Page 5: Table Of Contents
Preface Thank you for purchasing this product. Before using this product, read the following precautions to make sure the product is used correctly and safely. Safety Precautions·························································· ii Labels Attached to the Unit ·········································· ii Measurement Unit for Each Parameter ······················· iv Graphic Symbols ·························································...
Page 6: Safety Precautions
Safety Precautions Read the “Safety Precautions” thoroughly before use to ensure correct and safe use of the product. Make sure to follow the precautions indicated below, as these are important messages related to safety. Failure to follow this message may cause immediate threat of death or serious D A N G E R injury, or complete failure of the equipment.
Page 7 DS-8500 System Main Unit (DSC-8500 Series)
Page 8: Measurement Unit For Each Parameter
Measurement Unit for Each Parameter The measurement units for this equipment are as follows. Detail Parameter Display Unit Default (beats per minute) Heart Rate / Pulse Rate Invasive Blood Pressure PR_IBP PR_SpO ST Level mm, mv beat/minute Impedance Respiration RR_IMP (breaths per minute) Respiration Rate...
Page 9 Detail Parameter Display Unit Default Mixed Venous Oxygen Saturation Central Venous Oxygen ScvO Saturation Arterial Oxygen Saturation Oxygen Uptake Index Oxygen Transport mL/minute Oxygen Consumption mL/minute Stroke Volume Stroke Volume SV_STAT (STAT Mode) Stroke Volume Index mL/m Stroke Volume Index SVI_STAT mL/m (STAT Mode)
Page 10: Graphic Symbols
Graphic Symbols Refer to the following for the meaning of the symbols indicated on the equipment. DS-8500 System Main Unit Symbol Description Caution; refer to accompanying documents Indicates the need to refer to related accompanying documents before operation. Potential Equalization Terminal Indicates the terminal to equalize the potential difference when interconnecting the devices.
Page 11: Precautions For Safe Operation Of Medical Electrical
Precautions for Safe Operation of Medical Electrical Equipment Read the following precautions thoroughly to correctly operate the device. Users should have a thorough knowledge of the operation before using this system. Pay attention to the following when installing and storing the equipment. Do not install or store in an area where the equipment will be subject to splashing water.
Page 12: Precautions For Safe Operation Of Medical Telemetry
When interference or breakdown occurs in telemetry communication, the user is required to inform the zone manager and the overall manager of the problems. The zone manager and overall manager are to deal with the problem properly and/or contact their nearest Fukuda Denshi representative for service. viii...
Page 13: Precautions About The Maintenance
Maintenance, Modifications, and Repairs Fukuda Denshi is liable for the safety, reliability, and performance of its equipment only if; Maintenance, modifications, and repairs are carried out by authorized personnel. Components are used in accordance with Fukuda Denshi operating instructions.
Page 14: Precautions About Pacemaker
W A R N I N G For more details, contact FUKUDA DENSHI personnel, your institution’s professionals, or your pacemaker distributors. Reference “Minute Ventilation Rate-Adaptive Pacemakers”...
Page 15: Electrosurgery Safety
Electrosurgery Safety The monitoring system contains protection against interference generated by electrosurgical instruments. However, operating conditions, surgery site with respect to the location of ECG electrodes, or the type of instrument used, may cause noise on the ECG. The noise is generated at the tip of the electrical knife and is difficult to completely eliminate because of the frequency components of the ECG.
Page 16: Peripheral Devices
For safety and good performance of this equipment, connection of other manufacturers’ equipment to the monitor is not authorized, unless the connection is explicitly approved by Fukuda Denshi. It is the user’s responsibility to contact Fukuda Denshi to determine the compatibility and warranty status of any connection made to another manufacturer’s equipment.
Page 17: Precautions About The Ds-8500 System
D A N G E R Danger such as electric shock may result to the patient and operator. Do not connect a unit or cable not authorized by Fukuda Denshi to any I/O connector. If done so by mistake, the DS-8500 system cannot deliver its maximum performance and the connected units may be damaged, resulting in a safety hazard.
Page 18 (x4). Otherwise, the equipment may fall from the trolley, resulting in injury to the operator or damage to the equipment. Use the trolley only with the equipment specified by Fukuda Denshi. Otherwise, the monitor and trolley may fall down, resulting in injury or damage to the monitor.
Page 19 Systems Use only the accessories specified for this device. Otherwise, proper function cannot be executed. Do not use the touch panel with the film attached. Malfunction of the touch panel or damage may result. Due to its material characteristic, the touch panel expands/contracts depending on the temperature/humidity.
Page 20 When continuously detecting AC noise artifact as pacemaker pulses, QRS detection stops and heart rate is extremely degraded. Also arrhythmia cannot be detected. Respiration Monitoring When a defibrillator is used during respiration monitoring, a large offset voltage will be placed on the ECG electrodes, which may cause interruption of monitoring for a few seconds.
Page 21 Each time the blood pressure transducer or tubing is replaced, the zero balance procedure is required to ensure accurate measurements. “Perform zero balance” message will not be displayed unless the three-way valves of all pressure transducers are opened to air. If the status is not displayed, or if “Open stop cock to air”...
Page 22 Dispose of sampline lines according to standard operating procedures or local regulations for the disposal of contaminated medical waste. Before use, carefully read the Microstream EtCO sampling lines ® Directions for Use. Only use Microstream EtCO sampline lines to ensure the monitor ®...
Page 23 Make sure to firmly connect the calibration gas cylinder and the regulator. Make sure to connect the regulator and the regulator tube so that the calibration gas will not leak. To prevent the gas cylinder to become empty, make sure to disconnect the regulator when not using it.
Page 24: Precautions About The Wired Network System
Precautions about the Wired Network System (DS-LAN ΙΙ/DS-LAN ΙΙΙ) W A R N I N G Do not connect unspecified device to a wired network. If performing wired network transmission, configure the display so that the numeric data corresponded to the waveform is displayed. If not, the displayed waveform or numeric data may not be transmitted.
