Quick Start Guide
RemoteLinc ™ 2 - INSTEON
Model: 2444A2WH4

Introduction

Conveniently control your home's INSTEON network with the compact and
versatile RemoteLinc 2 wireless keypad controller.

What's Included

• RemoteLinc 2

Getting Started

Fully charge RemoteLinc 2 prior to programming (or anytime the unit is not
responding) using a Type A to Micro-B USB cable (sold separately). The
red Charging LED will turn off once the battery is fully charged
(approximately one hour). Slide the power switch to the ON position.
Note: RemoteLinc 2 requires an INSTEON dual-band or RF device to
communicate with other devices on your INSTEON network.
RemoteLinc 2 uses a subtle beeper sound to assist setup. It is
recommended that you program the unit in a quiet area.

Add RemoteLinc 2 (Button) as an INSTEON Controller

1) Tap ^ on the RemoteLinc 2 scene button of choice
2) Adjust the responder to the state you want when the scene is activated from RemoteLinc 2
3) Press and hold RemoteLinc 2's Set button until RemoteLinc 2 beeps
RemoteLinc 2's Status LED will begin blinking green
4) Press and hold the responder's Set button until the responder beeps or its LED flashes
RemoteLinc 2 will double-beep and its LED will stop blinking
Responder's LED will stop blinking (it may also double-beep)
5) Confirm that scene addition was successful by tapping on/off on the programmed RemoteLinc 2 button
The responder will toggle between the scene's preset on-level and off
1
If the responder is a multi-scene device such as a KeypadLinc, tap the scene button you wish to control until its LED is in the desired state (on or off)

Using RemoteLinc 2

RemoteLinc 2 contains four on/off button pairs (a-d). Each pair controls its own scene, sending commands to
devices linked specifically to that on/off button pair. Dimmable responders may behave differently, depending on
whether you tap, double-tap or press and hold a button to activate/deactivate a scene. Non-dimming responders
will only turn full-on or full-off, no matter what method you use.
Ramp to preset on-level or
off
The RemoteLinc 2 Status LED will flash green once for each on/brighten command
sent and red once for each off/dim command sent.
Warning: RemoteLinc 2 is permanently sealed. Do not attempt to open case. Doing so will damage the remote
and void the warranty.
Owner's Manual and Tech Support
Owner's Manual and current Quick Start Guide:
Call: INSTEON Support Line at 800-762-7845
2444A2xx4 Rev. 7/16/2012 10:08 AM / See Owner's Manual for Warranty Information, Patented
© Copyright 2012, INSTEON, 16542 Millikan Ave., Irvine, CA 92606, 800-762-7845
®
Wireless Keypad
Tap
Full-on or full-off instantly
http://www.insteon.com/support
Power
Switch
(Left=Off,
Right=On)
Double-tap
Brighten or dim until
released
Status LED
4 Scene Buttons
Right=On/brighten)
Charging LED
(inside case)
Set button
1
Press and hold
(Left=Off/dim,
Micro-USB
Charging
Jack
