Operating Manual
Congratulations on your purchase of laser distance meter TUF HD 50 Lite.
Safety instructions can be found in the end of this user manual and should be carefully read before you
use the product for the first time.
Functions/Applications
Laser distance meter TUF HD 50 is intended to measure distance, lengths, heights and calculate area and
Volume of measured objects. The product is suitable for use at both indoor and outdoor building areas.
Specifications
Working range
Smallest unit displayed
Measuring accuracy
Laser type
Continuous distance measuring (Tracking)
Area/volume
Automatic shutdown
Sound
Battery life
Storage temperature
Working temperature
Storage humidity
Battery
Dimensions
Weight
* Use a target plate to increase the measurement range during daylight or if the target has poor
reflection properties
** In favorable conditions (good target surface properties, room temperature) up to 10 m. In
unfavorable conditions, such as intense sunshine, poorly reflecting target surface or considerable
temperature variations, accuracy can decrease by ± 0.35 mm/m.
Set
1. Laser distance meter – 1 pc.
2. Carry pouch with a strap – 1 pc.
3. User manual – 1 pc.
4. Batteries LR3 (AAA) – 2 pcs.
Insert/replace batteries
TUF
HD 50
0,05...50 m*
1 mm
±2 mm**
Class II, 635 nm, < 1 mW
Yes
Yes
2,5 min
Yes
Up to 6000 times
-20...+60 °С
0...+40 °С
RH85%
2 х 1.5V AAA LR3 (alkaline)
105 mm х 47 mm х 27 mm
83 g
Advertisement
Table of Contents
Related Manuals for TUF HD 50
Summary of Contents for TUF HD 50
- Page 1 Functions/Applications Laser distance meter TUF HD 50 is intended to measure distance, lengths, heights and calculate area and volume of measured objects. The product is suitable for use at both indoor and outdoor building areas.
- Page 2 Remove the battery cover. Insert the batteries, observing correct polarity. Put the battery cover back. Remove the batteries when the product is not used for a long time to avoid corrosion and battery depletion. Both batteries should be replaced at the same time. Both batteries must be of the same brand with the same charge level.
- Page 3 Display 1. Laser indicator 2. Reference point 3. Area/volume measuring mode 4. Continuous distance measurement mode (Tracking) 5. Battery charge level 6. Area/volume unit 7. Unit 8. Display line Operation Reference point setting It is possible to set the reference point - from the top or bottom end of the product. The default reference point is the bottom end of the product.
- Page 4 2) Continuous distance measurement (Tracking) Press and hold during 2 seconds. Symbol will be blinking on the display. The product will take measurements one after the other, showing the last measured value. To exit the mode press 3) Area Press .
- Page 5 Measuring conditions Measuring range The range is limited to 30 m. At night or dusk and if the target is in shadow the measuring range without target plate may increase. Use a target plate to increase the measurement range during daylight or if the target has poor reflection properties.
- Page 6 6) After holding warranty works by TUF warranty period is not renewed or extended. 7) TUF is not liable for loss of profit or inconvenience associated with a defect of the device, the rental cost of alternative equipment for the period of repair.