Page 25: Precautions About The Wireless Network System
Precautions about the Wireless Network System When monitoring a patient using wireless telemetry, make sure the patient D A N G E R data is properly received at the central monitor. Pay special attention when the channel ID at the bedside monitor is changed. A password can be set to access the channel ID setup menu to allow only the telemetry channel administrator to change the channel ID.
Page 26: Precautions For Use Of Bidirectional Wireless
TCON and to inform the Overall Manager of the problem. The Overall Manager is to deal with the C A U T I O N problem properly and/or contact the nearest Fukuda Denshi representative for service. Precautions for Use The Bidirectional Wireless Communications Module (TCON) uses radio waves to transmit data.
Page 27: Precautions About The Ventilator Monitoring
When the TCON device is installed or moved to a location that is outside the radio communication range. If a nearby different group is set with a TCON channel frequency that is too close to the channel frequency set for the current TCON group. Follow the instructions from the Overall Manager for the wireless channel when setting the TCON and channel IDs to prevent interference within the same institution.
Page 28: Precautions For Use Of Spo 2 Sensor
D A N G E R Fukuda Denshi. If any other sensor/relay cable is used, a high temperature rise of the sensor may place the patient in danger of burns. Precautions for Use of NIBP Cuff The NIBP cuff used in this product contains natural rubber latex (excluding latex-free cuff).
Page 29: Precautions About Transportation
If incorrect time is displayed when turning on the power, a low battery may be the cause. In such case, replace the battery. In such case, contact Fukuda Denshi representative for replacing the battery. C A U T I O N...
Page 30: Electromagnetic Compatibility
Electromagnetic Compatibility The performance of this device under electromagnetic environment complies with IEC60601-1-2 (2007). Precautions for Safe Operation under Electromagnetic Influence If any sorts of electromagnetic wave, magnetic field, or static electricity exist around the device, noise interference or malfunction of the device may occur.
Page 31: Compliance To The Electromagnetic Emissions
Compliance to the Electromagnetic Emissions The DS-8500 system is intended for use in the electromagnetic environment specified below. Emissions Test Compliance Electromagnetic Environment - Guidance The DS-8500 System uses RF energy only for its internal RF Emissions function. Therefore, its RF emissions are very low and Group 1 are not likely to cause any interference in nearby CISPR 11/EN55011...
Page 32: Compliance To The Electromagnetic Immunity (1)
Compliance to the Electromagnetic Immunity (2) The DS-8500 system is intended for use in the electromagnetic environment specified below. It should be assured that the DS-8500 system is used in such an environment. IEC60601-1-2 Compliance Electromagnetic Environment - Immunity Test Test Level Level Guidance...
Page 33: Recommended Separation Distances Between Portable And Mobile Rf Communications Equipment And The Ds-8500 System
Recommended Separation Distances between Portable and Mobile RF Communications Equipment and the DS-8500 System The DS-8500 system is intended for use in an environment in which radiated RF disturbances are controlled. The electromagnetic interference can be prevented by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the DS-8500 system as recommended below, according to the maximum output power of the communications equipment.
Page 34 Blank Page...
Page 35 Contents Preface Chapter 1 General Description This chapter describes the outline of this equipment. This chapter describes electrical and mechanical Chapter 2 Specification specification. Chapter 3 This chapter explains the cable connection of this equipment. Name of Parts and Their Functions Chapter 4 Operational Description This chapter explains board circuit of this unit.
Page 36 Preface Chapter 1 General Description Safety Precautions ······················································ ii General Description ·····················································1-2 Labels Attached to the Unit ······································· ii Features ·································································1-5 Measurement Unit for Each Parameter ···················· iv Graphic Symbols ······················································ vi Precautions for Safe Operation of Medical Electrical Equipment ······························································· vii Chapter 2 Specification Precautions for Safe Operation of Medical Telemetry (When using HLX-501) ··························...
Page 37: Precautions For Safe Operation Of Medical Electrical
OAO-44A Stand Part Assembly (2) ··············· 7-3 Precautions about the Wireless Network System ··xxiv DSC-8510 CPU Block Assembly··················· 7-4 Precautions for Use of Bidirectional Wireless DSC-8510 Main Unit Rear Chassis Part Communications (TCON) ······································ xxv Assembly······················································· 7-5 Precautions about the Ventilator Monitoring·········xxvii DSC-8510 Main block Assembly (1)··············...
Page 38 Blank Page xxxiv...
Page 39 Chapter 1 General Description This chapter explains the general description of this equipment. General Description ····················································· 1-2 Features ··································································· 1-5 －...
Page 40: Chapter 1 General Description
Network connection with the central monitor using the Ethernet LAN and telemetry transmitter module (HLX-501) or HTC-701/HTC-702 Bidirectional Wireless Communications Module is also possible. <Composition of DSC-8510 (LC-8019T), HS-8312, IB-8004 and expansion modules> 【Lineup of Main Unit】 External Monitor Extended Display...
Page 41 【Lineup of Display Unit】 Circular Polarizing Display Size Model Type Filter LC-8015T 15 inch LC-8015TC 15 inch LC-8019T 19 inch LC-8019TC 19 inch 【Lineup of Super Unit】 Fixed Parameter Multiparameter Measure Model Type Unit ment HS-8312N NELLCOR 3 ports (Max.12-Leads) Temperature x6 (Max.) Respiration x1 BP x6 (Max.)
Page 42 【Lineup of Expansion Module】 Model Module Parameter Multimodule IBP, TEMP, CO HM-800 Serial communication 2ch, Multimodule HP-800 Analog communication 1ch SpCO, SpMet, PR HG-810 Module M ® (Masimo , PR HG-820 Module N (Nellcor 【Lineup of GAS Module】 Module Parameter Model measurement by Mainstream method with a Gas Unit I/F...
Page 43: Features
Features This equipment is a detachable type patient monitor which consists of a main unit, touch panel display unit and Super unit. The display unit (LC-8019T/LC-8019TC) can display a maximum of 28 waveforms. Also, various displays such as enlarged numeric data, trend, or ventilator can be selected according to monitoring conditions.
