blue Ridge 500-I Page 23...

  • Page 24: Air Tubes And Baffle Installation

    Starting with the rear tube, lean and insert the right end of the secondary air tube into the rear right channel hole. Then lift and insert the left end of the tube into the rear left channel. Page 24 Product Specification Manual - Blue Ridge 500-I...
  • Page 25 To remove the tubes use the above steps in reverse order. Note that secondary air tubes (A) can be replaced without removing the baffle board (B) and that all tubes are identical. Product Specification Manual - Blue Ridge 500-I Page 25...
  • Page 26 Page 26 Product Specification Manual - Blue Ridge 500-I...

  • Page 27: Log Retainers Installation

    Log retainers installation 2" 2" Product Specification Manual - Blue Ridge 500-I Page 27...

  • Page 28: Removal Instructions

    • Remove the blower assembly (E). • Remove the three screws securing the pipe connector (B). • Unscrew the bolts securing the insert to the floor on each side of the unit (C). Page 28 Product Specification Manual - Blue Ridge 500-I...

  • Page 29: Exploded Diagram And Parts List

    3.10 Exploded Diagram and Parts List Product Specification Manual - Blue Ridge 500-I Page 29...
  • Page 30 STAINLESS WASHER ID 17/64" X OD 1/2" SE31318 DOOR HINGE REPLACEMENT KIT AC01281 RIGID FIRESCREEN 30898 ROUND WOODEN BLACK HANDLE 60013 POWER CORD 96" X 18-3 type SJT (50 pcs per carton) Page 30 Product Specification Manual - Blue Ridge 500-I...
  • Page 31 RHEOSTAT KNOB SE74193 INSERT BLOWER 44028 CERAMIC THERMODISC F110-20F 44089 DOUBLE CAGE BLOWER 144 CFM 115V - 60Hz - 1.1A AC01298 5"Ø FRESH AIR INTAKE KIT 49028 5" WHITE AIR INTAKE TERMINATION Product Specification Manual - Blue Ridge 500-I Page 31...

  • Page 32: Englander Limited Lifetime Warranty

    90 days *Subject to limitations above **Picture required Shall your unit or a components be defective, contact immediately your ENGLANDER dealer. To accelerate processing of your warranty claim, make sure to have on hand the following information when calling: •...
  • Page 33 Product Specification Manual - Blue Ridge 500-I Page 33...
  • Page 34 Resale is strictly prohibited. The manufacturer may update St-Augustin-de-Desmaures (Québec) Canada this document from time to time and cannot be responsible G3A 2H3 for problems, injuries, or damages arising out of the use 1-877-356-6663 of information contained in any document obtained from https://www.englander-stoves.com/ unauthorized sources. tech@sbi-international.com...
