MARINE ELECTRONICS
One Touch To Choose Your World
Sunlight Readable Display Color Chart Plotter with external GPS Receiver
Sunlight Readable Display Color Chart Plotter with internal GPS Receiver
Sunlight Readable Display Color Chart Plotter with external GPS Receiver
Sunlight Readable Display Color Chart Plotter with internal GPS Receiver
PANORAMIC 8 HD FISH
COMPACT 8 HD FISH
Copyright 2009 LORENZ ELECTRONICS Italia.
All rights reserved. Printed in Italy. No part of this publication may be reproduced or distributed in any form or by any
means, or stored in a database or retrieval system, without prior written permission of the publisher.
PANORAMIC 8 XL
CODE: S4egLZ7wcx 1602gA83/300309
COMPACT 8 XL
CODE: S4igLZ7wcx 1602gA83/300309
PANORAMIC 8 HD
CODE: S4egLZ8wc 1602gB25/300309
COMPACT 8 HD
CODE: S4igLZ8wc 1602gB25/300309
Sunlight Readable Display Color Chart Plotter
with external GPS Receiver
CODE: S4egLZ8wc 1602gB25/300309
Sunlight Readable Display Color Chart Plotter
with internal GPS Receiver
CODE: S4igLZ8wc 1602gB25/300309
& internal Fish Finder
& internal Fish Finder
U
SER
M
ANUAL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lorenz PANORAMIC 8 XL
Summary of Contents for Lorenz PANORAMIC 8 XL
- Page 1 CODE: S4igLZ8wc 1602gB25/300309 ANUAL Copyright 2009 LORENZ ELECTRONICS Italia. All rights reserved. Printed in Italy. No part of this publication may be reproduced or distributed in any form or by any means, or stored in a database or retrieval system, without prior written permission of the publisher.
- Page 2 Warning! Electronic charts displayed by the chart plotter are believed to be accurate and reliable, but they are not intended to substitute for the official charts which should remain your main reference for all the mat- ters related to the execution of a safe navigation. For this reason we would like to remind you that you are required to carry on board and use the officially published and approved nautical charts.
-
Page 3: Table Of Contents
Table of Content Introduction ..................13 1.1 CONVENTIONS ..................13 1.2 FEATURES ..................13 1.2.1 Specifications ................. 14 1.2.1.1 Main Characteristics ............14 1.2.1.2 Physical Characteristics & C 8 XL/HD ANORAMIC OMPACT 1.2.1.3 Physical Characteristics & C 8 HD F ANORAMIC OMPACT FF Module 600W-50-200KHz Technical Specifications . - Page 4 3.1.4 Navigation Data Page ..............36 3.1.5 Graphic Data (Rolling Road) Page ..........37 3.1.6 Wind Data Page ................37 3.1.7 Fish Finder Pages ................37 3.2 BASIC SETTINGS ..................38 3.2.1 Course Vector ................. 38 3.2.2 Screen Amplifier ................38 3.2.3 Advanced Functions ...............
- Page 5 3.5.2.1 Info on objects with Pictures ........... 55 Change Picture Size ............56 3.5.2.2 Quick Info on Lakes ............56 3.5.2.3 Full Info on Lakes ............57 3.5.3 Info Tree and Expanded Info page ..........57 3.5.4 Info Function ................... 58 3.5.5 Getting Port Info ................
- Page 6 4.1.2.7 Send/Receive Route ............72 4.1.2.8 Safe Route Checking ............72 4.2 MARK & EVENT ..................74 4.2.1 Marks ..................74 4.2.1.1 Adding Mark ..............74 4.2.1.2 Deleting Mark ..............74 4.2.1.3 Goto ................. 74 4.2.1.4 Moving Mark ..............74 4.2.1.5 Editing Mark ..............
- Page 7 Advanced Settings ..................89 5.1 SETUP ..................89 5.1.1 Time Reference ................89 5.1.2 Time Format ..................89 5.1.3 Date Format ..................89 5.1.4 Wind Speed ..................90 5.1.5 Beeper ..................90 5.1.6 External Wpt ..................90 5.1.7 Backlight Timeout ................90 5.2 FIX ..................
- Page 8 5.7.2.5 TCPA Alarm ..............100 5.7.2.6 TCPA Limit ..............100 5.7.3 To Set the Chart Plotter for Receiving AIS ........100 5.7.4 Quick Info on AIS Target .............. 100 5.8 C-STAFF ..................101 5.9 C-WEATHER SERVICE ................. 101 5.9.1 C-Weather Service Menu ............. 102 5.9.1.1 Download ...............
- Page 9 6.5.7 Frequency ..................124 6.5.8 Interference Rejection ..............124 6.5.9 Sensitivity ..................124 6.5.9.1 Frequency O ....124 NLY IN THE REQUENCY PAGE 6.5.9.2 Gain ................125 6.5.9.3 STC ................125 6.5.9.4 STC Length ..............125 6.5.9.5 STC Strength ..............125 6.5.9.6 Surface Noise Filter ............
- Page 10 Terms ..................143 Smart DGPS WAAS Receiver ..............151 B.1 INSTALLING ..................151 B.2 DIMENSIONS ..................152 Analytical Index ..................153 User Manual...
-
Page 11: Conventions
Introduction Congratulations on your purchase of the chart plotter! If you have not used a position-finding instrument before and intend to use your chart plotter for navigating, we suggest you should read this User Manual and make sure you are familiar with its contents. The User Manual is divided into three main parts. -
Page 12: Specifications
more precisely, to ease and speed up all calculations, which so far have been done manually. If connected to a positioning instrument, the chart plotter displays the current position, the speed, and the heading of the boat and its Track. The user information like Waypoints, Marks and Tracks can then be stored on a User C-CARD and can be recalled at any time. - Page 13 Cartographic Functions Detailed Map by using C-MAP B C-CARD EPPESEN • "C-MAP B " MAX electronic charts, object-oriented chart system with EPPESEN • enhanced functionality including: Guardian alarm, Safety Status Bar, Safety route check Perspective view Satellite image coverage Turbo and Smooth Zoom Multilanguage Enhanced Port information database Tides &...