Page 44 concentration, anesthetic By connecting the optional Multigas Unit (MGU-800/810 series), CO gas concentration, O measurement, N O concentration can be measured. The following anesthetic gas can be measured. ・Halothane ・Isoflurane ・Sevoflurane ・Enflurane ・Desflurane By connecting the Gas Unit I/F (HPD-800) or CO Gas Unit (HCP-800) to the AUX connector on the HS-8000 series Super Unit, CO concentration can be measured.
Page 45: Specification / Performance
Chapter 2 Specification Specification / Performance ······································2-2 Specification (DSC-8500 Main Unit) ·······················2-2 Performance (DS-8500 system) ·····························2-4 －...
Page 46 Specification / Performance This section states the specification and performance of this equipment. Specification (DSC-8500 Main Unit) Size 265(W) × 263(H) x 117(D) mm (not including the protrusion) Weight 5.5kg (not including the accessory) Environmental Conditions : 10 to 40 ° C Operating Temperature Operating Humidity : 30 to 85% (non-condensing)
Page 47 Usable Life 6 years ： According to self-certification Refer to “12. Periodic Check” for components requiring periodic replacement. －...
Page 48: Performance (Ds-8500 System)
Performance (DS-8500 system) Display Device : 19 inch TFT ColorLCD/15 inch TFT ColorLCD Control : Touch Screen Type Waveform Trace : Stationary Trace Sweep Speed : ECG / SpO / BP (6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s) RESP / CO AG (6.25mm/s, 12.5mm/s, 25mm/s) Measurement Parameter ：ECG, RESP, TEMP, SpO...
Page 49 : ± 3bpm for 20 to 250bpm PR Accuracy Measurement Response : 6 to 7 sec. (averaging duration) Time ® Masimo Unit Measurement Method : 2 Wavelength Pulse Wave Method : MASIMO LNOP/LNCS Sensor Wavelength: Approx. 660nm (red light) Approx. 890nm (infrared light) Output: 15mW or below : MASIMO Rainbow Sensor Wavelength: 8 different wavelenghs are used within the range of...
Page 50 Safety Mechanism : Adult: 300mmHg or above Child: 210mmHg or above Neonate: 150mmHg or above (Carbon Dioxide Concentration) ® RESPIRONICS Capnostat 5 (Gas Unit I/F and Mainstream Module) Measurement Method: Infra-Red Solid-State Method, Mainstream Method Measurement Range: 0 to 150mmHg Measurement Accuracy: 0 to 40mmHg: ±...
Page 51 20-100[vol%]:±3[vol%] MGU-801P 0-25[vol%]:±1[vol%] 25-80[vol%]:±2[vol%] 80-100[vol%]:±3[vol%] Volatile Anesthetic Halothane Enflurane Isoflurane 0-1[vol%]：±0.15[vol%] 1-5[vol%]：±0.2[vol%] Sevoflurane 0-1[vol%]：±0.15[vol%] 1-5[vol%]：±0.2[vol%] 5-8[vol%]：±0.4[vol%] Desflurane 0-1[vol%]: ±0.15% of Reading* 1-5[vol%]: ±0.2% of Reading* 5-10[vol%]: ±0.4% of Reading* 10-15[vol%]: ±0.6% of Reading* 15-18[vol%]: ±1.0% of Reading* >18[vol%]: Unspecified Respiration Rate ±1bpm when below 60bpm Recording (Recorder Unit) Recording Speed...
Page 52 Blank Page －...
Page 53 Chapter 3 Names of Parts and Their Functions DSC-8500 series Main Unit ·········································· 3-2 【Front Side】 ···················································· 3-2 【Rear Side】····················································· 3-2 【Right Side】 ···················································· 3-3 【Left Side】 ······················································ 3-3 External Appearance ··················································· 3-4 DSC-8500 series Main Unit + Display Unit ··············· 3-4 －...
Page 54: Dsc-8500 Series Main Unit
DSC-8500 series Main Unit 【Front Side】 Display Unit Connector Connects the display unit. Display Unit Attaching Position Attach the display unit (LC-8019T/LC-8019TC/LC-8015) 【Rear Side】 HTC Fixing Position HLX Fixing Position Fixes the HTC-701 Bidirectional Fixes the HLX-501Telemetry Wireless Communications Module. Transmitter Module.
Page 55: Right Side
*LAN Connector, I/O Connector (ALARM), Serial Connector (COM A/B), and Extended Display Connector A/B can be added using CC-82/CC-83. Do not connect a unit or cable not authorized by Fukuda Denshi to any I/O connector. If done so by mistake, the DS-8500 system cannot deliver its...
Page 56: External Appearance
External Appearance DSC-8500 series Main Unit + Display Unit LC-8000 Series (19 inch/15 inch) Weight: 19 inch Approx. 14.5kg 15 inch Approx. 12.5kg －...
Page 57 Chapter 4 Operational Description DS-8500 Main Unit······················································4-2 Main CPU Board (PCB-7303) Circuit Explanation ··4-2 Mother board (PCB-7304) circuit explanation·······4-22 CF card board (PCB-7305) circuit explanation ·····4-23 Connector board (PCB-7306) circuit explanation ·4-23 Extended board (PCB-7307) circuit explanation···4-25 HTC connecting board (PCB-7351) cirguit explanation ···························································4-28 －...
Page 58: Ds-8500 Main Unit
DS-8500 Main Unit This section explains the block diagram of the DS-8500 and its function. Main CPU Board (PCB-7303) Circuit Explanation The Main CPU Board controls, displays, and records the monitor. The input signal operation of the touch panel, remote control, etc are processed by the CPU and then the display of the monitor or each measurement condition will change.
Page 59 RTC (Real Time Clock) RTC (Real Time Clock) is IC exclusively for timing. As with SRAM, RTC operates with the power supply from the long-term backup battery (lithium battery) while the power is turned OFF (while the power is ON, RTC operates with the external power supply). The main CPU obtains the time/date from the RTC during start-up, and then the main CPU conducts the timing by itself.
Page 60 Secondary battery/Charge control The nickel hydride rechargeable battery is used as a short-term backup battery. The rapid charge and trickle charge is switched. －...
