- Page 1 GAS CHARBROILER Radiant Models GCB-18S, GCB-24S, GCB-36S, GCB-48S Lava Rock Models GCRB-24S, GCRB-36S, GCRB-48S Installation and Operation Instructions 2M-Z23812 Rev. C (12-21) GCB-24S is a registered trademark of APW Wyott®, A Middleby Company. All rights reserved.
-
Page 2: Safety Symbols
WARNING RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine APW Wyott factory supplied parts relieves the manufacturer of all liability. APW Wyott reserves the right to change specifi cations and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment. - Page 3 104.4 kg 15.5” x 48” x 28.5” 960 sq. in 299 lbs 350 lbs GCB-48 120,000 48cm x 122cm x 72.3cm 6194 sq. cm 135.7 kg 158.9 kg is a registered trademark of APW Wyott®, A Middleby Company. All rights reserved.
-
Page 4: General Installation Data
The APW Wyott series gas charbroiler is equipped for the type of gas indicated on the nameplate mounted on the front panel. All units are shipped from the factory for use with natural gas. The unit can easily be converted for use with propane gas: see propane gas. - Page 5 GAS PIPING Gas piping shall be of such size and so installed as to provide a supply of gas sufficient to meet the full gas input of the appliance. If the appliance is to be connected to existing piping, it shall be checked to determine if it has adequate capacity.
-
Page 6: Pilot Lighting Instructions
PILOT LIGHTING INSTRUCTIONS The charbroiler is equipped with standing pilots, and should be lit immediately after the gas is turned on. 1. Turn off main valve to unit. 2. Turn off all knobs and pilot valves and wait 5 minutes to clear gas. 3. - Page 7 GENERAL OPERATING INSTRUCTIONS WATER PAN / DRIP TRAY Water Pan / Drip Tray The water pan is located at the bottom of the unit, and Fill with water before operating is easily removed fwrom the front of the unit. Water to prevent flare-ups and should be added to the water pan and replaced as catches grease.
- Page 8 MODEL GCB-24S, GCRB-24S SK2970 REV - 12/8/2020...
-
Page 9: Parts List
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. is a registered trademark of APW Wyott®, A Middleby Company. All rights reserved. - Page 10 IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. is a registered trademark of APW Wyott®, A Middleby Company. All rights reserved.
- Page 11 LIMITED EQUIPMENT WARRANTY WARRANTY EXCLUSIONS APW warrants to the original purchaser of new APW's products to be THE FOLLOWING WILL NOT BE COVERED UNDER WARRANTY. free from defects in material or workmanship, under normal and proper APWs’ sole obligation under this warranty is limited to either repair use and maintenance service as specified by APW and upon proper or replacement parts, subject to the additional limitations installation and start-up in accordance with the instructions...
- Page 12 PAGE INTENTIONALLY LEFT BLANK...
-
Page 13: Instructions De Fonctionnement
INSTRUCTIONS DE FONCTIONNEMENT BAC À EAU Le bac à eau est situé au bas de l’appareil et il est facile à enlever par la partie avant de l’appareil. Il faut ajouter de l’eau au bac et la remplacer tel que nécessaire. Le bac à eau aide à prévenir les flambées et attrape la graisse. - Page 14 INSTRUCTIONS POUR ÉTEINDRE LE BARBECUE Pour éteindre les brûleurs, tourner les boutons des brûleurs sur la position de fermeture. IGNITION DU BRÛLEUR ET AJUSTEMENT 1. Allumer des brûleurs tournent le bouton de la valve du brûleur à " SALUT " la place.
-
Page 15: Gaz Propane
NE PAS L’INSTALLER SANS ATTACHER LES PIEDS - NE PAS ENLEVER LES PIEDS. TUYAUTERIE À GAZ La taille de la tuyauterie à gaz et la façon dont elle est installée doivent être telles qu’elle fournisse une MISE EN alimentation suffisante de gaz pour répondre aux exigences d’admission de pleine puissance dans GARDE l’appareil. - Page 16 GARDE Le barbecue de la série APW Wyott est équipé pour le type de gaz indiqué sur la plaque du constructeur montée sur le panneau avant. Tous les appareils sont expédiés de l’usine pour l’utilisation au gaz naturel.
-
Page 17: Entretien Et Réparations
L’utilisation de toute pièce autre que les pièces d’origine STAR dégage le fabricant de toute responsabilité. APW Wyott se réserve le droit de changer les spécifi cations et la conception du produit sans préavis. Ces changements ne donnent pas le droit à... - Page 18 BARBECUE A GAZ Radiant Models GCB-18S, GCB-24S, GCB-36S, GCB-48S Lava Rock Models GCRB-24S, GCRB-36S, GCRB-48S Instructions d’installation et d’opération 2M-Z23812 Rev. C (12-21) CGB-24S est une marque de Registered APW Wyott®, la Compagnie A Middleby. Tous droits réservés.