- Page 14 Fix Functions Fix Correction (manual and automatic) • Position Filter • Speed Filter • Dead Reckoning • Screen Amplifier • Reset Total and Partial Trip • Rolling Road Scale • Fix Datum • Compass Calibration • Bearings True and Magnetic •...
-
Page 15: Physical Characteristics
Depth Unit (Ft, FM, Mt) • Altitude Unit (Ft, FL, Mt) • Temperature Unit (°C, °F) • Alarms Handling • Arrival Alarm, XTE Alarm, Anchor Alarm, Depth Alarm, Grounding Alarm, External Alarm MOB Function • Simulation • Speed, Heading, Date, Time, Cursor Control, Activate Simulation Auxiliary Memory User C-CARD 1/2/4 MB •... -
Page 16: Ff Module 600W-50-200Khz Technical Specifications
Keyboard Backlighted, silicon rubber • 1.2.1.3Physical Characteristics 8 HD F & C 8 HD F ANORAMIC OMPACT Chart Plotter size (inch/mm) 9.5" x 5.9" x 4.6" (241 mm x 151 mm x 116.5 mm) • Chart Plotter weight 1310 gr F 8 HD F OMPACT •... - Page 17 1.3 BASICS The chart plotter is controlled by using 13 keys. There is also a cursor key to move a cursor across the screen. As you press a key, a single audio beep confirms the key action; every time the key pressed is not valid, three rapid beeps sound indicates that no response is available.
- Page 18 User Manual...
-
Page 19: Before You Begin
Before You Begin This chapter provides basic information to get you start using the chart plotter; it will help you to become familiar with the chart display and the functions of the controls before you start using the chart plotter. 2.1 THE KEYBOARD 'CONTRAST'/'BACKLIGHT'/'POWER' key Press and hold for 1 second 'POWER' to turn the chart plotter On. - Page 20 Nota If the "Selectable Nav 3D" item in the Navigation menu (see Par. 5.3) is set, by pressing '<MODE>' it is possible to select the following modes: Charting, Navigation (Home), Navigation (Home) in 3D, Charting in 3D. Any time the key is pressed, a message describing the newly selected mode is shown on the center of the screen for about 2 seconds.
-
Page 21: Turning The Chart Plotter On And Off
Press 'MAP' to cycle among the Chart pages. Press 'MAP' for 1 second to open the Map Menu. Press 'ECHO' to select the Fish Finder pages (*). Note* 8 XL/HD & COMPACT 8 XL/HD ANORAMIC When Fish Finder or Radar is connected, otherwise the chart plotter emits three beeps. Refer to the Fish Finder or Radar User Manual for more information. -
Page 22: Selecting The User Interface Language
2.5 EXTERNAL CONNECTIONS 2.5.1 GPS CONNECTION PANORAMIC 8 XL/HD/HD F Connect the GPS to the Port 3: see the picture in Fig. 2.5.1. Control the input setting following the procedure: 'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' + "PORT 3 INPUT"... -
Page 23: Autopilot Connection
POWER QUICK DISCONNECT BRACKET CABLE SUPPLY WIRE COLOR DESCRIPTION FUNCTION BLACK GND/COMMON POWER SUPPLY GND POWER +10-35Vdc POWER SUPPLY+ WHITE INPUT1+ NMEA0183/C-COM GREEN SIGNAL RETURN- SIGNAL RETURN YELLOW OUTPUT1+ NMEA0183/180/180CDX/C-COM GPS POWER BROWN INPUT2+ NMEA0183/C-COM SWITCH GRAY OUTPUT2+ NMEA0183/180/180CDX/C-COM ORANGE INPUT3+ NMEA0183/C-COM PINK... -
Page 24: External Nmea Connection
QUICK DISCONNECT BRACKET CABLE WIRE COLOR DESCRIPTION FUNCTION BLACK POWER GND POWER SUPPLY GND POWER +10-35Vdc POWER SUPPLY+ WHITE INPUT1+ NMEA0183/C-COM GREEN SIGNAL RETURN- SIGNAL RETURN YELLOW OUTPUT1+ NMEA0183/180/180CDX/C-COM BROWN INPUT2+ NMEA0183/C-COM AUTOPILOT DEVICE GRAY OUTPUT2+ NMEA0183/180/180CDX/C-COM FUNCTION ORANGE INPUT3+ NMEA0183/C-COM PINK OUTPUT3+... -
Page 25: C-Com Gsm Plus Connection
QUICK DISCONNECT BRACKET CABLE WIRE COLOR DESCRIPTION FUNCTION BLACK POWER GND POWER SUPPLY GND NMEA0183 POWER +10-35Vdc POWER SUPPLY+ DEVICE WHITE INPUT1+ NMEA0183/C-COM FUNCTION GREEN SIGNAL RETURN- SIGNAL RETURN YELLOW OUTPUT1+ NMEA0183/180/180CDX/C-COM NMEA0183 OUTPUT+ BROWN INPUT2+ NMEA0183/C-COM NMEA0183 INPUT+ GRAY OUTPUT2+ NMEA0183/180/180CDX/C-COM SIGNAL RETURN... -
Page 26: Hd/Fish
8 HD ANORAMIC OMPACT 1. Connect AUX IN I/O as follows: AUX-IN I/O CABLE AUX-IN I/O CABLE AUX IN I/O PIN CABLE COLOR FUNCTION Fig. 2.5.4 - Connection for the Port 4 Note The connection is valid for the C-COM IR and C-COM RS232 too. 2. -
Page 27: Additional C-Cards
3. Set the C-COM for Port 1 as follows: 'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' + "PORT 1 INPUT" + 'ENTER' + "C-COM" + 'ENTER' 2.6 ADDITIONAL C-CARDS The chart plotter uses two types of C-MAP B cartridges: either a EPPESEN chart cartridge or a data storage cartridge. -
Page 28: Select Video Input
Warning! THIS IS THE RECOMMENDED WAY TO REMOVE THE C-CARD FROM THE CHART PLOTTER. If opening the door the C-CARD remains fixed into the chart plotter slot, do not try to remove it, but close the door again pressing it a lot so the C-CARD remains fixed into the door. -
Page 29: Quick Activation
following keys to adjust video settings: press the left side of 'POWER' to adjust the contrast and the right side of 'POWER' to adjust backlight, move the cursor up/ down to adjust brightness and left/right to adjust colors, press 'ZOOM IN'/ZOMM OUT' to adjust hue phase. - Page 30 User Manual...