Page 61 ●External Connection CF-CARD Connector (CN1801) Signal Signal Description Description Type Type Signal GND /CD1 Card Detect 1 Card Data D3 Card Data D11 Card Data D4 Card Data D12 Card Data D5 Card Data D13 Card Data D6 Card Data D14 Card Data D7 Card Data D15 Chip Enable 1...
Page 62 DS-LAN II Connector (CN1702) Signal Type Description Signal Level 10BASE-T / Transmit data + 100BASE-TX 10BASE-T / Transmit data - 100BASE-TX 10BASE-T / Receive data + 100BASE-TX No connection － No connection － 10BASE-T / Receive data - 100BASE-TX RESERVED Reserved －...
Page 63 I/O Connector (CN502) Signal Type Description Signal Level +5V Power － Differential signal- － Differential signal+ －－ UNIT-LINK Connector (CN2101) Signal Type Description Signal Level TX1+ Transmit data 1+ RS-485 RX1+ Receive data 1+ RS-485 TX2+ Transmit data 2+ RS-485 RX2+ Receive data 2+...
Page 64 Display Unit Conenctor (CN1201) Signal Type Description Signal Level GND_P Power Supply GND Odd number differential pixel DA0- LVDS data - Odd number differential pixel DA0+ LVDS data + GND_L Odd number differential pixel DA1- LVDS data - Odd number differential pixel DA1+ LVDS data +...
Page 65 Even number differential pixel DB0+ LVDS data + GND_L Even number differential pixel DB1- LVDS data - Even number differential pixel DB1+ LVDS data + Power Supply +18V Even number differential pixel DB2- LVDS data - Even number differential pixel DB2+ LVDS data +...
Page 66 MODULE LAN Connector (CN1701) Signal Type Description Signal Level M-LAN transmit data + 100BASE-TX M-LAN transmit data - 100BASE-TX M-LAN receive data + 100BASE-TX M-LAN receive data - 100BASE-TX Power supply for module LAN becomes Power supply control for possible when both /MLAN_POWEREN_A module LAN /MLAN_POWEREN_B...
Page 67 ●Internal connector CPU main power supply connector (CN1) Description Signal Level Signal Type Power input +18V Power input +18V Temperature sensor connector in housing (CN201) Unused Description Signal Level Signal Type Applied voltage temperature sensor Output current TMP2 temperature sensor *This connector is not used for DSC-8500.
Page 68 CF card expansion connector (CN1802) Signal Type Description Signal Level BF0_A[1] Address [1] BF0_A[3] Address [3] BF0_A[5] Address [5] BF0_A[7] Address [7] BF0_A[9] Address [9] BF0_A[11] Address [11] BF0_A[13] Address [13] BF0_A[15] Address [15] BF0_A[17] Address [17] BF0_A[19] Address [19] BF0_A[21] Address [21] BF0_A[23]...
Page 69 (Continued) Signal Type Description Signal Level BF0_A[0] Address [0] BF0_A[2] Address [2] BF0_A[4] Address [4] BF0_A[6] Address [6] BF0_A[8] Address [8] BF0_A[10] Address [10] BF0_A[12] Address [12] BF0_A[14] Address [14] BF0_A[16] Address [16] BF0_A[18] Address [18] BF0_A[20] Address [20] BF0_A[22] Address [22] BF0_D[0] Data [0]...
Page 70 Connector board connector (CN1901) Signal Type Description Signal Level Isolation +5V power Isolation +5V power Isolation +5V power Isolation +5V power ALARM_OUT1 Alarm 1 output ALARM_OUT2+ Alarm 2 output + ALARM_OUT2- Alarm 2 output - ALM_COM_TX Status II serial transmit data RS-232C output ALM_COM_RX...
Page 71 Speaker connector (CN2001) Unused Description Signal Level Signal Type Speaker output Speaker output *This connector is not used for DSC-8500. Jig board connector (CN503) Description Signal Level Signal Type －－－－ *Due to factory adjustment, no description. CPLD JTAG connector (CN801) Description Signal Level Signal Type...
Page 72 Mother board connector Mother board connector A (CN2201) Signal Type Remarks Description GND_D Digital GND EX_A[1] Address [1] EX_A[3] Address [3] EX_A[5] Address [5] EX_A[7] Address [7] Bus buffer output (PU:3.3V_AL) EX_A[9] Address [9] EX_A[11] Address [11] EX_A[13] Address [13] EX_A[15] Address [15] GND_D...
Page 73 (Continued) Signal Type Remarks Description GND_D Digital GND EX_A[0] Address [0] EX_A[2] Address [2] EX_A[4] Address [4] EX_A[6] Address [6] EX_A[8] Address [8] EX_A[10] Address [10] Bus buffer output EX_A[12] Address [12] (PU:3.3V_AL) EX_A[14] Address [14] EX_A[16] Address [16] EX_A[18] Address [18] EX_A[20] Address [20]...
Page 74 Mother board connector B (CN2202) Signal Type Remarks Description Digital GND GND_D Auxiliary address [1] LCDC0_AUX_A[1] Auxiliary address [3] LCDC0_AUX_A[3] Auxiliary address [5] LCDC0_AUX_A[5] Auxiliary address [7] LCDC0_AUX_A[7] LCDC input (PU:3.3V_AL) Auxiliary address [9] LCDC0_AUX_A[9] Auxiliary address [11] LCDC0_AUX_A[11] Auxiliary address [13] LCDC0_AUX_A[13] Auxiliary address [15] LCDC0_AUX_A[15]...
Page 75 (Continued) Signal Type Remarks Description Digital GND GND_D Auxiliary address [0] LCDC0_AUX_A[0] Auxiliary address [2] LCDC0_AUX_A[2] Auxiliary address [4] LCDC0_AUX_A[4] Auxiliary address [6] LCDC0_AUX_A[6] Auxiliary address [8] LCDC0_AUX_A[8] Auxiliary address [10] LCDC0_AUX_A[10] LCDC input Auxiliary address [12] LCDC0_AUX_A[12] (PU:3.3V_AL) Auxiliary address [14] LCDC0_AUX_A[14] Auxiliary address [16] LCDC0_AUX_A[16]...
