RSA Lighting ACCURUS ACT954RMMH Specification Sheet

DESCRIPTION

Remodel housing for Accurus round trims. Includes electronic metal halide
ballast for use with 20W or 39W MR16 Metal Halide lamp.
For remodel applications. Insulation must be kept 3" from all sides and at
least 1" above the housing.

SPECIFICATION FEATURES

A ...Housing
White housing with structural steel arm
and wireway. Connected to integral j-box.
B ...System Protection:
Thermal protection provided to guard
against overheating and misuse of
insulation over and around fixture.
Vent holes in housing provide cooler
operation.
C ...Electrical
Integral j-box and electronic metal halide
ballast. 120V/277V input. Junction box
is U.L. listed for through branch wiring.
Includes five 1/2 trade size knockouts.
D ...Lamp
MR16 style metal halide lamp.
GX10 twist-and-lock lamp socket included.
E ...Mounting
Supplied with 3 (three) spring loaded
mounting clips. May accomodate 1/2",
1", or 1-1/2" ceiling thickness. Includes
adjustable leveling screw.
Ceiling Cut-Out: 4.18"

ORDERING INFORMATION

ACT954RMMH
Housing Lamp Wattage
ACT954RMMH =
20
Accurus Remodel Housing
39
for Round Trim
w/Integral Metal Halide Ballast
www.cooperlighting.com
(not included)
4.18"
5.00"
Voltage
20 watts
= 120 = 120 volts primary
39 watts 277
= = 277 volts primary
*Consult factory for 277V ballast availability.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031
Catalog #
Project
Comments
Prepared by
J-box with integral
electronic metal
halide ballast
11.25"
3.28"
Type
Date
ACCURUS
ACT954RMMH
Remodel Housing
for 5" Round Trim
FOR METAL HALIDE MR16
20W or 39W
rev 122007