-
Page 31: For The New User
For the New User In order to get started using your chart plotter, you must do the following things: 1) Your chart plotter must have been installed properly according to the installation instruction on Par. 6.2. 2) You must have performed the proper settings for use with your position- ing instrument (see Par. -
Page 32: Charts And Text Area
3.1.1 CHARTS AND TEXT AREA The charts and text area can be shown in two different modes. The first is with text area on the right side of the screen: Fix received Indication - if fix is not received the following icon is shown: - if a Differential GPS signal is received the following icon is shown: Charting or Navigation (Home) -
Page 33: Depth Graph Page
Fig. 3.1.1b - Example of Full charts 3.1.2 DEPTH GRAPH PAGE The depth graph can be shown in two different modes. Depth graph dis- played only on 1/3 of the screen: Fig. 3.1.2 - Example of Depth Graph 1/3 of the screen or Depth graph displayed on 1/2 of the screen: Fig. -
Page 34: Navigation Data Page
Fig. 3.1.3 - Example of GPS Data Page On the right side of the screen (see Fig. 3.1.3), there is a polar representation of the Azimuth and elevation of each satellites. The circle contains a number indicat- ing the PRN of the satellite and it is filled when it is used for the fix solution. On the left side there are histograms indicating the S/N ratio (SNR). -
Page 35: Graphic Data (Rolling Road) Page
3.1.5 GRAPHIC DATA (ROLLING ROAD) PAGE The Graphic Data Page shows in graphic mode navigation data. Fig. 3.1.5 - Example of Graphic Data Page 3.1.6 WIND DATA PAGE The Wind Data Page shows data related to the wind: TWS (True Wind Speed: Velocity of the Wind relative to a fixed point on the earth), AWS (Apparent Wind Speed: the Speed at which the Wind appears to blow relative to a moving point, also called Relative Wind Speed), TWA (True Wind Angle) and AWA (Apparent Wind... -
Page 36: Basic Settings
Fig. 3.1.7 - Fish Finder Pages 3.2 BASIC SETTINGS The Basic Settings menu provides access to the set up functions. Here you can choose the language you want (see Par. 2.4). For "Page Preview" option see Par. 3.1. 'MENU' + "BASIC SETTINGS" + 'ENTER' 3.2.1 COURSE VECTOR Disables (Off) the Course Vector or selects the preferred time among: 2, 10, 30 Min, 1 hour, 2 hours, Infinite. -
Page 37: User Points
3.2.4 USER POINTS Selects the User Point display among On, Off or Icon. The default setting is On. 'MENU' + "BASIC SETTINGS" + 'ENTER' + "USER POINTS" + 'ENTER' 3.2.5 DEPTH WINDOW Enables/Disables the display on the Depth Window on the screen. The de- fault setting is Off. -
Page 38: Input/Output Menu
3.2.8 INPUT/OUTPUT MENU WARNING !!! After every software upgrade the RAM is cleared and the chart plotter re starts with the usual default settings. Please go to the Input/Output menu and set the proper input format once again. 3.2.8.1 Port 1/Port 2/Port 3/Port4*/Port5* Input Sets or disables the format for the navigation data input serial Port1/2/3/4*/ 5*. -
Page 39: Internal Gps Only For Compact
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' + "GPS SETUP" + 'ENTER' Note This item is shown alternately to the selection of the output messages when to the related port is connected a GPS identificable by the chart plotter. Internal GPS COMPACT 8 XL/HD/HD F Enables (On) or disables (Off) the Internal GPS. -
Page 40: Cable Wiring Page
nal Alarm (when activated, this pin goes to GND level. It is used to command an external buzzer), External Power (it is command switch for the Radar. It must be used in conjunction with the Radar Junction box device) and Off. 'MENU' + "BASIC SETTINGS"... -
Page 41: A-B-C-D Function
'MENU' + "BASIC SETTINGS" + 'ENTER' + "C- VOICE" + 'ENTER' + "OUTPUT PORT" + 'ENTER' 3.3 A-B-C-D FUNCTION The A-B-C-D Function allows you to create the A, B, C, D points and to delete them. 3.3.1 INSERTING THE A-B-C-D POINTS Place the cursor on the desired position and press 'ENTER': the A point and an information window on A appear. -
Page 42: Navigating To A Single Destination
3.4 NAVIGATING TO A SINGLE DESTINATION 3.4.1 DISTANCE AND BEARING TO TARGET (DESTINATION) Once you have positioned the cursor on your desired location (a generic point on the map) press 'GO-TO'. On the screen is shown a straight line connecting the Target (called DEST) with the ship's position and an information window with Target position, that disappears when the cursor is moved from the Target. -
Page 43: C-Map B Yjeppesen Max Cartography Information
3.5 C-MAP MAX CARTOGRAPHY INFORMATION EPPESEN MAX is a major evolution of the product technology. Key points are: Data Features ISO Certification (electronic chart production process with quality certification) • Extra Large Coverage (all the C-MAP B electronic chart detail and a EPPESEN •... -
