ASSEMBLY INSTRUCTION
721 PARSON CHAIR
A
Chair Back
1pc
E
Flat Washer
Ø5/16"x19mm
11pcs
I
Allen Key
M5
1pc
B
Seat
1pc
F
Bolt
Ø5/16"x3-1/2"
4pcs
J
Wood Dowel
Ø10x30mm
1pc
C
Front Leg
2pcs
G
Bolt
Ø5/16"x3"
3pcs
This page lists all the contents included in
Please take the time to identify
the box.
the hardware as well as the individual
components to this product.
unpack and prepare for assembly, place
the contents on a carpeted or padded
area to protect them from damage.
1
D
Lock Washer
Ø5/16"x13mm
11pcs
H
Bolt
Ø5/16"x2-1/2"
4pcs
As you
