Techniks 00450 Operation Manual
  1. Manuals
  2. Brands
  3. Techniks Manuals
  4. Industrial Equipment
  5. 00450
  6. Operation manual

Techniks 00450 Operation Manual

Shrinkstation
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

Techniks Inc. 9930 E. 56th St. Indianapolis, IN 46236 | 800.597.3921 | www.techniksusa.com | info@techniksusa.com
00450 SHRINKSTATION
OPERATIONS MANUAL
www.techniksusa.com
COMPLETE INSTALLATION AND TROUBLESHOOTING GUIDE
Techniks is a proud member of Techniks Tool Group.
Connect with Techniks Tool Group:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 00450 and is the answer not in the manual?

Questions and answers

Related Manuals for Techniks 00450

Summary of Contents for Techniks 00450

  • Page 1 Techniks Inc. 9930 E. 56th St. Indianapolis, IN 46236 | 800.597.3921 | www.techniksusa.com | info@techniksusa.com 00450 SHRINKSTATION OPERATIONS MANUAL www.techniksusa.com COMPLETE INSTALLATION AND TROUBLESHOOTING GUIDE Techniks is a proud member of Techniks Tool Group. Connect with Techniks Tool Group:...
  • Page 2 IMPORTANT - CAUTIONS & WARNINGS The Model 00450 has been constructed using the latest technology and are extremely safe and easy to operate. Despite that, there is still some danger if these units are operated incorrectly and/or by untrained personnel.
  • Page 3 POWER REQUIREMENTS & HEATING SPEEDS Techniks Model 00450 operates on a 440-480 VAC, 20 amp, 3-phase power supply. Tool holders for smaller cutting tools require less power to heat, but must be heated to a higher temperature than larger tools to perform insertion and extraction.

  • Page 4: Product Specs

    00450 PARTS IDENTIFICATION & MACHINE REQUIREMENTS FEATURES • Output power of 13kw • Change 1/8" - 1-1/4" shanks in seconds NEMA L8-20P NEMA L8-20R NEMA L8-20P plug comes installed on • Automatic cooling cycle by compressed air the power cord. Requires a NEMA L8-20R receptacle.

  • Page 5: Machine Setup

    OPERATIONS GUIDE MACHINE SETUP • Machine requires a level, stable surface and good ventilation for proper operation. Keep the machine clean and dry at all times. • Connect the machine to your power supply. The machine operates on 480V on a 3-phase 20 amp circuit. •...

  • Page 6: Heating Cycle

    OPERATIONS GUIDE HEATING CYCLE • Heating duration is set by default based upon shank size. Use the gray slider bar on the touch screen to add or subtract time. • Wearing the insulated glove on one hand, with your other hand, press and hold the red button located on the induction head.