Page 44: Map Settings Menu
Perspective View ("Real World" perspective view of the chart, updated real-time • during navigation) Smooth-Zoom (smooth transition of cartographic levels) • Enhanced Turbo-Zoom (extra fast cartography level change displaying the most • important cartographic objects) Enhanced Mixing Levels (seamless data presentation) •... -
Page 45: Palette
As the upper side of the map is more compressed than the lower side, a wider map area is visible. The perspective view allows showing more chart information immedi- ately ahead and around the cursor. Fig. 3.5.1.1 - Perspective View 3.5.1.2 Palette 'MENU' + "MAP SETTINGS"... -
Page 46: Fonts & Symbols
This feature allows more expansions or compression of the chart scale while zooming in or out. Zoom Type has two options; STANDARD (default) or FLEXI- ZOOM. When in FLEXI-ZOOM mode, a short 'ZOOM...' push causes a change of chart, whilst a long 'ZOOM...' push (press and hold) causes a pop-up window to be displayed on a corner of the screen. -
Page 47: Safety Status Bar (Dsi - Data Safety Indicator)
mation read from, at most, two zoom levels above the current zoom level. For this reason the map is drawn three times: firstly it draws the two levels before the current level and then the current level. The area covered by the cartographic data read from the previous levels is identified by a dotted pattern. -
Page 48: Satellite Imagery
scale, gray otherwise. O. Zoom: red when the chart is over-zoomed in more than twice normal • scale, gray otherwise. Chart Lock: red when the chart is zoomed in more than twice normal scale, • gray otherwise. Best Scale Red when a more detailed chart is available under the cursor position. Data Off Red when at least one of the following objects or layers is turned off (by the user): Depths/soundings;... -
Page 49: Other Map Configurations
Language: Allows setting the language to display chart information. The language is chosen among the list of languages available on the cartographic data (C-CARD or embedded charts). 'MENU' + "MAP SETTINGS" +'ENTER' + "Chart Language" + 'ENTER' + "Language" + 'ENTER' Mode: Defines how objects are translated. - Page 50 Seabed Type Ports & Services Tracks & Routes Depth Range Min 3 Mt 3 Mt 3 Mt 3 Mt 3 Mt 3 Mt Depth Range Max 10 Mt 10 Mt 10 Mt 10 Mt 10 Mt 10 Mt Land Elevations Land Elevation Data Roads POIs...
- Page 51 Ports & Services: On/Off. The default setting is On. 'MENU' + "MAP SETTINGS" +'ENTER' + "Other Map Configurations" + 'ENTER' +"Ports & Services" + 'ENTER' Tracks & Routes: On/Off. The default setting is On. 'MENU' + "MAP SETTINGS" +'ENTER' + "Other Map Configurations" + 'ENTER' + "Tracks &...
-
Page 52: Getting Automatic Info
'MENU' + "MAP SETTINGS" +'ENTER' + "Other Map Configurations" + 'ENTER' + "Chart Lock" + 'ENTER' Underwater Objects Limit: Selects the max depth value to display Underwater Objects. The default setting is 10 Mt. 'MENU' + "MAP SETTINGS" +'ENTER' + "Other Map Configurations" + 'ENTER' + "Underwater Object Limit"... -
Page 53: Info On Objects With Pictures
On Points: only on points. This is the default setting. • On All: on all objects (points, lines and areas). • The Automatic Info On Points shows information when the cursor is placed on points (as Port Services, Tides, lights, wrecks, rocks, buoys, beacons, obstruc- tions, land markers, etc.). -
Page 54: Change Picture Size
Objects Fig. 3.5.2.1a - Example of Full Info on objects with picture To see picture press 'MENU' when the object with a picture is highlighted. Change Picture Size When the picture is shown, it is possible to fit it to screen by pressing 'ENTER'. 3.5.2.2 Quick Info on Lakes Upon viewing the chart of a lake, you will click on to query the available infor-... -
Page 55: Full Info On Lakes
If you press 'ENTER' all available information about the cartographic point under the cursor will be shown. See the next paragraph. 3.5.2.3 Full Info on Lakes The following is an example of Full Info on Lakes: Fig. 3.5.2.3 - Example of Full Info page To see the "Fishing"... -
Page 56: Info Function
3.5.4 INFO FUNCTION Place the cursor in any place you want and press: 'MENU' + 'INFO' to show the Info Tree and Expanded Info page (see Par. 3.5.4). 3.5.5 GETTING PORT INFO Upon viewing the chart of a port or harbor, you will see a Port Info icon that can be clicked on to query the available information immediately displayed with many details. - Page 57 Fig. 3.5.6 - Tide Info icon Place the cursor on the Tide symbol, a Automatic Info window is opened: Fig. 3.5.6a - Automatic Info on Tide To display the Tide Graph page, press 'ENTER': Fig. 3.5.6b - Tide Graph Using the cursor key, it is possible to move the cursor anywhere on the graph and display the time, height (vertical cursor) and draught (horizontal cursor) on a particular graph point.