Page 76 Mother board connector C (CN2203 Signal Type Remarks Description 12V_AL 12V_AL 12V power 12V_AL 12V_AL 12V_AL GND_D Digital GND IIC_SCL1 Extended board communication (I CPU output IIC_SDA1 Extended board communication (I CPU output GND_D Digital GND 3.3V_AL 3.3V power Main board FPGA configuration control /CFG_CONFIG0 CPU output (PU:3.3_AL) output...
Page 77 (Continued) Signal Type Remarks Description GND level output for extended board /PRSNT1 Connect to GND detection 12V_AL 12V_AL 12V power 12V_AL 12V_AL GND_D Digital GND PCIE_TCK JTAG clock for extended board Unused PCIE_TDI JTAG data input for extended board Unused PCIE_TDO JTAG data output for extended board Unused...
Page 78 Mother board (PCB-7304) circuit explanation The mother board is used to relay the main CPU board (PCB-7303) to the extended board (PCB-7307), HTC connecting board (PCB-7351), and speaker. And, the FAN voltage regulator controlled by the main CPU board and the RS-232 transceiver for the serial connector (COM5) mounted on the HTC connecting board are mounted.
Page 79 CF card board (PCB-7305) circuit explanation The CF card board is connected to the main CPU board, and the CF card slot 2 is added. Connector board (PCB-7306) circuit explanation The board is equipped with the serial connector and status connector which are installed on the side of DSC-8500 main unit and connected to the main CPU board in cable connection.
Page 80 COM1, COM2, COM3, and COM4 connectors (RS-232C I/O signal) (CN3, 4, 5, and 6) Pin3 Pin1 Pin6 Pin4 Pin7 Pin2 Pin8 Pin5 Signal Type Description Signal Level RESET Port Reset TTL Hi Level Reset No Connection COM1 ―― No Connection COM2 ――...
Page 81 Extended board (PCB-7307) circuit explanation The extended board provides up to two types of extended displays and touch panel interface for each display. Additionally, the alarm I/O connector and LAN connector (TCP/IP) are mounted. *This board is also supplied as optional CC-82/CC-83. Main CPU board Power supply inside the board...
Page 82 ●External connector LAN connector (CN6) Signal Type Description Signal Level Transmit data + 10BASE-T / 100BASE-TX Transmit data - 10BASE-T / 100BASE-TX Receive data + 10BASE-T / 100BASE-TX RESERVED Reserved RESERVED Reserved 10BASE-T / Receive data - 100BASE-TX RESERVED Reserved RESERVED Reserved I/O connector (Alarm I/O signal) (CN11)
Page 83 COM A/B connector (RS-232C I/O signal) (CN7, 8) Pin3 Pin1 Pin6 Pin4 Pin7 Pin2 Pin8 Pin5 Signal Type Description Signal Level RESET Port Reset TTL Hi Level Reset No Connection ―― Serial transmit data output RS232C Signal GND Serial receive data input RS232C ＋5V power (150mA) No Connection...
Page 84 HTC connecting board (PCB-7351) circuit explanation The connector for the serial communication (non-insulated) and the external connector (non-insulated) as a future function are mounted on the HTC connecting board. Also, the connector for the short-term backup battery is mounted. ● External connector COM5 connector (RS-232C I/O signal) (CN2) Pin3 Pin1...
Page 85 Power supply unit (FDK-X205: SKYNET) Power supply unit is the AC-DC universal power supply and its rated output is 18V / 11.1A single output. When the AC power decreases, detection signal (AC_FAIL) can be outputted before the output voltage decreases. Speaker Speaker, which is antimagnetic and rated 8Ω, 4W, outputs the pulse tone and alarm sound.
Page 86 Blank Page －...
Page 87 Chapter 5 Wiring Diagram Main Unit DSC-8500 ···················································5-2 －...
Page 88 Main Unit DSC-8500 This section explains the block diagram of DSC-8500 and its function. Main Block ⑨ Battery CF Card Board Connector PCB-7305 Board PCB-7306 ⑧ Main CPU Board PCB-7303 ② ③ Mother Board PCB-7304 Power Supply Unit FDK-205X POWER ④...
Page 89 CAUTION To repair a connector or cable, replace the entire board or contact your local Fukuda Denchi factory for service. Parts may be damaged when reparing/detaching connectors on the board as they are very small and pin-pitch is very narrow. List of connection cables Cable Remarks...
Page 90 Blank Page －...
Page 91 Chapter 6 Spare Parts List DSC-8500 Main Unit Block Spare Parts·······················6-2 Extended Board CC-82 Spare Parts ····························6-5 Extended Board CC-83 Spare Parts ····························6-5 Periodic Replacement Parts·········································6-5 －...
Page 92 DSC-8500 Main Unit Block Spare Parts The spare parts of the main unit of DSC-8500 block are as follows: Item Code Item Name Model Name Note 9F0101100 Main CPU board PCB-7303 SAS 9F0101110 Mother board PCB-7304 SAS 9F0101120 CF card board PCB-7305SAS 9F0101130 Connector board...
Page 93 The assembly mechanism parts of the DS-8500 Main Unit are as follows: Item Code Item Name Model Name Note 9H010293A Main Unit front case SU 5H0107040 Main Unit rear case SU 9G0106450 Connector Case(EXP) U 9H0102960 Fin Cover SU 5H0107060 Battery Cover SU 6C0115950 Extended board cover (blank)
Page 94 The spare parts labels of the DSC-8500 are as follows: Item Code Item Name Model Name Note 5H0109150 Instruction label battery (EXP) 5H0109160 Instruction label caution(EXP) 5H0106990 Functional ground label 6C0118520 Blank label 5G0008420 Caution mark label 5H0056010 Internal earth mark label 5G0022370 Instruction label LED 5H0100620...
Page 95 Extended Board CC-82 Spare Parts The spare parts for extended board CC-82 of DSC-8520 are as follows: Item Code Item Name Model Name Note 9F0102300 Extended board PCB-7307 SAS CC-82 See Diagram (Page 7-8) 5H0105290 Extended board cover (82) SU See Diagram (Page 7-8) 6C0116910 Fixing plate for extended board (82)
Page 96 Blank Page －...
