Quick Start Guide
for
RSU-352 Family
Description
®
®
Acceptance Date
2023/03/24
2023/03/24
Originator
Nidor Huang
Creating document
Adding product variants
Nidor Huang
Adding product characteristics
Adding dimensions and weight
Updating temperature range
Nidor Huang
Updating mechanical drawing
Adding GNSS antenna detection mechanism
Nidor Huang
Adding V2X antenna detection mechanism
Nidor Huang
Adding GORE
Updating product variants to 352 series
Nidor Huang
Updating functional block diagram
Updating Unex BSP interface settings
Nidor Huang
Updating mounting bracket instructions
Doc. No: Unex-QSG-21-002
Document Number
Revision
Authors
- Europe ETSI C-V2X stack, 0A1
®
- Europe ETSI ITS-G5 stack, 0A1
- US C-V2X stack, 0A1
- US DSRC/WAVE stack, 0A1
®
Note
Comment
®
Vent
Unex-QSG-21-002
0.8
Nidor Huang
1/21
