Page 1
Manuale d’Istruzioni Frigorifero Doppia Porta RCT323WH1 Si prega di leggere a entamente le istruzioni riportate in questo manuale e di conservarlo per ogni eventualità futura.
Page 3
Attenzione: Rischio di incendio/Materiali infiammabili IT-2...
Page 4
l prodotto non dovrebbe essere trasportato,installato o utilizzato da minori o altre persone inabili. IT-3...
Page 5
PRECAUZIONI DI SICUREZZA Si prega di seguire sempre e in ogni caso le precauzioni di sicurezza qui di seguito riportate: L'alimentatore del frigorifero deve essere sempre corrispondente a quanto descritto nelle specifiche. Utilizzare sempre una presa standard dotata di messa a terra. Il frigorifero dovrebbe funzionare in luoghi ove non siano presenti sostanze infiammabili o esalazioni esplosive E' assolutamente vietato introdurre nel frigorifero sostanze volatili infiammabili,...
Page 6
INSTALLAZIONE POSIZIONAMENTO Il frigorifero dovrebbe essere posizionato in un L'unità deve essere posizionata su un terreno ambiente asciutto e ventilato. Non posizionare piano e stabile. Utilizzate i piedini regolabili l'unità alla luce solare diretta e tenerla il più anteriori per regolare il livello del frigorifero. lontano possibile da sorgenti di calore.
Page 7
INVERSIONE DELLE PORTE Nota: assicurarsi che l'apparecchio sia scollegato e privo di contenuto. 1. Rimuovere la copertura 2. Rimuovere le viti di fissaggio 3. Spostare tutto il blocco della cerniera superiore sul lato opposto dell’apparecchio. Rimuovere il dado. Estrarre la rondella quindi invertire la cerniera di 180° e fissarlo sul lato opposto.
Page 8
4. Rimuovere le viti di fissaggio della cerniera inferiore (mantenere un angolo di inclinazione massimo dell’apparecchio di 45°) 5. Spostare il supporto inferiore della porta e il blocco di posizionamento sul lato opposto 6. Spostare tutto il blocco della cerniera inferiore sul lato opposto dell’apparecchio. 7.
Page 9
9. Invertire la posizione della cerniera superiore. 10. Mettere la porta superiore nella posizione corretta, quindi fissarla alla cerniera superiore. 11. Inserire i tappini di copertura nelle apposite posizioni, quindi regolare i piedini nella posizione più alta. 12. Spostare il livellatore sul lato opposto e regolarlo adeguatamente per consentire la chiusura agevolata delle porte SPAZIO RICHIESTO PER L’APERTURA DELLE PORTE Le porta devono essere in grado di aprirsi completamente come mostrato.
Page 10
LIVELLAMENTO DEL PRODOTTO Regolare i due piedini sulla parte anteriore dell'unità. Se l'unità non si trova in piano, le porte e di conseguenza le guarnizioni potrebbero non richiudersi correttamente. Assicurarsi che i piedini tocchino perfettamente il suolo prima dell'uso. PRIMA DI UTILIZZARE IL PRODOTTO Il frigorifero adotta l'alimentazione AC 220~240V a 50Hz: fluttuazioni di tensione oltre il range di 187 ~ 264V causano problemi di funzionamento o danni.
Page 11
PANORAMICA DI PRODOTTO * Tutte le immagini in questo manuale sono da considerarsi a scopo puramente indicativo FUNZIONAMENTO ACCENSIONE DELL’ APPARECCHIO Il selettore di temperatura (termostato) si trova sulla parete laterale destra interna del frigorifero: Impostare "Min" per una temperatura meno fredda Impostare "Med"...
Page 12
RUMORI ALL’INTERNO DELL’ APPARECCHIO È possibile che l'unità emani rumori: la maggior parte di questi sono perfettamente normali, e sono causati dalla circolazione del liquido refrigerante nel sistema di raffreddamento. Questo fenomeno è diventato più intenso dopo l'introduzione dei gas privi di CFC. Questo non è...
Page 13
MANUTENZIONE PULIZIA Prima di effettuare qualsiasi operazione di pulizia del frigorifero staccare la spina dalla rete di alimentazione e lettrica. Pulire l'interno dell'apparecchio con una soluzione diluita di sodio bicarbonato. In seguito risciacquare con acqua tiepida con una spugna ben strizzata o un panno. Lavare i ripiani con acqua saponata tiepida e asciugare completamente prima di reinserirli nell'unità.