Page 97 OAO-44A Stand Part Assembly (2) ··············· 7-3 DSC-8510 CPU Block Assembly··················· 7-4 DSC-8510 Main Unit Rear Chassis Part Assembly······················································· 7-5 DSC-8510 Main block Assembly (1) ············· 7-6 DSC-8510 Main block Assembly (2) ············· 7-7 CC-82 Final Assembly··································· 7-8 CC-83 Final Assembly··································· 7-9 *For display units, refer to the LC-8015T/8015TC/8019T/8019TC Service Manual.
Page 98: Oao-44A Stand Part Assembly (1)
OAO-44A Stand Part Assembly (1) －...
Page 99: Oao-44A Stand Part Assembly (2)
OAO-44A Stand Part Assembly (2) －...
Page 100: Dsc-8510 Cpu Block Assembly
DSC-8510 CPU Block Assembly －...
Page 101 DSC-8510 Main Unit Rear Chassis Part Assembly －...
Page 102: Dsc-8510 Main Block Assembly (1)
DSC-8510 Main block Assembly (1) －...
Page 103 DSC-8510 Main block Assembly (2) －...
Page 104: Final Assembly
CC-82 Final Assembly －...
Page 105 CC-83 Final Assembly －...
Page 106 Blank Page －...
Page 107 Chapter 8 Software Upgrade Procedure Software Upgrade ························································ 8-2 Software Version·························································· 8-3 －...
Page 108 Software Upgrade This section explains how to perform the upgrade. Software upgrading is performed using the CF Card for Data Transfer. Copy the following software file to the CF Card. ds85inst.bin SUB_DS85.bin ds85prog.bin ds85csum.txt Insert the CF Card into the CF Card Slot1. Open the CF Card Slot cover on the side of the main unit, and insert the CF Card into the CF Card Slot1.
Page 109 Software Version After the software upgrade is complete, check the software version on the main unit. Press the Menu → Maintenance → Program Version keys. The software version of the DSC-8500 will be displayed. Check if the installed version is correct. －...
Page 110 Blank Page －...
Page 111 Chapter 9 Caution Label Caution Label ............9-2 DSC-8500 Series........... 9-2 －...
Page 112 Caution Label DSC-8500 Series DS-8500 System Main Unit (DSC-8500 Series) －...
Page 113 Chapter 10 Troubleshooting Backup ·································································10-2 Alarm Sound·························································10-2 Touch Panel ·························································10-3 Wired Network (DS-LAN ΙΙ/ΙΙΙ) ·····························10-4 Telemetry ·····························································10-5 TCON ···································································10-6 Remote Control Unit ·············································10-6 General·································································10-7 Ventilator ······························································10-9 －...
Page 114: Backup
Backup The recall, trend, OCRG, and ST data in the Data Review disappear when the power is turned OFF. Cause 1 ： The power has been ON only for a short time. Solution ： If the power has been turned ON for 30 minutes or more, backup for 5 minutes is available.
Page 115: Touch Panel
Touch Panel The touch panel keys are out of alignment. Cause ： The keys may have shifted due to change over time. Solution ： Calibration is required. The touch panel does not properly function. Cause ： Due to scratches on the touch panel surface or foreign substances getting into the touch panel attachment, the correct key area cannot be detected.
Page 116 Wired Network (DS-LAN ΙΙ/ΙΙΙ) The ECG waveform is not displayed on the central monitor although other waveforms are displayed. Cause ： BP is selected for ”HR/PR Alarm Source” in the ECG configuration menu. Or, Auto is selected and BP has become the HR/PR source due to reason such as lead-off condition.
Page 117: Telemetry
Telemetry There is no reception at the telemetry center. Cause ： The channel ID or group ID does not correspond with the telemetry receiver. Solution ： Set the correct channel ID and group ID. The impedance respiration waveform cannot be received at the telemetry center. Cause 1 ：...
Page 118: Tcon
TCON Cannot communicate with the central monitor. The "Chk TCON Reception” message is displayed. Cause 1 ：The location is too far from the central monitor. Solution ：Readjust the location so as not to be too far from the central monitor. Cause 2 ：The setup is not correct.
Page 119: General
General Nothing is displayed but the main power indicator is lighted. Cause ：A system error has occurred. Solution ：Turn off the power, unplug the power cable, and contact our service representative. The data is initialized each time the power is turned ON. Cause 1 ：The rotary switch is not set to “0 (zero)”.
Page 120 The clock shows incorrect time when used on a wired network (DS-LANΙΙ). Cause ：The clock of the network administrator (central monitor with central ID: 001) is not correct. Solution ：When using a wired network, the clock of all connected monitors will synchronize with that of the network administrator.
Page 121 Ventilator The “Vent. Disable” message is displayed. Cause ：One of the following situation is observed. ・Waiting to communicate with ventilator. ・Waiting to communicate with ventilator after the power of the DS-8500 system is turned ON. ・”Vent. Invalid” is displayed for the connection status message and OFF is selected on the ventilator display.
Page 122 Blank Page －...
Page 123 Chapter 11 Maintenance DIP Switch / Rotary Switch Setup···························11-2 DIP Switch Setup··················································11-2 Rotary Switch Setup ·············································11-2 Test Menu ·································································11-4 To Display the Test Menu·····································11-4 Test Menu Items···················································11-6 Details of the Test Menu·······································11-9 ●MAINTENANCE(1/2)···································11-9 ●MAINTENANCE(2/2)·································11-10 ●VIDEO I/F··················································11-11 ●TOUCH PANEL·········································11-12 ●Touch Panel Adjustment ···························11-12 ●NIBP Test··················································11-13 ●EEPROM···················································11-14 ●RTC Setup ················································11-15...
Page 124: Dip Switch / Rotary Switch Setup
DIP Switch / Rotary Switch Setup This section explains the settings of the DIP switch and rotary switch. DIP Switch Setup The DIP switch is located under the maintenance cover at the side of the monitor. SW No. Default Description (When ON) Not used.
