Summary of Contents for MotoCrane ULTRA Isolator + SRB
- Page 1 ULTRA Isolator + SRB Operation Manual v1.0 NOV. 2020 ...
-
Page 2: Safety Signal Words
● is used to address practices not related to physical injury The terms IMPORTANT and NOTE are also used to describe ideas for better and more efficient use of the ULTRA Isolator + SRB. 2 ... -
Page 3: Table Of Contents
IMPORTANT: Restricted Use Statement 5 Disclaimer and Limitations of Liability 5 Limited Warranty 6 Intellectual Property 6 Intended Use of ULTRA Isolator + SRB 7 Part Lists 8 Parts of the SRB Solo 8 Parts of the SRB + HL 8 ... -
Page 4: Before The First Drive
Before the First Drive Do the following before using the ULTRA Isolator + SRB for the first time! 1. Read this Operation Manual 2. Read the Warranty in the Terms of Sale 3. Watch any available video tutorials on the ... -
Page 5: Important Product & Safety Instructions
IMPORTANT: Restricted Use Statement The ULTRA Isolator + SRB must only be used by trained operators 18 years of age or older. Only appropriate motor vehicles driven on a closed course with paved or finished surfaces (for example, asphalt, concrete, or tarmac) or moderate off-road (for ... -
Page 6: Limited Warranty
directly or indirectly from the use of the ULTRA Isolator + SRB. By the act of use, setup or assembly, the user accepts all resulting liability. Limited Warranty The ULTRA Isolator + SRB has a limited manufacturer's warranty on parts and assembly. ... -
Page 7: Intended Use Of Ultra Isolator + Srb
Intended Use of ULTRA Isolator + SRB The MotoCrane ULTRA Isolator + SRB are designed to isolate cinema camera stabilizers (brushless gimbals, or “stab heads”) and camera packages from vibration and low to medium frequency shock loads caused by rapid changes in terrain. They are ... -
Page 8: Part Lists
● (Including parts listed in SRB Solo) ● ULTRA Isolator Parts of the Essentials Kit ● (Including parts listed in ULTRA Isolator + SRB) ● 4 pcs of 1-½’’(48-52mm) Speedrail Swivel (Adjustable) clamps ● 2pcs of 1-½’’ Speedrail starters ● 19mm Wrench ... -
Page 9: Ultra Isolator + Srb System Overview
ULTRA Isolator + SRB System Overview SSG NOTE: RATCHET STRAPS NOT PICTURED (REQUIRED FOR USE) 9 ... -
Page 10: Setting Up The Ultra Isolator + Srb
Setting up the ULTRA Isolator + SRB Below is the proper setup sequence of the ULTRA Isolator + SRB 1. Install the 1-½’’ (48-52mm) Speedrail clamps using the provided 4 x M10 Fasteners. If re-configuring clamps between single/dual rail configurations, apply ... - Page 11 3. Secure the ULTRA Isolator to the SRB using the provided M12 fasteners and M12 washers.Torque all M12 fasteners to 18ft-lbs (24Nm). ...
-
Page 12: Attaching Your Payload
Attaching your Payload 1. Remove the M6 Bolts and Quick Release Pin from the ULTRA Isolator and release the Head Adapter by sliding it forward or backwards. 2. Install the Head Adapter to the Payload. Below are the available Head Adapter bolt patterns for reference. ... -
Page 13: Tuning The Ultra Isolator
Tuning the ULTRA Isolator 1. Using the air pump (Included only in Essentials and Ultimate Bundles), increase or decrease the pressure at the rear chamber of the air shock so that the Z-Axis Ride Angle Indicator reads ~20º. N ote: early ULTRA units are equipped with 2 pressure adjustment valves. - Page 14 3. For adjustment of the Pitch and Roll passive damping, manually deflect the stabilized head on either axis to 45º and release. Complete this process for both Pitch and Roll axes. ● If the head does not reach the neutral hanging position, the damping should be decreased (it is too hard/stiff) ...
-
Page 15: Advanced Application Notes
Advanced Application Notes While each setup and configuration is unique, below are suggestions that we have found to be helpful in achieving optimum image stabilization. ● Anti-vibration mounts are h ighly recommended for achieving adequate pan axis stabilization. -
Page 16: Known Hazards
● ULTRA Isolator + SRB: M ake sure the ULTRA Isolator + SRB is secured and does not shift around during operation. All fasteners must be tight and secured, following torque specifications as per the setup instructions. ... -
Page 17: Maintenance
None required - contact Technical Support if you believe the unit requires service or maintenance. Weather & Water ULTRA Isolator + SRB parts are weather resistant (IP65 rated). After using the ULTRA Isolator + SRB in wet or dusty conditions, wipe all components down with a soft dry ... -
Page 18: Revision History
This content is subject to change. Download the latest version from www.motocrane.com/knowledge-base If you have any questions about this document, please contact MotoCrane, LLC by sending an email to c ontact@motocrane.com . ©2020 MotoCrane, LLC. All rights reserved. ...
