00450-M SHRINKSTATION
OPERATIONS MANUAL
www.techniksusa.com
COMPLETE INSTALLATION AND TROUBLESHOOTING GUIDE
Techniks is a proud member of Techniks Tool Group.
Connect with Techniks Tool Group
Techniks Inc. 9930 E. 56th St. Indianapolis, IN 46236 | 800.597.3921 | www.techniksusa.com | info@techniksusa.com
Advertisement
Table of Contents
Related Manuals for Techniks 00450-M
Summary of Contents for Techniks 00450-M
- Page 1 00450-M SHRINKSTATION OPERATIONS MANUAL www.techniksusa.com COMPLETE INSTALLATION AND TROUBLESHOOTING GUIDE Techniks is a proud member of Techniks Tool Group. Connect with Techniks Tool Group Techniks Inc. 9930 E. 56th St. Indianapolis, IN 46236 | 800.597.3921 | www.techniksusa.com | info@techniksusa.com...
- Page 2 IMPORTANT - CAUTIONS & WARNINGS The Model 00450-M has been constructed using the latest technology and are extremely safe and easy to operate. Despite that, there is still some danger if these units are operated incorrectly and/or by untrained personnel.
- Page 3 Shrink Fit holders under some conditions. Sand blasting the cutter shanks has improved the holding power. Techniks ShrinkFIT holders are made of H13 tool steel, tempered at 1050˚F. Heating a tool holder to or above temper point will permanently damage the holding power of the tool holder. Never use an alternate heat source on shrink fit toolholders or damage to the toolholder and cutting tool may occur.
- Page 4 00450-M PARTS IDENTIFICATION & MACHINE REQUIREMENTS FEATURES • Output power of 22 kw • Change 1/8" - 1-1/4" shanks in seconds NEMA L16-30P NEMA L16-30R • Automatic cooling cycle by compressed air NEMA L16-30P plug comes installed on power cord. Requires a NEMA L16-30R PRODUCT SPECS receptacle.
- Page 5 OPERATIONS GUIDE MACHINE SETUP • Machine requires a level, stable surface and good ventilation for proper operation. Keep the machine clean and dry at all times. • Connect the machine to your power supply. The machine operates on 480V on a 3-phase 30 amp circuit. •...
- Page 6 OPERATIONS GUIDE HEATING CYCLE • Heating duration is set by default based upon shank size. Use the gray slider bar on the touch screen to add or subtract time. • Wearing the insulated glove on one hand, with your other hand, press and hold the red button located on the induction head.
- Page 7 Declaration of Conformity This declaration of conformity is issued under the sole responsibility of the manufacturer Declarer’s Name: Techniks Tool Group Declarer’s Address: 9930 E 56 Street Indianapolis, IN 46236 Type of Equipment: Electrically Heated Appliances Product Description: Shrink Fit Tool Changer...
- Page 8 Phone: (800) 597-3921 or (317) 803-8000 • Fax: (317) 803-8001...