-
Page 58: Find Function
3.5.7 FIND FUNCTION The chart plotter allows finding Nearest Services, Port By name, Port By distance, Tide Stations, Wrecks, Obstructions, Lakes info, POIs. 3.5.7.1 Finding Port Services To locate and display the nearest available facilities of a particular type (i.e. the nearest Hospital, sailmaker, bank, etc.). -
Page 59: Finding Ports By Distance
3.5.7.6 Finding Ports By Distance To select the Ports By Distance function following the procedure: 'MENU' + "FIND" + 'ENTER' + "PORTS BY DISTANCE" + 'ENTER' Shows the list of all ports stored on the C-CARD in closest distance order and allows to locate the ports on the map. -
Page 60: Finding Points Of Interest
3.5.7.9 Finding Points Of Interest Searches for Nearest Points Of Interest: 'MENU' + "FIND" + 'ENTER' + "POINTS OF INTEREST" + 'ENTER' A sub-menu is opened to find different categories of POIs. 3.6 MAN OVERBOARD (MOB) It is an important function useful in the case someone or something falls overboard. -
Page 61: For The Experienced User
For the Experienced User Now you have had a chance to became familiar with your new chart plotter, there are a great number of advanced features that you will find helpful. First of all the use of the Advanced Mode. The chart plotter can operate in two different modes: Basic Mode and Ad- vanced Mode. -
Page 62: Creating A Route
Fig. 4.1.1.1 - Waypoint placing 4.1.1.2 Creating a Route Repeat the "Adding Waypoint" procedure described in the previous Par. 4.1.1.1. The sequence of moving the cursor and pressing 'ENTER' is continued to create the Route, until you have reached the last Waypoint, your final destination. Segments connecting the Waypoints are shown, and the starting point is identified by a circle surrounding the first Waypoint of the route: Fig. -
Page 63: Deleting Route
Press 'ENTER'. Select "DELETE" and press 'ENTER'. The Waypoint is deleted and a new line between previous and next Waypoint is shown. The deleted Waypoint remains shaded until the screen is redrawn. Fig. 4.1.1.3a - Deleting Waypoint (II) 4.1.1.4 Deleting Route Select Advanced Mode + Place cursor on Waypoint Press 'ENTER'. -
Page 64: Time To Go
Time To Go When the Target is set the TTG value is displayed in the Graphic Data Page: 'PAGE' more times to select Graphic Data page Note If SOG value is less than 1.0 knots or the BRG is greater than 90 degrees, the TTg value is not displayed. -
Page 65: Inserting Waypoint
Fig. 4.1.1.6a - Moving Waypoint function (II) 4.1.1.7 Inserting Waypoint Every time you place the cursor on the segment connecting two existing Waypoints of a Route the following function is available. Place cursor on route leg Fig. 4.1.1.7 - Placing Waypoint between two existing ones (I) Press 'ENTER'. -
Page 66: Editing Waypoint
Once you have positioned the cursor at new location, press 'ENTER' (press 'CLEAR' to abort operation): Fig. 4.1.1.7b - Placing Waypoint between two existing ones (III) 4.1.1.8 Editing Waypoint Select Advanced Mode + Place cursor on Waypoint Press 'ENTER'. Select "EDIT" and press 'ENTER' to modify a Waypoint. A window will be shown with Name, Symbol, Color and Latitude/Longitude of the Waypoint, advising about what Waypoint data are modifiable. -
Page 67: Finding Info On Waypoints: User Points List Page
Use the cursor key to select the symbol and press 'ENTER'. If select Coordi- nates field, press 'ENTER' and then use the cursor key to insert the value. If Color field is selected press 'ENTER': a window with 8 different colors appears, use the cursor key to select the desired color and press 'ENTER'. -
Page 68: Deleting All Stored User Points
Deletes all User Points which have the same type of that shown in the selected row. A warning message appears, select "YES" and press 'ENTER' ('CLEAR' otherwise). Deleting all stored User Points 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "USER POINTS" + 'ENTER' + "CLR-ALL' + 'ENTER' A warning message appears, select "YES"... -
Page 69: Reversing Route
4.1.2.3 Reversing Route 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "ROUTE" + 'ENTER' + "ROUTE REVERSE" + 'ENTER' Reversing a Route plan is most typically used to return to the point where the Route originally started. 4.1.2.4 Route Color 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "ROUTE" + 'ENTER' + "ROUTE COLOR"... -
Page 70: Changing Speed & Fuel Values
Changing Speed & Fuel values 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "ROUTE" + 'ENTER' + "ROUTE REPORT" + 'ENTER' It is possible to modify the Speed and Fuel consumption values, respectively by se- lecting "SPEED" and "FUEL". Insert value by using the cursor key and pressing 'ENTER'. - Page 71 Intertidal Areas • Rocks • Wrecks • Obstructions • Shoreline Constructions • Fishing Facility • Dreged Areas • Diffusers • Mooring/Warping Facility • Production Installation • Pingos • No Data Available • If any of these alarm conditions is detected, the function returns the list of dangerous objects and the relative dangerous route leg, that is drawn with a different color.
-
Page 72: Mark & Event
4.2 MARK & EVENT You may place a Mark, as it is called, at your cursor position, while Event is created at your vessel position. 4.2.1 MARKS You may tag a location on the chart with a Mark symbol and number, which you can record for later use. -
Page 73: Editing Mark
Fig. 4.2.1.4 - Moving Mark function (I) Press 'ENTER': Fig. 4.2.1.4a - Moving Mark function (II) The Mark is placed in the new position, the "old" Mark, remains on the screen shaded until the screen is redrawn. Note If you try to move a Mark that belongs to many Routes, the chart plotter emits three beeps and on the screen a Warning message appears. -
Page 74: Finding Information On Marks: User Points List Page
Use the cursor key to select the field. If you have selected Name field, press 'ENTER': use the cursor key to insert the character (8 characters max), then press 'ENTER'. If Symbol field is selected press 'ENTER': a window with 16 different symbols appears. -
Page 75: Goto
Note If you try to delete a Event that belongs to many Routes, the chart plotter emits three beeps and on the screen a Warning message appears. If you want to delete the Event, press 'ENTER'. 4.2.2.3 Goto Place cursor on Event Press 'GO-TO': a circle encloses the Event symbol. -
Page 76: More About A-B-C-D Function
