Mounting and User Instructions for
Double folding screen awning
Packing List...................................
Product Description.......................
Safety Instructions.........................
Technical Data...............................
Preparations..................................
Mounting........................................
Cleaning.........................................
Dismounting...................................
Storage...........................................
Disposal..........................................
2-3
3
3
4
4
5-9
11
11
11
12
1
Advertisement
Table of Contents
Related Manuals for Metalcraft GR-4100
Summary of Contents for Metalcraft GR-4100
-
Page 1: Table Of Contents
Mounting and User Instructions for Double folding screen awning Content Packing List........Product Description....... Safety Instructions......Technical Data....... Preparations........Mounting........Cleaning......... Dismounting........Storage........... Disposal.......... -
Page 2: Packing List
Attention: Read this instruction manual carefully and completely before mounting and usage. Keep this manual for future reference. Dear Customer, congratulations and thank you for buying an awning. To enjoy this product for a long time and for your own and the safety of other people please obey the mounting instructions. Before you start mounting and using the awning, please get familiar with this product. -
Page 3: Product Description
Front bar top bracket for wall mount Front bar bottom bracket for wall mount Screw Expansion bolts Fluorescent base Instruction manual Independent parts：if the place not with wall where you will install the screen , you can choose the below part to install the screen on the floor. Product Description Double folding screen awning are a retractable system that gives you shade and privacy outdoors. -
Page 4: Safety Instructions
Cassette Front bar Front bar top bracket for wall mount Wall bracket Handle Front bar bottom bracket for wall mount End cap Standing pole Fabric Standing pole base Important Safety Instructions Warning: For your own and the safety of other persons it is important to follow below instructions and obey warnings. -
Page 5: Preparations
This product and its fixing parts are only suitable for installation on a plain cement wall or stable unrendered brickwork. If the wall/brickwork shows cracks you have to consult a professional. Nobody is allowed to change the products’ design and structure without the permission of manufacture or authorized deputy. - Page 6 Fix the screen on the floor as following step: Drilling the holes which diameter is 14mm and the depth must be more than 90mm on the floor...
- Page 7 Fix the base on the floor, shown as the left drawing ; fix the brackets on the base ,shown as the right drawing: According to the below drawing to fix the screen on the brackets ,the way is the same as fix on the wall.
- Page 8 Fix on the base of front bar (according to the below drawing to drilling the holes which diameter is 14mm and the depth must be more than 80mm on the floor.)
- Page 10 Fix on the button of front bar： if your screen is a fixed location, in pull fabric the range of a wall , you can choose to install hook of the front bar on the wall, with hook of front bar instead of the use of the post. Hook of front bar installation steps are as follows: When use the screen ,please insert the pole of front bar into the base of front bar, then rotating fasten on the base, then put the hand grip，...
- Page 11 During the period of using double folding screen awning, pull out and retract, to ensure that the cloth surface and the ground parallel, otherwise the fabric will be twisted or not returned.
-
Page 12: Cleaning
Cleaning Frame: Over time, dust and dirt will collect on the frame and will require periodic cleaning to maintain its appearance. A mild spray cleaner or water/detergent mixture may be applied to the frame to clean it. Wipe dust off with a damp cloth. -
Page 13: Disposal
Disposal Do not dispose this awning with other household wastes. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased.