Page 125 0：Normally, set the rotary switch to “0”. 2：To start the demo, press the demo start key on the test menu. To enter the test menu, the password, “11111111” is required. 7：This mode will be set when adjusting analog for factory shipment, adjusting analog after replacing the board at service division, or using the function for development evaluation.
Page 126: Test Menu
Test Menu This section explains the test menu of this unit. To Display the Test Menu <To display the “Maintenance" screen> Menu → Maintenance → Test Menu → (Password) For the password request, enter “11111111”. The display will differ according to the rotary SW setup.
Page 127 Rotary SW 7 N O T E The Test Menu screen may differ according to the software version. －...
Page 128: Test Menu Items
Test Menu Items MAINTENANCE : The hardware information of the equipment can be checked on this display. For details, refer to the section on “Maintenance”. VIDEO I/F : Displays various patterns of test screen to check the LCD operation. For details, refer to the section on “Video I/F”. TOUCH PANEL : Checks the touch panel key input.
Page 129 PERFORMANCE : Interrupt data will be displayed in increment. This information can be used to find solution when equipment failure occurs. MAINTENANCE(HS-8000) MAINTENANCE(M-LAN) MAINTENANCE(MODULE I/F) MAINTENANCE(IB-8000_1) MAINTENANCE(IB-8000_2) MAINTENANCE(IB-8000_3) MAINTENANCE(LC-8000) MAINTENANCE(DS-LAN) Since this display is used for development, do not press thse keys. If this is accidentally displayed, press the Previous Display key.
Page 130 Analog Adjustment : This adjusts the analog board. A special tool is required to adjust the analog board. For details, refer to the item of the analog adjustment screen. Initialize : All the data that has been set up will be cleared. Alarm log : The log of the generated alarm will be displayed.
Page 131 Details of the Test Menu This section explains each test menu items. ●MAINTENANCE(1/2) CPU A/D Verifies the data such as voltage and analog data read by the AD converter, and checks if they are in the normal operating range. If “NG” is displayed, malfunction of the circuit can be considered. Status ●Amount of installed memory information Displays the amount of memory installed on the main board.
Page 132 ●The rapid charge status of the Short Term Backup Battery Displays the rapid charge status of the Short Term Backup Battery. 11. Rapid charge (ON/OFF) ●The status of the external equipment connector Displays the presence of the external equipment connector. 12.
Page 133 ●VIDEO I/F Touching the display panel will sequentially display the following patterns. “Black” → “White” → “Gray Scale (8 gradation)” → ”Burst” → “Red” → “Green” → “Blue” When all 7 patterns are displayed, Video I/F test is completed and returns to test menu. Blue ↑...
Page 134 ●TOUCH PANEL ○ Each time the touch panel is pressed, the coordinates and a marker “ ＋ ” is displayed. If there is a big shift between the position pressed and the marker, perform the touch panel adjustment. Pressing the touch panel at any position for more than 3 seconds will return to the test menu screen.
Page 135 ●NIBP Test The NIBP function is tested. Pressing the START/STOP key for each test item, will start each test. Pressing the ALL TEST START/STOP automatically starts all the test. When the test result is “NG” , an NIBP module failure can be considered. Inflation Time The inflation performance of the NIBP pump is tested.
Page 136 ●EEPROM This display shows the data stored in EEPROM like the Equipment characteristic Info. Page 1/2 will not be particularly used for maintenance －...
Page 137: Rtc Setup
●RTC Setup Sets the built-in RTC (clock). Use the numeric keypad to enter the date and time. Press the Yr , Mo , Day , Hr , Min key, and set each item. Press the Setup key to store the setup. This RTC Setup in the test menu is the reference time setting at factory shipment.
Page 138: Storing The Device
Storage Storing the equipment and recording paper This section explains how to store the equipment and recording paper. Storing the Device Store in a place where the device will not be exposed to splashing water. Store in a place where the device will not be adversely affected by atmospheric pressure, temperature, humidity, ventilation, sunlight, dust or atmosphere containing salt or sulfur.
Page 139: Cleaning The Touch Panel And Housing
Cleaning the Touch Panel and Housing This section explains how to clean the device and sensors. Cleaning the Touch Panel Since the DSC-8500 system incorporates a touch panel, fingerprints and other stains are likely to appear. Follow the procedure below to clean the touch panel. Press the Key Lock key for more than 2 seconds.
Page 140: Cleaning The Housing
Cleaning the Housing Clean the housing using tightly squeezed gauze or an absorbent cotton cloth dampened with alcohol or a neutral cleanser. Clean the equipment frequently so stains can be removed easily. To prevent injury, it is recommended to wear gloves when cleaning the equipment.
Page 141: Cleaning The Nibp Cuff And Air Hose
Cleaning the NIBP Cuff and Air Hose Remove the rubber bag inside the cuff and wash the cuff (bag) with natural detergent. Before re-inserting the rubber bag, make sure that the cuff (bag) is dry. Cleaning and Disinfecting the SpO Sensor ®...
Page 142: Extention Board
Extention Board (CC-82/CC-83) This section describes the procedure to disassemble/assemble the Extention Board. Addition of Extension Board For the main unit equipped with Extension Board, maximum of 2 extended display units and LAN function can be connected. Video output connector, touch panel connector and LAN connector are equipped to allow connecting the optional extended display unit.
Page 143: Installation
Installation ●How to Install to the Extention Board Make sure that the power of the DSC-8500 Main Unit is turned OFF when C A U T I O N installing. ●Tools for installationt ・Phillips Screwdriver (Large) ●Disassembly and Assembly １. Remove the dummy panel on the left side of the DSC-8500 series main unit. 2.
Page 144 3. Push the hook of the fixing plate for extended board (82 or 83) after fixing the finger screw and connect it surely when you connect the extended board. 1) Turn 2) Push 4. Select the extended display unit type. (1) Press the [Menu], [Initial Settings], [System], [Other] keys.
Page 145: Periodic Replacement
Periodic Replacement This section describes the procedure to disassemble/assemble the equipment during periodic replacement. ●When the periodic replacement period approaches When the periodic replacement period approaches, the O sensor, NIBP unit, and short-term backup battery message will be displayed on the “Check Discharge at Power ON” screen to notify the user.
