  • Page 1 IR Fisheye Network Camera Quick Start Guide V1.0.1...

  • Page 2: Foreword

    Foreword General This manual introduces the functions, installation, and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, WARNING could result in slight or moderate injury.
  • Page 3  If there is any uncertainty or controversy, please refer to our final explanation.

  • Page 4: Important Safeguards And Warnings

    Important Safeguards and Warnings Electrical Safety  All installation and operation shall conform to your local electrical safety codes.  The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1.
  • Page 5  Do not touch the image sensor (CMOS) directly. Dust and dirt can be removed with air blower, or you can wipe the lens gently with soft cloth that is moistened with alcohol.  You can clean the device body with soft dry cloth, and for stubborn stains, use the cloth with mild detergent.

  • Page 6: Table Of Contents

    Table of Contents Foreword ..............................I Important Safeguards and Warnings ....................III 1 Introduction ............................1 General............................1 Device Ports ..........................1 Connecting Alarm Input/output ..................... 2 2 Network Configuration.......................... 4 Initializing Device .......................... 4 Modifying Device IP Address ......................5 Logging in to Web Interface ......................

  • Page 7: Introduction

    Introduction General This series of digital video cameras use internet protocol, and they can send and receive audio and video data through network independently. They are equipped with fisheye lens and advanced algorithm of fisheye image rectification; they support surveillance with no dead zone and panorama image output with multiple image screens, and every screen supports virtual Device Ports Cable type might vary with different models, and the actual product shall prevail.

  • Page 8: Connecting Alarm Input/Output

    Table 1-2 Alarm I/O port information Port Port Name Function ALARM_OUT Outputs alarm signal to alarm device. Alarm I/O ALARM_IN Receives the switch signal of external alarm source. ALARM_GND Ground connection. Connecting Alarm Input/output Alarm input/output is available on select models. Step 1 Connect alarm input device to the alarm input end of the I/O port.
  • Page 9 Figure 1-4 Mode B Step 3 Log in to web interface, and configure alarm input and alarm output in alarm setting. The alarm input on the web interface is corresponding to the alarm input end of the  I/O port. There will be high level and low level alarm signal generated by the alarm input device when alarm occurs, set the input mode to "NO"...

  • Page 10: Network Configuration

    Network Configuration Device initialization and IP address setting can be finished with the "ConfigTool" or on web interface. For more information, see the Web Operation Manual. Device initialization is available on select models, and it is required at first use or after the ...

  • Page 11: Modifying Device Ip Address

    Step 6 Select the devices that need initialization, and then click Initialize. The password setting interface is displayed. See Figure 2-2. Figure 2-2 Password setting Step 7 Set and confirm the password of the devices, then enter a valid email address, and then click Next.

  • Page 12: Logging In To Web Interface

    Figure 2-3 Modify IP Address Step 3 Select Static mode, and then enter start IP, subnet mask, and gateway. IP addresses of multiple devices will be set to the same if you select the Same IP  check box.  If DHCP server is available in the network, devices will automatically obtain IP addresses from DHCP server when you select DHCP.

  • Page 13: Installation

    Installation Packing List The tool required for the installation such as electric drill is not provided in the packing.  The operation manual and related tool information are contained in the disk or the QR code,  and the actual packing shall prevail. Dimensions The following figures are for reference only, and the actual product shall prevail.

  • Page 14: Installing Device

    Installing Device 3.3.1 Installation Type 3.3.2 Installing SD Card (Optional) Disconnect the power before installing or removing the SD card.

  • Page 15: Attaching Device

    Press the WPS button on your router, and then press and hold the WPS button on the  camera for 1-2 s, the camera would be connected to your router within 1 min. Press and hold the WPS button on the camera for at least 10 s during proper operation ...
  • Page 16 Mounting plate Positioning map Locking Mounting Plate The mounting plate is at the "open" state by default, make sure it stays "open" when  installing the camera; and adjust it to the "close" state after installation. When the mounting plate is at the "open" state, you can install, adjust, or remove the ...
  • Page 17 Fixing Device Cable going through the mounting surface...
  • Page 18 Cable going through the side cable tray...