lected Event is connected to the current Route. The same Event can be added in many Routes. Note An existing Event can be connected to the current Route in another mode too. Place cursor on Event, the information window related to the Event appears, press 'CLEAR' to close the window and then press 'ENTER', select the Waypoint option and press 'ENTER'. -
Page 77: Moving The A-B-C-D Points
4.3.4 MOVING THE A-B-C-D POINTS When placing the cursor on the desired point (A, B, C or D) the information window appears. Press 'ENTER', select "MOVE" and press 'ENTER': by the cursor key move the cursor, on the screen a dotted line connecting the point to move with the new position appears. -
Page 78: Displaying Track
4.4.3 DISPLAYING TRACK 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER' + "VISIBILE" + 'ENTER' To enable (On) or disable (Off) the displaying of track. The default setting is On. 4.4.4 SELECTING TRACK COLOR 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER' + "COLOR"... -
Page 79: Selecting Time
4.4.9 SELECTING TIME 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER' + "TIME" + 'ENTER' When the tracking function is On and the type of track storing is Time, the chart plotter can store a fix after a defined time. Choose among 1, 5, 10, 30 sec, 1, 5, 10 min. -
Page 80: Formatting User C-Card
your User C-CARD. Remember that this option permanently erases the file. 4.5.4 FORMATTING USER C-CARD 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "USER C-CARD" + 'ENTER' + "FORMAT" + 'ENTER' A warning window is shown, select "YES" and press 'ENTER' to confirm the formatting (select "NO"... -
Page 81: Operations
Destination ID & Position, Next Waypoint ID & Position, Total Route length, Fuel Consumption Rate, ETA, TTG etc.) between two chart plotters linked through the C-Link system. The chart plotters can be set to operate in two modes: MASTER mode (Primary chart plotter that sends data) •... -
Page 82: C-Link Serial Connection
C-Link Navigation Data can refer to: Single Destination navigation • Route Following navigation. • Values identified by * are sent only for Route Following navigation. The Destination Icon, Navigation leg (Fix Position to Destination), the Next Waypoint Icon and all other relevant C-Link Navigation Data will be shown on the Slave chart plotter. -
Page 83: C-Link Navigation Data: Acquisition And Display
Stop current navigation If the navigation was already active, it will be disabled as soon as Slave mode is set. An appropriate warning message will be shown to notify that the navigation is already active and to confirm whether Slave mode can be set. Inhibit navigation operation As soon as Slave mode is set, the destination cannot be placed anymore either the C-Link Navigation Data is received from the Master or not. -
Page 84: Graphical Representation On Map Display
4.7.1.6 Graphical representation on Map Display Fig. 4.7.1.6 - Graphical Displaying 4.7.1.7 Route Data Report When the navigation to the External Route is received, it will be possible to display the information related to the External Route by entering the Route Data Report. Fig. -
Page 85: Quick Info
Distance to Last Wpt : distance to travel from ship to the end of the Route • (calculated: Distance to Dest +Distance from Dest to last Wpt received from PCMPN,1) TTG To Destination : estimated time to travel the “Distance to Last Wpt”. •... - Page 86 User Manual...
-
Page 87: Advanced Settings
Advanced Settings The Advanced Settings menu allows to handle the chart plotter functions. The menu options are arranged in sub-menus. For example, all options that relate to the Fix functions are in Fix sub-menu. See Par. 3.5 for informations about Map Setting menu, see Par. -
Page 88: Wind Speed
MM-YY (day-month-year). The default setting is MM-DD-YY. 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "SETUP" + 'ENTER' + "DATE FORMAT" + 'ENTER' 5.1.4 WIND SPEED Selects the Wind Speed unit among Kts = Knots, m/s and Kmh = kilome- ters per hour. The default setting is Kts. 'MENU' + "ADVANCED SETTINGS"... -
Page 89: Compute Correction
rection is calculated, but the Correction is not enabled, the ship's position is not changed. The default setting is Off. 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "FIX" + 'ENTER' + "FIX CORRECTION" + 'ENTER' 5.2.2 COMPUTE CORRECTION Corrects fixes from the positioning instrument. By placing the cursor on the ship's real position and selecting this option, the error is calculated and internally memorized for appropriate correction, but not applied. -
Page 90: Static Navigation
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "FIX" + 'ENTER' + "DEAD RECKONING" + 'ENTER' 5.2.8 STATIC NAVIGATION Sets up a threshold for the speed. When the speed received from the position- ing device is under that threshold, the chart plotter displays zero speed. The default value is 0.0 Knots. -
Page 91: Map Orientation Resolution
5.3.4 MAP ORIENTATION RESOLUTION Selects the orientation of your chart according to your personal needs (see Par. 3.5.1.3 for more information). The Orientation Resolution is the resolution angle for the Map Orientation, range [5°, 60°]. The default setting is 30°. 'MENU' + "ADVANCED SETTINGS"... -
Page 92: Bearings
5.4.1 BEARINGS Selects either degrees Auto Magnetic or True. If magnetic readings are se- lected the variation is computed automatically for every zone as soon as the chart is displayed. The default setting is Mag. 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "COMPASS" + 'ENTER' + "BEARINGS"... -
Page 93: Xte Alarm
5.5.2 XTE ALARM Disables (Off) or specifies the distance your Cross Track Error (XTE) can vary before the sound of an alarm or disables the XTE Alarm (Off). The default setting is Off. 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "ALARMS" + 'ENTER' + "XTE ALARM"... -
Page 94: Grounding Alarm Range
the Grounding Alarm has been activated, a warning message is shown. 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "ALARMS" + 'ENTER' + "GROUNDING ALARM" + 'ENTER' Note The Grounding Alarm function only operates with the new C-CARDs. It also affects the speed of the redraw of the screen. -
Page 95: Speed
5.6.2 SPEED To start the simulator you can insert the Speed value. Using the cursor key select the preferred Speed and press 'ENTER'. The default setting is 01.0 Kts. 'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "SIMULATION" + 'ENTER' + "SPEED"... -