Page 146: Replacing The Short-Term Backup Battery
Replacing the Short-term Backup Battery ●Service Life of the Short-term Backup Battery For the short-term backup battery, a nickel hydride secondary battery is used. The service life is approximately 36 months depending on the usage frequency. If the device is used beyond this service life, the recall data, or short trend data may not be backed up for 5 minutes when the power is turned OFF.
Page 147 2. Remove the battery. ・Disconnect the wire of the short-term backup battery and pull out the battery. * When disconnecting the wire, pull out horizontally with the board. If disconnected with force, it may damage the wire. 3. Assemble the "4/V250H Battery Kit". ・Install the short-term backup battery inside the battery cover.
Page 148 5. Reattach the battery cover to the right of the main unit. ・W sems (S) M3 × 8 (Q’ty: 1) 6. Fill in the “Parts Replacement Label”. ・ Take out the “Parts Replacement Label” from the “4/V250H Battery Kit”. Write down ”4/V250H Battery”...
Page 149 Chapter 12 Periodic Check Maintenance Check Daily and Periodic Check····· 12-2 About Maintenance Check ····································· 12-2 ●Daily Check ··················································· 12-2 ●Periodic Check ·············································· 12-2 Periodic Replacement Period for Each Part ··········· 12-2 ●To Check the Periodic Replacement Period·· 12-3 Periodic Check ······················································· 12-5 ●Introduction ···················································...
Page 150: Maintenance Check Daily And Periodic Check
Maintenance Check Daily and Periodic Check This section explains daily check and periodic check of the device. About Maintenance Check Periodic inspection must be performed. When reusing the device, which was left unused for a while, always check that the device operates properly and safely before use. The following maintenance check items are for this equipment.
Page 151: To Check The Periodic Replacement Period
●To Check the Periodic Replacement Period Displays the used hours since the part which must be replaced periodically was first used. This information can be used as an indication for the periodic replacement period. Menu Maintenance Usage Time Displays the used months for periodic →...
Page 152 Daily Check List Inspected Date Inspected by Location Device Type (Main Unit) DS-8500 System Serial No. Device Type (Option Unit) Serial No. Device Type (Option Unit) Serial No. Item Details Criteria Judgment Appearance Visually check the exterior for No abnormality should be found. □OK / □NG scratches, cracks, deformation, and rust.
Page 153: Periodic Check
Periodic Check ●Introduction The periodic check is intended to check the medical equipment used daily in a medical institution to prevent failures and accidents and to ensure safety and reliability. As these are general check procedures covering the whole monitoring equipment, perform the check procedure for the corresponded function of the equipment.
Page 154: Periodic Check Item
C A U T I O N The measurement device must be properly calibrated. ●Periodic Check Item The periodic check items are as follows. Check Item External Appearance Power Supply Display / Control / Record Respiration Temperature Non-invasive Blood Pressure Arterial Oxygen Saturation (SpO Invasive Blood Pressure Cardiac Output (CO)
Page 155 Check Item Check Procedure Criteria 2. Power Supply Main Power Supply Connect the power cable to the outlet, Main power supply indicator Switch and turn ON/OFF the power switch. should light when system is turned ON. Fuse Take out the fuse from the fuse The specified fuse must be holder, and visually check the model used.
Page 156 No Check Item Check Procedure Criteria 4. ECG Input Impedance* Measure input impedance with safety Should be 5MΩ or above. tester. Suppression With SG-2000, input 50Hz or 60Hz Should be 10mmp-p or below Characteristic of 20Vr.m.s. signal, and measure for standard sensitivity Common-Mode fluctuation of each lead.
Page 157 Check Item Check Procedure Criteria 5. Respiration Respiration With comprehensive tester or reference The displayed amplitude Waveform Accuracy respiration signal generator, input should be within sinusoidal waveform of 0.5Hz with base 10mm±2mm. resistance of 1.5kΩ/1Ω change. Respiration Rate Input reference respiration signal with Error should be within Accuracy comprehensive tester or respiration...
Page 158 No. Check Item Check Procedure Criteria 9. Invasive Blood Pressure BP Accuracy Apply the voltage of 0, 100, and Error should be within (full 200mmHg using a comprehensive scale, 300mmHg) ±2% or tester, and measure the difference ±1mmHg, whichever is between the value displayed in the larger.
Page 159 No. Check Item Check Procedure Reference 13. Calibration Touch Panel Perform calibration when the touch Touch panel calibration value is panel is largely displaced. stored in the display unit. Analog If measurement error of ECG, BP, Calibration value of analog board TEMP, CO is too large, perform is stored in the analog board.
Page 160 Check Item Check Procedure Criteria 14. Electrical Safety Earth Leakage Measure the earth leakage current with Earth Leakage Current (NC) Current (NC) normal condition using a safety tester. Should be ≤0.1mA According to test procedure of IEC 60601-1 19. Earth Leakage Measure the earth leakage current with Earth Leakage Current Current (SFC)
Page 161: Periodic Check List
●Periodic Check List Bedside Monitor Periodic Check Report Check Date Periodic Check Contract Delivery Date Location □Yes □No Customer Code Month Check Model Name Serial No.: Product Code Next Check Date Requested Acceptance Date Item Check Item Judge Check Item Judge Check Item Judge...
Page 162 Blank Page －...
Page 163 • The company and product names used in this manual are trademarks or registered trademarks. • If this manual has pages missing or out of order, contact Fukuda Denshi for replacement. • Only physician or persons instructed by physicians are allowed to use the equipment.
Page 164 39-4, Hongo 3-chome, Bunkyo-ku, Tokyo, Japan Phone:+81-3-3815-2121 Fax:+81-3-3814-1222 Printed in Japan 4R0100600 201108...

This manual is also suitable for:

Dsc-8530 Cc-82 Cc-83

Fukuda Denshi DSC-8510 Service Manual

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fukuda Denshi DSC-8510

Summary of Contents for Fukuda Denshi DSC-8510

This manual is also suitable for:
