Setra Systems C290 Operating Instructions

LIMITED WARRANTY AND LIMITATION OF LIABILITY

SETRA warrants its products to be free from defects in materials and workmanship, subject to the fol-
lowing terms and conditions: Without charge, SETRA will repair or replace products found to be defec-
tive in materials or workmanship within the warranty period; provided that:
a) the product has not been subjected to abuse, neglect, accident, incorrect wiring not our own,
improper installation or servicing, or use in violation of instructions furnished by SETRA;
b) the product has not been repaired or altered by anyone except SETRA or its authorized service
agencies;
c) the serial number or date code has not been removed, defaced, or otherwise changed; and
d) examination discloses, in the judgment of SETRA, the defect in materials or workmanship devel-
oped under normal installation, use and service;
e) SETRA is notified in advance of and the product is returned to SETRA transportation prepaid.
Unless otherwise specified in a manual or warranty card, or agreed to in a writing signed by a SETRA
officer, SETRA pressure and acceleration products shall be warranted for one year from date of sale.
The foregoing warranty is in lieu of all warranties, express, implied or statutory, including but not
limited to, any implied warranty of merchantability for a particular purpose.
SETRA's liability for breach of warranty is limited to repair or replacement, or if the goods cannot be
repaired or replaced, to a refund of the purchase price. SETRA's liability for all other breaches is limited
to a refund of the purchase price. In no instance shall SETRA be liable for incidental or consequential
damages arising from a breach of warranty, or from the use or installation of its products.
No representative or person is authorized to give any warranty other than as set out above or to as-
sume for SETRA any other liability in connection with the sale of its products.
OPERATING INSTRUCTIONS
SANITARY PRESSURE TRANSMITTERS

GENERAL INFORMATION

Your Setra C290 Sanitary Pressure Transmitter has been carefully tested and calibrated be-
fore shipment and it should be handled with the same care given any precision instrument.
Detailed performance information is listed on the specification bulletin for the transmitter.
The C290 is designed according to 3A Standard, as indicated on etched cover label, for sanitary
installations. It has a rugged MICRO-TIG welded stainless steel housing and is exceptionally in-
sensitive to vibration, shock, EMI/RFI interference and other environmental extremes. The C290
is insensitive to the thermal shocks typical of CIP and SIP installations.

INSTALLATION NOTES

Model C290's should not require adjustment at installation. If adjustments are made it
is important to replace and tighten the zero and span screws (with O-rings) to
prevent moisture from entering.
The C290 is vented through the cable. Connections to the cable should be made in a
dry junction box vented to atmosphere. Insure that moisture cannot enter the end of the
cable.
The C290 is shipped with a rubber boot over the stainless steel pressure sensing
diaphragm to protect the diaphragm during shipment, storage, and handling prior to
installation. This boot should not be removed until the transmitter is to be installed and
should be used whenever the unit is removed from its installation. Do not contact the
diaphragm with sharp objects, screwdrivers or other mechanical devices.
Environment - The C290 Transmitter is designed to be used with any gas or liquid
compatible with 316L stainless steel (316 for ranges > 30 psig). It is designed to be
splash and drip proof for wash-down cleaning and can also be completely submerged
with the exception of the open end of the electrical cable.
Cleaning - The pressure sensing diaphragm will withstand normal high pressure
washing and partial vacuums created by fast cooling of steam sterilized tanks. However,
be sure not to exceed the proof pressure (listed on specification sheet). In high pressure
washing, care should be taken not to spray directly on diaphragm as it could result in
exceeding the proof pressure. The C290 can also be cleaned by dipping the diaphragm
in a container of cleaning solution or by wiping gently with a soft cloth.
Temperature Limits - The operating temperature limits of the C290, based on the limits
of the electronics, are -40 o F to 260 o F.
Thermal Effects
Zero Shift
Span Shift
Mounting - The C290 will mount directly to a mating tri-clover flange along with a tri-clover
type clamp and gasket. (2 inch tri-clover for ranges up to 30 psig and 1.5 inch for higher ranges.)
Horizontal mounting is recommended to enable proper cleaning and draining of liquids from
sensor cavity.
Note: The output signal is not appreciably affected by clamping forces so it is not necessary to
orient the flange circle to any special position for best performance.
MODEL C290
20 o F to 180 o F range
± 2.00% F.S./100 F
o
± 2.00% F.S./100
