AZTEC (PLC)
INSTALLATION INSTRUCTIONS
MONO EQUIPMENT
Queensway
Swansea West Industrial Estate
Swansea. SA5 4EB UK
COMPLETE OPERATION AND MAINTENANCE INSTRUCTIONS
FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19
Enter Serial No. here._____________________________________
In the event of an enquiry please quote this serial number.
DOUGHNUT FRYER
IMPORTANT INFORMATION
ARE AVAILABLE AT www.monoequip.com
and
Tel. +44(0)1792 561234
email:spares@monoequip.com
Spares Tel.+44(0)1792 564039
Fax. 01792 561016
FILE 7
Advertisement
Table of Contents
Related Manuals for Mono AZTEC PLC
Summary of Contents for Mono AZTEC PLC
- Page 1 MONO EQUIPMENT Tel. +44(0)1792 561234 Queensway email:spares@monoequip.com Swansea West Industrial Estate Spares Tel.+44(0)1792 564039 Swansea. SA5 4EB UK Fax. 01792 561016 COMPLETE OPERATION AND MAINTENANCE INSTRUCTIONS ARE AVAILABLE AT www.monoequip.com FILE 7 FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19...
- Page 2 FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19...
-
Page 3: Safety Symbols
The switch disconnector must meet the specification requirements of IEC 60947. The supply to this machine must be protected by a 30mA RCD FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19... - Page 4 Thank you for purchasing the MONO AZTEC FRYER. A combination of clean industrial design and the latest technology. The following information should get your purchase running without any problems If you have a problem with your purchase please contact MONO EQUIPMENT at: MONO EQUIPMENT Queensway Swansea West Industrial Estate Swansea.
-
Page 5: Installation
UP DIRECTION If carrier moves UP, this is CORRECT. If carrier moves DOWN, this is NOT CORRECT. Transpose any two of the phase carrying wires at main isolator feeding the fryer. VERY IMPORTANT FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19... - Page 6 Turn main isolator switch (4) to ‘OFF’ (horizontal position). Remove two screws (5). Remove cover (6). Switch breakers (top right in control box) to on position. Replace cover (6) and screws (5) Switch on main control switch (4) FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19...
-
Page 7: Control Panel
IN THE TOP TANK. POSITION, AS SHOWN DURING TRAINING, THE CARRIER MAY JAM IN POSITION. IF THIS HAPPENS PRESS CARRIER RETURN SWITCH ONCE AND THE CARRIER WILL RETURN TO THE START POSITION. CONTROL PANEL FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19... - Page 8 DO NOT TURN POWER OFF UNTIL FULL FILTER CYCLE HAS FINISHED. DO NOT LEAVE MACHINE WITH ALL THE OIL IN THE BOTTOM TANK, (ALWAYS MAKE SURE THE OIL HAS PUMPED BACK TO THE TOP TANK BEFORE LEAVING THE MACHINE.) FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19...
-
Page 9: Machine Operation
Read off scale (2) on left until required position is found. The positions required will have to be determined and recorded for future reference. (Generally position 1 is for large products and position 4 is for very small or finger doughnuts) FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19... -
Page 10: Cleaning Instructions
Only use hot water to clean filter. Do not use soap or detergent. Do not clean in a dishwasher. Ensure filter is dry and replace on to filter holding bars, ensuring all poppers are done Push lower tank back under machine. Close doors. FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19... - Page 11 If the sediment does build up, a fire could result as the temperature sensors will not be able to function correctly. FILE 7 FG059 Aztec plc Quickstart RevA19 29-01-19...
