OR STEEL light POSEIDON 24VDC Technical Manual

TECHNICAL SHEMATICS
95 95
INSTALLATION SHEMATICS
All data are given for information purposes only. They do not constitute a contractual commitment on our part and are subject
to change at any time.
PMMA DIFFUSANT T PMMA DIFFUSAN
55 55
Parallel wiring 24VDC
TECHNICAL MANUAL
POSEIDON
24VDC
2,1
ACS
IP69 IK10
A A+ A++
T° max 55°C
Poseidon is the star spotlight for light coloured water jets! This spotlight, designed in
316L stainless steel, will provide magical colours for your fountains and water jets. It is
simply fixed on the nozzle of the fountain or water jet. Give a new dimension to your
water effects and take advantage of the incredible capacity of this lighting ring. This
LED spotlight is also programmable with an infinite range of lighting effects.
Electrical features
POWER 5x2.5W
SUPPLY 24VDC
POWER Not included
SUPPLY
WIRING Parallel
Features
lighting technology
AVERAGE LIFE OF THE 60 000 hours
Certificated L90 B10
LED
COLOUR EMISSION 2700K - 3000K -
4000K - 6000K
RED - GREEN
BLUE - AMBER
10°-25°-40-115°
BEAM
INITIAL OUTFLOW 980lm at 3000k
Mechanical features
Ø120mmx90
SIZE
WEIGHT 2.1kg
MATERIAL 316L Stainless steel
General features
OPERATING - 20°c ~+ 40°
TEMPERATURE
PROTECTION RAITING IP69
RESISTANCE INDEX IK10
A / A+ / A++
ENERGY CLASS
APPLICANCE CLASS CLASS III
WALKOVER FIXTURE NO
DRIVE-OVER FIXTURE NO
POWER SUPPLY Supply wire 2x0.5mm2
in IP68
CABLES
PHOTOBIOLOGICAL Risk group I
SAFETY
