VERANDA HRV52
ALERTS AND WARNINGS
Installation must be performed by qualified personnel in accordance with EN and locally applicable
safety regulations on electrical systems for households.
See also the document with the product technical data.
Study this manual in detail before utilising the product.
The stretching of springs creates considerable forces. Be very careful and stand on a firm surface
during the work.
Ensure good lighting of the assembly area. Remove obstacles and impurities. Ensure that no other
persons except the fitters are present in the work area. Unauthorised persons are likely to get in the
way and endanger themselves and other people.
This symbol indicates the possibility of personal injury or damage to the
product.
This symbol indicates warning.
This symbol indicates that force must be used during the activity.
Only use electric screwdrivers with the proper torque set.
This symbol indicates the need of visual check.
This symbol indicates an optional element.
The manufacturer does not accept any responsibility for any inaccuracies or typographical errors
that may be found in this manual. The manufacturer reserves a right to carry out alterations of the
product which it deems necessary or in the user's interest and which do not change the basic
operating and safety characteristics of the device. It is forbidden to make changes of any kind to the
design or configuration without prior consultation with the manufacturer. The end user must receive
operating instruction for the product.
Manual validity: as of 20.05.2023
MEASUREMENT AND INSTALLATION MANUAL
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Isotra HRV52
Summary of Contents for Isotra HRV52
- Page 1 MEASUREMENT AND INSTALLATION MANUAL VERANDA HRV52 ALERTS AND WARNINGS Installation must be performed by qualified personnel in accordance with EN and locally applicable safety regulations on electrical systems for households. See also the document with the product technical data. Study this manual in detail before utilising the product.
-
Page 2: General Instructions
MEASUREMENT AND INSTALLATION MANUAL GENERAL INSTRUCTIONS Several safety measures must be adopted for the safe use and maintenance of the Veranda. Observe the following instructions for your own safety and safety of other persons. Should you have any doubts, contact your supplier. This manual describes the use and operation of standard shading products. -
Page 3: Operating Principle
MEASUREMENT AND INSTALLATION MANUAL 3) Maintain safe distance from the moving sunshade. The moving sunshade is likely to pose a danger or cause personal injury. 4) Prevent operation of the product by children. 5) When operating the sunshade, always have it in sight. Its movement may be obstructed by persons (especially children). - Page 4 MEASUREMENT AND INSTALLATION MANUAL SHUT THE SUNSHADE AT NIGHT. THE USER MUST ALWAYS BE AWARE WHETHER THE SUNSHADE IS OPEN OR SHUT. PREVENT CHILDREN AND UNAUTHORISED PERSONS FROM USING OR PLAYING WITH THE SUNSHADE. THE SAME APPLIES TO SWITCHES AND REMOTE CONTROLS. ALWAYS KEEP THE REMOTE CONTROL OUT OF THE REACH OF CHILDREN.
-
Page 5: Safety Measures
HRV08-ZIP HRV80-ZIP HRV80-ZIP-2P force of 6 Bft. = 49 km/h max. allowed up to wind resistance class 2 = wind HRV52 HRV08-ZIP HRV80-ZIP HRV80-ZIP-2P force of 5 Bft. = 35 km/h max. allowed up to wind resistance class 1 = wind... - Page 6 MEASUREMENT AND INSTALLATION MANUAL • If the lower profile of the Veranda moves at the height under 2.5 metres above the ground, the Veranda must be operated by an impulse switch (the motor stops if you release the switch). This ensures the user always has a good view of the moving Veranda and prevents personal injury.
- Page 7 MEASUREMENT AND INSTALLATION MANUAL − Lubrication of the drum bearings (at least once a year). − Lubrication of the hinge pins of the arms and bearings opposite the control mechanisms using a silicone-based dry lubricant (at least once a year). Note: Do not soil the fabric.
- Page 8 MEASUREMENT AND INSTALLATION MANUAL THIS VERANDA MAY ONLY BE CONTACT YOUR SUPPLIER SHOULD YOU DISASSEMBLED AND REMOVED BY HAVE ANY QUESTIONS OR MATTERS THAT QUALIFIED FITTERS. THE DISASSEMBLY OF ARE NOT EXPLAINED OR INSUFFICIENTLY COMPONENTS MAY BE DANGEROUS AS EXPLAINED IN THIS MANUAL. THE CORDS, SPRING, AND TELESCOPIC THE VERANDA IS A LARGE AND HEAVY POLE ARE UNDER A VERY HIGH...
