Introduction
■Item to prepare
Firmware update process
■
1. Download the firmware update file.
2. Extract the ZIP file.
3. Copy the extracted firmware update file to a microSD card.
4. Update the firmware.
5. Confirm that the firmware has been updated correctly.
M4 Firmware Update Guide
Proper display is not possible on grayscale devices.
M4
microSD card
Windows or macOS computer
with Internet access
Supported recording media
microSDHC: 4 GB – 32 GB
microSDXC: 64 GB – 1 TB
Always format microSD cards on the M4
after purchasing them new or using them with
a different device.
Advertisement
Related Manuals for Zoom M4
Summary of Contents for Zoom M4
- Page 1 Internet access Supported recording media microSDHC: 4 GB – 32 GB microSDXC: 64 GB – 1 TB Always format microSD cards on the M4 after purchasing them new or using them with a different device. microSD card Firmware update process ■...
-
Page 2: Updating The Firmware
Updating the Firmware This guide explains firmware update to version 1.10 as an example. 1. Download the firmware update file. Download the ZIP file that contains the firmware update file from the M4 download page. - Page 3 On Windows Extract the ZIP file Select the folder that contains the downloaded ZIP file. Click ①“Compressed Folder Tools” and then click ② “Extract all”. This extracts the ZIP file. ① ② M4̲v1.10̲E.zip M4̲v1.10̲E M4̲v1.10̲E M4̲v1.10̲E M4̲Firmwa M4̲Firmwa M4SYSTEM re̲Update̲...
- Page 4 Copy the firmware update file to a microSD card. Copy the “M4SYSTEM.BIN” file to a microSD card. microSD M4̲SD(F:) M4̲v1.10̲E M4̲v1.10̲E M4̲v1.10̲E M4̲SD(F:) M4SYSTEM M4̲Firmwa M4̲Firmwa M4SYSTEM re̲Update̲ re̲Version̲ .BIN .BIN History̲E.p Guide̲E.pdf Firmware update file Copy the firmware update file...
- Page 5 After downloading, open the ①“Downloads” folder which appears at the right end of the Dock by default. Then, click ②. Downloaded files will be shown. ② ① Copy the firmware update file to a microSD card. Copy the “M4SYSTEM.BIN” file to a microSD card. microSD M4̲v1.10̲E M4̲SD M4̲Firmware̲ M4̲Firmware̲Ver M4SYSTEM.BIN M4SYSTEM.BIN Update...e̲E.pd sion...ory̲E.pdf...
- Page 6 Install new batteries in the M4 or connect an AC adapter. NOTE The firmware update is not possible if the remaining battery power is low. Insert the microSD card into the M4. Slide toward This turns the M4 power on and opens the Home Screen on the display.
- Page 7 Press This opens the Menu Screen on the display. to select “System” and press to confirm. to select “Firmware” and press to confirm.
- Page 8 Press to select “Execute” and press to confirm. Slide toward until “Goodbye! See You!” appears on the display.
- Page 9 Then, turn the power on and try updating again. Slide toward This turns the M4 power off. NOTE If the firmware update failed, starting the unit might not be possible and the REC indicator might blink. Turn the...
- Page 10 Confirming that the firmware has been updated correctly Check the firmware versions used by the M4. Press This opens the Menu Screen on the display. to select “System” and press to confirm. to select “Firmware” and press to confirm.
- Page 11 Check the firmware version. ● ZOOM CORPORATION will bear no responsibility for any losses or third-party claims resulting from the use of this software. Moreover, distribution, sale, leasing, rental, alteration, and reverse engineering without permission of this software are prohibited. The specifications of this software and the contents of this document could be changed without notice in the future.
