ADDENDUM
Frequency
offers a wide choice of programs using different frequency configurations :
• Eleven simultaneous multi-frequency programs, each with different combinations of frequencies and
internal parameter settings (see chapter Programs for the specific features of each one). The maximum
frequency used by FMF programs can be configured by the user : 14 kHz - 24kHz or 40 kHz.
To help you better adapt to your soil and desired targets, the
frequency band used from above. For example : You can configure your machine with 24kHz limit to be
less sensitive to very small conductors and more stable in difficult ground conditions. Selecting the 14kHz
limit can help focus on high conductors while reducing the crackling from some ferrous targets. Selecting
the 40kHz limit will remain the most versatile option because it selects the widest frequency range, which
will be more sensitive to a wider range of targets, non-ferrous targets close to ferrous and better perfor-
mance on some mineralized ground.

FMF multi frequency programs

Press
FREQ. MAX
40
If you are experiencing too much interference:
Press
kHz
start an automatic scan by pressing

Ground

Press
G.B.
settings.
90
When entering the Ground menu (Grab,Tracking,...)
mode, unlike
This is practical for listening to the ground and its response during the adjustment, but
also gives you a quick insight to the ground at any time, for example a clean zone or
identifying a mix of ferrous and non-ferrous targets.

Audio Filter

Press
AUDIO FIL.
This function is to filter the audio and produce softer and more fluty sound, especially
0
when target is at the detection limit. At depth the signal will be less scratchy. In some
situations, Audio Filter can gain a little extra depth.
On the beach:
In land:
At 0:
Audio Type
HIGH SQUARE
The High Square sound has a richer and clearer harmonic compared to the standard Square, especially
on deep or small targets which are higher and more identifiable. When combined with the Pitch tone, the
strong targets near the coil are lower and softened compared to the standard Square tone.

Ferrous T.ID

Press
FE. T.ID
This function turns on/off the visual target IDs for targets that fall below the discrimination
setting, for example when FE TID is set OFF you only see the TIDs above the discrimina-
tion adjustment even if you keep the Iron Volume ON.
2
or to select one of the 3 frequency limits.
(3 sec) then shift the frequencies and find the quietest band with
to access the G.B. (ground balance) and press
I.
choose
AUDIO
high levels like 2 to 4 can be combined with a low reactivity (0 to 1).
lower levels like 1 or 2 are suggested to help recognize the short iron blips.
The Audio Filter is deactivated.
choose
SETTINGS
.
SCAN
then (3 sec).
then (3 sec).
offers you the possibility to limit the
2 seconds to enter into G.B.
moves into an all metal
V1.0
and or
