INSTALLATION AND OPERATING INSTRUCTIONS
WARNING: California Residents Only. This product can expose you
to chemicals including chromium which is known to the State of
California to cause cancer and birth defects or other reproductive
harm. For more information go to www.P65Warnings.ca.gov.
WARNING: For your safety do not store or use gasoline or other
flammable vapors or liquids in the vicinity of this or any other appliance.
Keep the area free and clear of combustibles. (See ANZI Z83.14B, 1991)
WARNING: Improper installation, operation, service or maintenance can
cause property damage, injury or death. Read and understand these
thoroughly before positioning, installing, maintaining or servicing this
equipment.
APW Wyott
cooking equipment has been engineered to provide you with year-round dependable
®
service when used according to the instructions in this manual and standard commercial kitchen
practices.
This manual includes material related to installation, use , cleaning, and care. Exploded view[s], as well as any
available parts list[s] and wiring diagram[s] pertaining to the unit[s] covered by this manual are also included.
This manual must be read and understood by all persons using or installing this appliance. Contact your APW
Wyott dealer if you have any questions concerning installation, use, or maintenance of this equipment.
DO NOT DISCARD THIS MANUAL.
UTILITY THERMO DRAWER
SPTU
is a registered trademark of APW Wyott®, A Middleby Company.
All rights reserved.
DESIGNED SMART. BUILT SOLID.
2M-8893980 REV B (02-23)
instructions
®
MODEL:
SPTU

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPTU and is the answer not in the manual?

Questions and answers

Related Manuals for APW Wyott SPTU

Summary of Contents for APW Wyott SPTU

  • Page 1 This manual must be read and understood by all persons using or installing this appliance. Contact your APW Wyott dealer if you have any questions concerning installation, use, or maintenance of this equipment. DO NOT DISCARD THIS MANUAL. is a registered trademark of APW Wyott®, A Middleby Company. All rights reserved.
  • Page 2 You may take this unit to the APW Wyott Authorized Service Distributor. List of same is included with each product. If the problem is covered under warranty the unit will be repaired at no cost to you.

  • Page 3: Table Of Contents

    Warranty ....... . 12 APW Wyott takes pride in the design and quality of our products. When used as intended and with proper care and maintenance, you will experience years of reliable operation from this equipment.
  • Page 4 CAUTION: Maintenance & repair should be handled by a factory authorized agent. Before doing any maintenance or repair, contact APW Wyott. NOTICE: Install according to the spacing requirements listed in the installation section of this manual. We strongly recommend having a competent professional install this equipment.

  • Page 5: General Installation Instructions

    Mild cleansers and plastic scouring pads may be used to remove baked-on food and water scale on metal unit. 3. Unplug electrical unit before cleaning or servicing. All service should be performed by an APW Wyott authorized service agency.

  • Page 6: General Troubleshooting

    A current listing of all authorized APW Wyott authorized parts/service distributors is included with this product manual at the time of shipment. In the absence of this list you can call the APW Wyott 24-hour Service Hot Line which gives access to the nearest Authorized APW Wyott parts/service distributor.

  • Page 7: Operation/General Description

    OPERATION / GENERAL DESCRIPTION SPTU operates as a Heat & Hold oven. The product is loaded in the unit by the operator and heated per the instruction below, insuring the food product has reached the appropriate temperature to meet the depth of health guidelines. The operator then places it on the roller grill above. This methodology prevents cold food product that was just placed on the grill from being selected by the customer.
  • Page 8 EXPLODED VIEW – SPTU...
  • Page 9 SPTU SERVICE PARTS LIST Item SPTU-50 SPTU-50N SPTU-30 SPTU-30N Descritpion 25000046 -SAME- -SAME- -SAME- THERMOSTAT BULB BRACKET 25000017 / 25000013 / 25000011 / HEATER, FOIL BLANKET 120V / 220V 25000015 25000018 25000016 25000014 25000012 25000076 - SAME - - SAME - - SAME - BRACKET, T-STAT &...

  • Page 10: Wiring Digram

    WIRING DIAGRAM...
  • Page 11 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or Parts, this information is required. Model Number Serial Number Date Purchased Notes...

  • Page 12: Warranty

    WARRANTY EXCLUSIONS LIMITED EQUIPMENT WARRANTY THE FOLLOWING WILL NOT BE COVERED UNDER WARRANTY. APW (as well as its subsidiaries) warrants to the original purchaser APWs’ sole obligation under this warranty is limited to either repair of new APW's products to be free from defects in material or or replacement parts, subject to the additional limitations workmanship, under normal and proper use and maintenance service as detailed below.
  • Page 13 APW Wyott • www.apwwyott.com/ Printed in the U.S.A. • 2M-8893980 REV B (02-23) Specifications are subject to change without notice. 265 Hobson St. • Smithville, TN 37166 Telephone: (800) 527-2100 is a registered trademark of APW Wyott®, A Middleby Company. All rights reserved.
