Zoom MicTrak M2 Quick Start Manual

Hide thumbs Also See for MicTrak M2:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
An Operation Manual with more detailed explanations and other documents
related to this product can be viewed on the following website.
You must read the Usage and Safety Precautions before use.
© 2022 ZOOM CORPORATION
Copying or reprinting this manual in part or in whole without permission is prohibited.
You might need this manual in the future. Always keep it in a place where you can access it easily.
The contents of this manual and the specifications of the product could be changed without notice.
Quick Tour
www.zoom.jp/docs/m2

Advertisement

Table of Contents
loading

Related Manuals for Zoom MicTrak M2

Summary of Contents for Zoom MicTrak M2

  • Page 1 You must read the Usage and Safety Precautions before use. © 2022 ZOOM CORPORATION Copying or reprinting this manual in part or in whole without permission is prohibited. You might need this manual in the future. Always keep it in a place where you can access it easily.

  • Page 2: Inserting Microsd Cards

    Inserting microSD cards Supported recording media microSDHC: 4 GB – 32 GB microSDXC: 64 GB – 1 TB • Always turn the power off before inserting or removing a microSD card. • To remove a microSD card, push it further into the slot and then pull it out. Turning the power on Use only one type of battery (alkaline, NiMH or lithium) at a time.
  • Page 3 Making settings when first turned on Setting the language Setting the date format to select the language The year, month and day will be used in the recording file name in the order set here. to confirm. Setting the date and time Select a setting item, and press Change the value, and press to confirm.

  • Page 4: Formatting Microsd Cards

    Formatting microSD cards Always format microSD cards in order to maximize their performance after purchasing them new or using them with a different device. All data previously saved on a microSD card will be deleted when it is formatted. The microSD card formatting screen can also be opened by pressing while turning the power on.
  • Page 5 Making input and recording settings ■ Selecting the recording file type This will record and save stereo files with the left and STEREO right signals from the built- in XY mic. This will record and save mono files that mix the left MONO and right signals from the built-in XY mic.

  • Page 6: Playing Recordings

    Recording The indicator will light red and This ends recording. recording will start. Slide toward HOLD when recording to prevent misoperation. Playing recordings Operations during playback This opens the FILE LIST Screen. Use these to move the file playback position backward/ forward.

  • Page 7: Functions Of Parts

    Functions of parts ■ Front ■ Left side ■ Right side ⑦ HEADPHONE/LINE OUT jack This outputs sound to headphones or a connected device. ⑧ VOLUME buttons Use these to adjust the volume output from the speaker and headphones. ⑨ Battery compartment closure screw Use this when installing and removing the battery compartment.

  • Page 8: Other Functions

    Recording is not possible → Confirm that the microSD card has open space. See the ZOOM website (zoomcorp.com) for informa- → Confirm that a microSD card is loaded properly in the tion about microSD cards that have been confirmed to work with this unit.
