RSA Lighting ACCURUS ACT950MH Specification Sheet

DESCRIPTION

New construction housing for Accurus 5" round trims. Includes electronic
metal halide ballast for use with 20W or 39W MR16 Metal Halide lamp.
For new construction applications. Insulation must be kept 3" from all
sides and at least 1" above the housing.

SPECIFICATION FEATURES

A ...Housing

Housing and plaster frame: 18 gauge CRS
with flat black powder coated internal
finish. Adjustable plaster frame can
accommodate up to 1" ceiling thickness.

B ...System Protection:

Thermal protection provided to guard
against overheating and misuse of
insulation over and around fixture.
Vent holes in housing provide cooler
operation.

C ...Electrical

Integral j-box and electronic metal halide
ballast. 120V/277V input. Junction box
is U.L. listed for through branch wiring.
Includes five 1/2 trade size knockouts

D ...Lamp

MR16 metal halide lamp 20 or 39 watts.
GX10 TAL lamp socket included. Internal
rotation ring with locking adjustment.
Provides 360º rotation of trim and secures
original trim position after relamping.

E ...Mounting

Hanger Bars and Butterfly Brackets
included for residential and commercial
applications respectively.
Ceiling Cut-Out: 4.50" dia.

ORDERING INFORMATION

ACT950MH
__
Housing Lamp Wattage
ACT950MH =
20
Accurus New Construction
39
Housing for Round Trim
w/Integral Metal Halide Ballast
www.cooperlighting.com
12.00"
4.63"
0.5" - 1.0"
__
Voltage
20 watts
= 120 = 120 volts primary
39 watts 277
= = 277 volts primary
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031
Catalog #
Project
Comments
Prepared by
Ceiling
Cut-Out
4.50"dia.
4.63"
13.00"
8.18"
Type
Date
ACCURUS
ACT950MH
New Construction
Metal Halide
for 5" Round Trim
FOR METAL HALIDE MR16
7.25"
Housing
20W or 39W
rev 122007