Page 14
Luce in avaria La porte sono bloccate da alimenti; Le porte non si chiudono Eccessivo ingombro di alimenti correttamente Errata inclinazione dell’apparecchio Rumori Controllare l’inclinazione dell’apparecchio, mantenerlo in equilibrio SERVIZIO DI ASSISTENZA TECNICA Se un problema dovesse persistere anche dopo aver effettuato i controlli sopra indicati, NON TENTATE IN ALCUN MODO DI RIPARARE L'APPARECCHIO.
Page 15
16° C e 38 °C’; Tropicale: ‘questo apparecchio di refrigerazione è destinato all'uso a temperature ambiente comprese tra 16° C e 43 °C’. Le par� ordinate nella seguente tabella possono essere acquisite dal canale COMFEE: Parte ordinata Fornitore...
Contents SAFETY WARNINGS ......................1-2 INSTALLTION ........................3 Location ........................3 Reversing the Door Swing ..................3 Door Space Requirements ..................7 Levelling the Unit ....................... 8 Cleaning Before Use ....................8 Before Using Your Unit ....................8 Interior Accessories ....................8 PRODUCT OVERVIEW ......................
1. SAFETY WARNINGS Warning : risk of fire / flammable materials THIS appliance is intended to be used in household and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses and by clients in hotels, motels and other residential type environments;...
Page 18
DANGER : Risk of child entrapment.Before you throw away your old refrigerator or freezer: -Take off the doors. -Leave the shelves in place so that children may not easily climb inside. refrigerator must be disconnected from the source of electrical supply before attempting the installation of accessory.
2. INSTALLTION 2.1 Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption.
Page 20
3) Replace the top-hinge and the top-door limit block and the door bearing bush to the other side. Remove the nut with sleeve.Take off the washer then remove the axes to the other side and fixed. Remove the door limit block Please taking out another door limit block, with screw mounting to the door 4) Disassemble the screws fixed the bottom-hinge with cross-slot screwdriver .
Page 21
Note:the refrigerator-freezer incline angle less 45°. 5) Replace the bottom door bearing bush and the limit block. 6) Replace the bottom hinge to the other side then fix it with screws 7) Replace the mid-hinge. EN-5...
Page 22
8) Set the bottom door right position,fix the mid-hinge. 9) Replace the top-hinge. 10) Set the top door right position,fix the top-hinge and the cover. 11) Install the four screw caps and two catches to corresponding position. ·Ensure the Appliance is unplugged and empty. ·Adjust the two leveling feet to their highest position.
Door Space Requirements The unit's door must be able to open fully as shown. W×D≥902×1052mm Levelling the Unit To do this adjust the two levelling feet at the front of the unit. If the unit is not level, the door and magnetic seal alignments will not be covered properly.
damages to the product or fire accidents. Do not place flammable items near the refrigerator to avoid fires. This product is household refrigerators and shall be only suitable for the storage of foods. According to national standards, household refrigerators shall not be used for other purposes, such as storage of blood, drugs or biological products.
Drawers, food boxes, shelves, etc. placed according to the position in the picture above are the most energy efficient. *All images in this instruction manual are for indication only; please refer to your individual unit for details. 4. OPERATION 4.1 Switching On Your Unit ◆The thermostat knob is located on the right hand side wall of the refrigerator interior wall of the refrigerator interior...
continuously in order to maintain a low temperature in the cabinet. ◆For the first time you install your refrigerator, set the thermostat knob at “Med”. Give your refrigerator time to cool down completely before adding food. It is the best to wait 24 hours before adding food.
For areas that are difficult to clean in the refrigerator (such as narrow sandwiches, gaps or corners), it is recommended to wipe them regularly with a soft rag, soft brush, etc. and when necessary, combined with some auxiliary tools (such as thin sticks) to ensure no contaminants or bacterials accumulation in these areas.
Low voltage; Failure power or tripping circuit Odorous foods should closely wrapped; Odor Whether foods are rotten; Whether the interior shall be cleaned. It is normal that refrigerator operates for longer time in summer when the ambient temperature is higher; Long-term operation of Do not put too much food in the freezer at one time;...
cleaning could shorten the storage life. 9. DISPOSAL Old units still have some residual value. An environmentally friendly method of disposal will ensure that valuable raw materials can be recovered and used again. The refrigerant used in your unit and insulation materials require special disposal procedures. Ensure that none of the pipes on the back of the unit are damaged prior to disposal.