Page 96: Ais System Definitions
giving the skipper or navigator a visual interpretation of the data of nearby vessels. This improves safety, and specifically for collision avoidance reasons. 5.7.1 AIS SYSTEM DEFINITIONS Target • It is a vessel equipped with AIS. Information about the targets is being re- ceived by AIS Receiver and displayed on the screen. -
Page 97: Ais Menu
Dangerous Target • Target detected by CPA or TCPA Alarm. Dangerous target is Active Target by definition. For better visibility Dangerous Target symbol is flashing. Sleeping Target • Target located outside the Activation Range. Sleeping target is represented by a small oriented triangle. Lost Target •... -
Page 98: Activation Range
5.7.2.2 Activation range 'MENU' + "AIS SETUP" + 'ENTER' + "ACTIVATION RANGE" + 'ENTER' Defines the range from the fix within which the AIS Target becomes active. The values allowed are from 0.1 to 20 Nm. The default setting is 5 Nm. 5.7.2.3 CPA Alarm 'MENU' + "AIS SETUP"... -
Page 99: C-Staff
• CPA and TCPA values • Note The selected AIS target icon is surrounded by a square frame when user places the cursor over the icon. 5.8 C-STAFF The C-Staff functions are based on STAFF Concept ® (Satellite Tracking Aided Fleet Fishing). The STAFF Concept ® is designed for professional fishing purpose to allow monitoring the position of the vessels of a fleet from each vessel (the fleet may have until 20 vessels max). -
Page 100: C-Weather Service Menu
5.9.1 C-WEATHER SERVICE MENU To select the menu: 'MENU' + "C-WEATHER" + 'ENTER' The C-Weather menu is shown on the screen, the items are described in the following paragraphs. 5.9.1.1 Download 'MENU' + "C-WEATHER" + 'ENTER' + "DOWNLOAD" + 'ENTER' Allows to connect the software to the Jeppesen Marine weather server and to download weather data directly via C-COM. -
Page 101: Weather Forecast
5.9.1.3 Weather Forecast 'MENU' + "C-WEATHER" + 'ENTER' + "FORECAST" + 'ENTER' Allows selecting the Layer of specific weather data to be displayed on the screen and to change date and time of the forecast preview. The following functions are available: Panning •... -
Page 102: 1Distress Call And Position Request
The Distress Call, that allows to receive a position of the vessel in distress, and the Position Request, a great feature for anyone wanting to know the location of another vessel - for example you buddy that is catching fish, or finding the location of a person you are cruising with, are performed by an external device, the DSC VHF radio. -
Page 103: 2Dsc Menu
Stay on View • Exits the pop-up screen and remains on the selected map screen. 5.10.2 DSC MENU To select the DSC menu: 'MENU' + "DSC" + 'ENTER' The DSC menu is shown on the screen, the items are described in the following paragraphs. -
Page 104: Dsc Directory
Hide/Show 'MENU' + "DSC" + 'ENTER' + "LOG" + 'ENTER' + "HIDE/SHOW" + 'ENTER' Allows hiding/showing the selected DSC position on the chart display. Position Request/Distress Call 'MENU' + "DSC" + 'ENTER' + "LOG" + 'ENTER' + "POSITION REQUEST/ DISTRESS CALL" + 'ENTER' Shows Position Request/Distress Call page. -
Page 105: 3Quick Info On Dsc Icons
Delete All 'MENU' + "DSC" + 'ENTER' + "DIRECTORY" + 'ENTER' + "DELETE ALL" + 'ENTER' Deletes all entries in the page. 5.10.3 QUICK INFO ON DSC ICONS Placing the cursor on the Distress Call or Position Request icon, the following information is displayed: Vessel Name/MMSI Number •... -
Page 106: 2Mobilarm Status
5.11.2 MOBILARM STATUS If you want to know information about the MOBILARM connected, follow the procedure: 'MENU' + "About" + 'ENTER' 2008 JEPPESEN Italia S.r.l. XXXX V. X.yy [GG/MM/YYYY] MOBILARM Connected Fig. 5.11.2 - Example of About Page In the About Page a new item appears, related to MOBILARM status, where status can be: Function Not Activated : MOBILARM input format has not been set... -
Page 107: Ptx Is Received
5.11.3.1 PTX is received When a PTX has beeen received, the PTX data are saved on the chart plotter memory and the PTX icon appears on the map: Fig. 5.11.3.1 - PTX icon All menus and/or pages are closed and the chart is centered on the PTX received position. -
Page 108: 4Moving Cursor On The Ptx Icon
5.11.4 MOVING CURSOR ON THE PTX ICON Placing the cursor on the PTX icon shown on the screen, an information window containing the PTX Identifier, position and status (Overboard or Recovered) appears: MOBILARM - PTX OVERBOARD 41°16.552N 009°25.514E Time 000001A0 11:25:15 PM Fig. -
Page 109: Show Ptx
PTX indentifier PTX status MOBILARM-Alarm Status List RECOVERED 00000001 12:45:08 AM 118°10.040W 33°26.080N Recovered 00000002 03:45:14 PM 213°22.120W 20°01.022N 00000003 10:31:24 PM 305°04.015W 79°56.320N Recovered PTX position Time of PTX creation GOTO DELETE SHOW SHOW ALL Fig. 5.11.4.3 - Example of MOBILARM PTX List page This page allows you to: Goto Activates navigation to the selected PTX. -
Page 110: Radar Setup Menu
'ECHO' then from the Fish Finderpage it is possible to open the Fish Finder: 'ECHO' for 1 second For more information see the specific User Manual. Note The Fish Finder display page is available only if the Fish Finder is connected and powered On. 5.13 RADAR SETUP MENU The Radar consists of a scanner unit which illuminates targets with micro- wave energy and then collects the echoes from those targets. -
Page 111: Fish Finder F
Fish Finder 8 HD F & C 8 HD F ANORAMIC OMPACT The Fish Finder consists of a high power transmitter, sensitive receiver and a transducer. The Fish Finder sends an electrical pulse to the transducer which contains an element that converts the pulse into acoustic (sound) wave which is sent through the water. -
Page 112: Setting The Internal Fish Finder On
6.1 SETTING THE INTERNAL FISH FINDER ON The internal Fish Finder driver is connected directly to the dedicated serial Port2. To switch the internal Fish Finder transmission On follow the procedure: 'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' + "FISH FINDER"... - Page 113 items on the right side of the screen are closer to you than those on the left. The correct interpretation of the Echogram allows retrieving useful information about what is under the boat. See the following Par. 6.2.2 for more information. Color Bar Colored scale located on the left side of the screen that shows the colors used in the Echogram to represent the echoes strength.
