Manufactured for Rooms To Go.
Thank you for purchasing this quality product. Be sure to check all packing material for small parts which may have
come loose inside carton during shipment. Identify and count all parts and compare with the hardware list as below:
No.
1
2
Hardware List
3
4
No.
A
B
C
Parts List
D
E
F
A
E
PARTS DETAIL
Hardware Pack Location (s) :
4265-CH SIDE CHAIR SKU# 42442652
ASSEMBLY INSTRUCTIONS
ITCO
4265-CH SIDE CHAIR
SKU# 42442652
Description
Long Bolt M6 x 80mm
Spring Washer
1/4" x 12
Ø
Flat Washer
1/4" x 19
Ø
Short Bolt M6 x 35mm
Spring Washer
1/4" x 12
Ø
Flat Washer
1/4" x 19
Ø
Wood Screw
Allen Key
Description
Chair Back
Seat With Frame
Front Leg- Left
Front Leg- Right
Side Stretcher- Left
Side Stretcher- Right
B
F
C
6 x P1.0 x 80mm
6 x P1.0 x 35mm
D
Page 1 of 3
Dimension
M4 x 38mm
M4
Hardware Pack Location
Qty
8 Pcs
8 Pcs
8 Pcs
3 Pcs
3 Pcs
3 Pcs
4 Pcs
1 Pc
Qty
1 Pc
1 Pc
1 Pc
1 Pc
1 Pc
1 Pc
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ROOMS TO GO 4265-CH
Summary of Contents for ROOMS TO GO 4265-CH
- Page 1 Seat With Frame 1 Pc Front Leg- Left 1 Pc Parts List Front Leg- Right 1 Pc Side Stretcher- Left 1 Pc Side Stretcher- Right 1 Pc Hardware Pack Location PARTS DETAIL Hardware Pack Location (s) : 4265-CH SIDE CHAIR SKU# 42442652...
- Page 2 Page 2 of 3 Assembly steps STEP 1 Attach front leg- left (C) and front leg- right (D ) to the seat with frame (B) Tighten with Allen Bolt, Lock Washer and Flat Washer (1) using Allen Key (4). STEP 2 Attach seat with frame (B) side stretcher- left (E) side stretcher- right (F) to the chair back (A) and tighten with Long Bolt, Lock Washer and Flat Washer (1) and Short Bolt, Lock Washer and Flat Washer (2) using Allen Key (4).
- Page 3 Page 3 of 3 Assembly steps STEP 3 Tighten side stretcher to front leg and chair back with wood screw (3) using screwdriver (Not provided). Screwdriver - Not provided STEP 4 Complete Assemble NOTE : Make sure this product assemble on the flat and soft surface. Follow the instructions. Tighten all the nuts, bolts or screws firmly and make sure this product does not wobble before use.
