Leviton 47120-7 Installation Instructions

®
Seven Mode Panel
For branch and service entrance
Cat. Nos.:
47120-7, 47120-4X7
47277-7, 47277-4X7
Installation Instructions
PK-92954-10-00-00 REV A0
LIMITED TEN YEAR WARRANTY AND EXCLUSIONS
Leviton warrants to the original consumer purchaser and not for the benefit of
anyone else that this product at the time of its sale by Leviton is free of defects
in materials and workmanship under normal and proper use for ten years from
the purchase date. Leviton's only obligation is to correct such defects by repair
or replacement, at its option, if within such ten year period the product is returned
prepaid, with proof of purchase date, and a description of the problem to Leviton
Manufacturing Co., Inc., Att: Quality Assurance Department, 59-25 Little
Neck Parkway, Little Neck, New York 11362-2591. This warranty excludes
and there is disclaimed liability for labor for removal of this product or
reinstallation. This warranty is void if this product is installed improperly or in
an improper environment, overloaded, misused, opened, abused, or altered in
any manner, or is not used under normal operating conditions or not in
accordance with any labels or instructions. There are no other or implied
warranties of any kind, including merchantability and fitness for a particular
purpose, but if any implied warranty is required by the applicable jurisdiction,
the duration of any such implied warranty, including merchantability and fitness
for a particular purpose, is limited to ten years. Leviton is not liable for incidental,
indirect, special, or consequential damages, including without limitation, damage
to, or loss of use of, any equipment, lost sales or profits or delay or failure to
perform this warranty obligation. The remedies provided herein are the exclusive
remedies under this warranty, whether based on contract, tort or otherwise.
For Technical Assistance Call:
1-800-824-3005 / www.leviton.com
PK-92954-10-00-00-A0
Black
Transient voltage surges are short-term deviations from a
desired voltage level or signal that can occur at any time.
Such changes can result in an electronic device
malfunction, or cause extensive damage. Also termed
"spikes" , these occurances take place as a result of
magnetic field/inductive coupling or whenever the line
current is interrupted. They can originate from either
inside a facility, or derive from outside utility lines.
Sources within a facility involve loads that are switched,
such as electric motors that are turned ON and OFF.
Outside transient influences involve utility grid switching.
Leviton Panel Mounted devices are designed to provide
protection for microprocessor-based equipment in
industrial and commercial establishments from high
voltage transients.
Ratings: 47120-7, 47120-4X7 120/208VAC, 3 Phase
47277-7, 47277-4X7 277/480VAC, 3 Phase
• Listed to UL Standard 1449 - 2nd Edition
(effective Feb. 1998).
• CSA certified.
• IEEE C62.41-1991 Category A&B Combination Wave
Suppression.
• Provides seven modes of protection: L-N (3), L-G (3),
N-G (1).
• High-energy solid-state semi-conductor surge
suppression circuitry per phase. Each Line to Neutral,
Line to Ground and Neutral to Ground.
• Each phase provided with independent thermal
fuse protection.

GENERAL INFORMATION

• Green LED diagnostic indicator for each phase.
• Acoustic as well as visual indicators.
• Interior plastic circuit enclosure for added safety and
easy servicing.
• Compatible with Decora Home Controls (DHC).
• Provided with Remote Monitoring Dry Contact
(Form C Rated 120/240V, 5A).
1

INTRODUCTION

DESCRIPTION

SPECIFICATIONS

1
10/29/01, 1:24 PM
NOTES:
• Standard J-Box metal enclosure with pre-punched
standard size knockouts simplifies flush mounting in
typical frame construction environments, and provides
convenient connection means to existing branch panels.
• For superior local TVSS protection, use Leviton Surge
Suppression Outlets to protect against internally-
generated transients between the Seven Mode Panel
and the point of use.
• Cat. Nos. 47120-4X7 and 47277-4X7 are provided with
a NEMA 4X enclosure for outdoor installation.
• TVSS device terminal blocks accept up to #6 AWG wire.
• Recommended conductor size: 10AWG stranded.

TO INSTALL

WARNING:
TO BE INSTALLED AND/OR USED IN
ACCORDANCE WITH APPROPRIATE ELECTRICAL
CODES AND REGULATIONS.
WARNING:
IF YOU ARE NOT SURE ABOUT ANY PART
OF THESE INSTRUCTIONS, CONSULT A QUALIFIED
ELECTRICIAN.
WARNING:
TO AVOID FIRE, SHOCK, OR DEATH; TURN
OFF POWER AT CIRCUIT BREAKER OR FUSE AND TEST
THAT THE POWER IS OFF BEFORE WIRING!
WARNING:
THIS DEVICE IS NOT A LIGHTNING
ARRESTOR. IT WILL NOT SURVIVE LIGHTNING
STRIKES IN CLOSE PROXIMITY TO THE PREMISES.
WARNING:
ELECTROCUTION, FATAL, OR SERIOUS
INJURY AND PROPERTY OR EQUIPMENT DAMAGE
CAN RESULT FROM FAULTY INSTALLATION AND/OR
SERVICING. ALWAYS TURN POWER OFF BEFORE
REPLACING MODULES.
WARNING:
A TVSS MODULE IN A FEED-THROUGH
BRANCH CIRCUIT WILL PROVIDE PROTECTION ONLY
FOR LOADS WIRED DIRECTLY TO IT. IT WILL NOT
PROVIDE PROTECTION TO ANY OTHER MODULES ON
THE SAME BRANCH CIRCUIT.
WARNING:
THIS DEVICE SHOULD BE INSTALLED ON
A LINE THAT IS SERVED BY DISCONNECT MEANS,
SUCH AS DEDICATED 20 AMP CIRCUIT BREAKERS OR
20 AMP FUSED OR 20 AMP FUSED DISCONNECT
SWITCHES.
