Please complete this information and retain this manual for the life of the equipment. For
Warranty Service and/or Parts, this information is required.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
!
cause property damage, injury or death. Read the Installation, Operating and
Maintenance Instructions thoroughly before installing or servicing this equipment.
This equipment has been engineered to provide you with year-round dependable service when used
according to the instructions in this manual and standard commercial kitchen practices.
Phone: +1
Fax:
+1 (307) 637-8071
Toll Free: +1 (800) 752-0863
Website: www.apwwyott.com
E-mail:
info@apwwyott.com
Get user manuals:
See SafeManuals.com
COLDWELLS
INTENDED FOR OTHER THAN HOUSEHOLD USE
RETAIN THIS MANUAL FOR FUTURE REFERENCE
IMPORTANT FOR FUTURE REFERENCE
Model Number
(307) 634-5801
INSTALLATION
AND
OPERATING
INSTRUCTIONS
CW-13
Model:
Serial Number
1
R
Date Purchased
P/N 88041-00 9/05
APW WYOTT
P.O. Box 1829
Cheyenne, WY 82003
!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for APW Wyott COLDWELLS CW-13
Summary of Contents for APW Wyott COLDWELLS CW-13
- Page 1 P/N 88041-00 9/05 Phone: +1 (307) 634-5801 Fax: +1 (307) 637-8071 APW WYOTT Toll Free: +1 (800) 752-0863 Website: www.apwwyott.com P.O. Box 1829 E-mail: info@apwwyott.com Cheyenne, WY 82003 Get user manuals: See SafeManuals.com...
- Page 2 APW Wyott takes pride in the design and quality of our products. When used as intended and with proper care and maintenance, you will experience years of reliable operation from this equipment. To ensure best results, it is important that you read and follow the instructions in this manual carefully.
- Page 3 Install per the spacing requirements listed in the installation section of this manual. We WARNING: strongly recommend having a competent professional install the equipment.A licensed electrician should make the electrical connections and connect power to the unit. Local codes should always be used when connecting these units to electrical power.
- Page 4 SPECIFICATIONS ELECTRICAL MODEL VOLTS PHASE AMPS COMPRESSOR CHARGE CW-13 1/5 HP 5.0 oz. - R134A DIMENSIONS MODEL DIMENSIONS INCHES (mm) RECOMMENDED CUT-OUT CW-13 12-1/4 (311.2) x 17-3/4 (450.9) x 27-1/16 (687.4) 11-1/2 (292.1) x 17 (431.8) INSTALLATION Clean the unit before using. Wipe body and the inside of the unit with a hot, wet cloth to remove any shipping dust or protective oil.
- Page 5 WIRING DIAGRAM - COLDWELL CW-13 Pressure Switch Power Switch Thermoprotector Compressor Start Relay Check data plate for voltage and frequency White Green Connect to Wire Connector Compressor Box 11961-00 (2 ea.) OPERATING INSTRUCTIONS Plug Coldwell in and turn on the power switch. The unit has been calibrated at the factory for 35° F-39° F at sea level.
- Page 6 A current listing of all authorized APW WYOTT authorized parts/service distributors is included with this product manual at the time of shipment. In the absence of this list you can call the APW WYOTT 24 hour Service Hot Line which gives access to the nearest Authorized APW WYOTT parts/service distributor. Call 1-800-733-2203.
- Page 7 PARTS LIST & EXPLODED VIEW COLDWELL CW-13 ITEM DESCRIPTION CW-13, 120V 60Hz CW-13, 220V 50Hz Compressor 1/5 HP 18069-51 18069-22 Condenser 18013-00 18013-00 Fan Blade 12000-00 12000-00 Fan Motor 12002-00 12003-00 Drier 18125-00 18125-00 Thermostat 14894-00 14894-00 Compressor Housing 217708-10 217708-10 Power Switch 13056-10...
- Page 8 APW Wyott's option or its Authorized Service Agency, it will be serviced on site or replaced. From day two through the conclusion of this warranty period, portable units must be taken to or sent prepaid to the APW Wyott Authorized Service Agency for in-warranty repairs.
