6-Inch Models - Garmin ECHOMAP PLUS Owner's Manual

6-Inch Models

Specification
Dimensions on cradle and bail mount with swivel base (W x H x D)
Display size (W x H)
Display resolution
Weight
Compass-safe distance
Clearance to nearest obstruction
Max. power draw
Typical current draw at 12 Vdc (RMS)
Max. current draw at 12 Vdc
Wireless frequency
7-Inch Models
Specification
Dimensions on cradle and bail mount (W x H x D)
Display size (W x H)
Display resolution
Weight
Clearance to nearest obstruction
Max. power draw
Typical current draw at 12 Vdc (RMS)
Max. current draw at 12 Vdc
Wireless frequency
114
Measurement
21.8 x 13.0 x 6.2 cm (8.6 x 5.1 x 2.6 in.)
13.7 x 7.7 cm (5.4 x 3.1 in.)
15.2 cm (6.2 in.) diagonal
WVGA, 400 x 800 pixels
0.75 kg (1.6 lb.)
65 cm (25.6 in.)
8.0 cm (3.14 in.)
12 W
0.7 A
1.25 A
2.4 GHz @ 17.2 dBm maximum
Measurement
25.9 x 15.4 x 6.3 cm (10.2 x 6 x 2.5 in.)
15.5 x 8.7 cm (6.1 x 3.4 in.)
17.8 cm (7 in.) diagonal
WVGA, 400 x 800 pixels
0.77 kg (1.7 lb.)
11.5 cm (4.5 in.)
15 W, 9 W with a GT-52 transducer
0.8 A
2.1 A
2.4 GHz @ 18.5 dBm maximum
Appendix