-
Page 9: General Information
MEASUREMENT AND INSTALLATION GENERAL INFORMATION The Veranda HRV52 shutter is able, to a great extent, to regulate the amount of sunlight entering the room, thus reducing uncomfortably high level of light and heat. The shutter fabric is protected and rolled up in a box which is closed by the lower profile in the completely rolled-up position. The box is fastened to the guide rails. - Page 10 MEASUREMENT AND INSTALLATION MANUAL The recommended minimum angle of slope: − For Soltis 86 and 92 fabrics: 8° − With integrated LED lighting: 10° − For Blackout fabrics: 14° The maximum angle of slope for all variants is 30°. MEASUREMENT Total width = from the centre of the guide rail to the centre of the guide rail.
-
Page 11: Installation
Make sure that the box and lower profile can be opened at all times and that the mechanical parts inside are always accessible. If this rule is not complied with, ISOTRA a. s. shall not bear any costs associated with demolition works! FASTENERS All fasteners are made of stainless steel, and all accessories are always part of the supply. - Page 12 MEASUREMENT AND INSTALLATION MANUAL LIST OF NECESSARY TOOLS • Ladder • Planks • Wood blocks 60×60×300 mm • Electric drill • Phillips screwdriver • Allen keys, sizes 3 and 8 • Fork or ring spanners, sizes 10 and 13 • Nail nippers with bent ends after driving •...
-
Page 13: Installation Instructions
MEASUREMENT AND INSTALLATION MANUAL INSTALLATION INSTRUCTIONS Manual validity: as of 20.05.2023... - Page 14 MEASUREMENT AND INSTALLATION MANUAL Manual validity: as of 20.05.2023...
- Page 15 MEASUREMENT AND INSTALLATION MANUAL HOLDERS – STANDARD Manual validity: as of 20.05.2023...
- Page 16 MEASUREMENT AND INSTALLATION MANUAL Manual validity: as of 20.05.2023...
- Page 17 MEASUREMENT AND INSTALLATION MANUAL Manual validity: as of 20.05.2023...
- Page 18 MEASUREMENT AND INSTALLATION MANUAL CHECK Manual validity: as of 20.05.2023...
- Page 19 MEASUREMENT AND INSTALLATION MANUAL CHECK IF AT LEAST 2–3 CABLE TURNS ARE WOUND ON THE ROLLER see p. 22 Manual validity: as of 20.05.2023...
- Page 20 MEASUREMENT AND INSTALLATION MANUAL Manual validity: as of 20.05.2023...
- Page 21 MEASUREMENT AND INSTALLATION MANUAL see p. 24 Manual validity: as of 20.05.2023...
- Page 22 MEASUREMENT AND INSTALLATION MANUAL TABLE – SPRING DISTANCE R [MM] Slope [mm] * Read off the distance “R” in the highlighted zone depending on the spring type (650 mm / 850 mm). Manual validity: as of 20.05.2023...
- Page 23 MEASUREMENT AND INSTALLATION MANUAL Manual validity: as of 20.05.2023...
- Page 24 MEASUREMENT AND INSTALLATION MANUAL More about the motor and its adjustment can be found in a separate document. Manual validity: as of 20.05.2023...
- Page 25 MEASUREMENT AND INSTALLATION MANUAL Manual validity: as of 20.05.2023...
- Page 26 MEASUREMENT AND INSTALLATION MANUAL COUPLING THE VERANDAS See p. 12 See p. 15 Manual validity: as of 20.05.2023...
- Page 27 MEASUREMENT AND INSTALLATION MANUAL See p. 16 Manual validity: as of 20.05.2023...
- Page 28 MEASUREMENT AND INSTALLATION MANUAL COUPLING 2 GUIDE RAILS In some cases, it is necessary to couple 2 guide rails (when 2 or more systems are installed side by side). This may be done in several ways. 1) FASTENING THE LOWER ATTACHMENT POINT IN THE MIDDLE The fastener is attached directly under the two guide rails.
- Page 29 MEASUREMENT AND INSTALLATION MANUAL 3) FASTENING THE ATTACHMENT POINT UNDER THE LEFT OR RIGHT GUIDE RAIL The fastener is fixed before or after the attachment point used. Manual validity: as of 20.05.2023...
-
Page 30: Troubleshooting
MEASUREMENT AND INSTALLATION MANUAL TROUBLESHOOTING The motor does not roll up or unroll the fabric • The internal end switch in the motor was not activated in either direction. Press both adjusting buttons of the motor and set the end positions. •... - Page 31 MEASUREMENT AND INSTALLATION MANUAL The Veranda is not flush when rolled up • The springs are not adjusted to the same tension. • The spring for the panel which is rolled up the most must be tensioned more (or it is necessary to loosen the other spring).