-
Page 114: Understanding The Echogram Display
Operating Frequency Readout of the selected operating frequency. 6.2.1 UNDERSTANDING THE ECHOGRAM DISPLAY The main elements that can be easily distinguished into an Echogram are: Fig. 6.2.1 - The Fish Finder echogram Fishes Fishes are represented as arcs because of the cone angle of the transducer. In fact as the boat passes over the fish the leading edge of the cone strikes the fish, causing a display pixel to be turned on. -
Page 115: Displaying The Fish Finder Page
Surface Clutter Appears like noise at the top of the screen extending many feet below the surface. It’s caused by many things, including air bubbles, bait fish, plankton and algae. Structures Generally, the term “structure” is used to identify objects like wrecks and weeds rising from the bottom. -
Page 116: Fish Finder Full Page
Note It is possible to select immediately any Fish Finder by using 'ECHO', the pages are shown wrap around. 6.3.2 FISH FINDER FULL PAGE To display the Fish Finder Full Page Echogram, follow this procedure: 'PAGE' + use cursor to select the Fish Finder Full Screen page + 'ENTER' Fig. -
Page 117: Dual Frequency Page
The CLEAR key By pressing 'CLEAR' the Variable Depth Marker (VDM) is hidden. The ZOOM IN and ZOOM OUT keys From this page pressing 'ZOOM IN' once changes to Zoom 2X, pressing 'ZOOM IN' twice changes to Zoom 4X, while pressing 'ZOOM OUT' reverts to Zoom 2X and no zoom. -
Page 118: Chart/Fish Page
Fig. 6.3.4 - The Fish Finder Zoom The Depth Cursor is shown only on the unzoomed Fish Finder Echogram. The ZOOM IN and ZOOM OUT keys When in this page pressing 'ZOOM IN' changes to Zoom 4X, pressing 'ZOOM OUT' changes to Zoom 2X. 6.3.5 CHART/FISH PAGE To display the Chart page on the left half of the screen and the Fish Finder Echogram on the right half of the screen, follow this procedure:... -
Page 119: Fish Finder And Radar
Note When focus is on the Chart page, all keys work in cartography standard mode. 6.3.6 FISH FINDER AND RADAR PAGES To display the Radar page on the left half of the screen and the Fish Finder Echogram on the right half of the screen, follow this procedure: 'PAGE' + use cursor to select the Radar/Fish Finder page + 'ENTER' Fig. -
Page 120: Zoom Modes
6.4 ZOOM MODES 6.4.1 THE BOTTOM LOCK ZOOM The Bottom Lock Zoom mode is activated when the Fish Finder is in Auto Range or Bottom Lock mode (see Par. 6.6.3) and the Variable Depth Marker (VDM) is not displayed on the screen. In Bottom Lock Zoom mode the Fish Finder Echogram is automatically moved up/down as to keep the Bottom Line always visible in the lower half of the screen. -
Page 121: Preset Mode
Fig. 6.5 - The Fish Finder Setup menu 6.5.1 PRESET MODE Preset modes are pre-defined settings of the Fish Finder operating parameters. You can use them to quickly set the Fish Finder in the most commonly used operating modes. These are Cruise (sets the Fish Finder in full auto mode with the sensitivity settings optimized for displaying at best the bottom) and Fish (sets the Fish Finder in full auto mode with the sensitivity setting optimized for target searching). -
Page 122: Bottom Range
Lock Mode the Fish Finder automatically tracks the range around the bottom specified by the Bottom Range value. 'MENU' + "RANGE MODE" + 'ENTER' 6.5.4 BOTTOM RANGE Shows the max depth to reach. This option is available when Range Mode is Bottom Lock. -
Page 123: Gain
Note The Frequency value is only displayed: to select the desired frequency see the previous Par. 6.5.7. 6.5.9.2 Gain Allows you to control the Gain of the unit's receiver. To see more details on the screen, increase the receiver sensitivity by selecting a higher gain percentage. If there is too much detail or if the screen is cluttered, lowering the sensitivity may increase the clarity of the display. -
Page 124: Scrolling Speed
6.5.10.2 Scrolling Speed Adjusts the chart scrolling rate. Note that the scrolling rate is limited by the sound speed and the depth according with the following relation: the deeper the setting, the slower the scrolling rate. 100% is the maximum possible. 6.5.10.3 White Line Controls how the chart plotter displays information about the bottom type... -
Page 125: Calibrate Water Speed
6.5.11.3 Calibrate Water Speed Allows calibrating the value of Water Speed sensor. The calibration value, in the range between -10% to +10%, will be applied to the water speed from the transducer. 6.5.11.4 Calibrate Water Temperature Allows the calibration on the Water Temperature sensor. Using the readings from a precise temperature measuring device, insert here a positive/negative offset to display right value on Fish Finder screens. -
Page 126: Temp Rate
6.5.12.5 Temp Rate Triggers an alarm when the transducer reports a temperature (from TEMP 1 sensor) variation rate above the value set. 6.5.12.6 Fish Alarm The options for Fish Alarm set the size of the fishes that, if detected by the unit, switches an alarm to sound. -
Page 127: Dedicated Available Transducers
6.6.1 DEDICATED AVAILABLE TRANSDUCERS AIRMAR # Model Designation Housing Mount Funct. Power 31-492-1-01 P58 Transom Mount Plastic Transom D/S/T 600W 31-680-1-01 P66 Hi Performance Plastic Transom D/S/T 600W 31-494-2-01 P79 Plastic Plastic In-hull 600W 31-495-2-01 P319 Plastic Plastic Thru-hull 600W 31-658-2-02 B744V W/ Hi Performance Fairing Bronze... - Page 128 User Manual...
-
Page 129: For The Technician
For the Technician 7.1 DIMENSIONS 87,5 [7.3”] GRAY parts are present ONLY on chart plotter 67 [2.64”] 241 [9,5”] WITH GPS INTERNAL 159,8 [6.3”] 241 [9,5”] 115 [4,5”] Fig. 7.1 - P 8 XL/HD & C 8 XL/HD ANORAMIC OMPACT Fig. -
Page 130: Installation And Removing
7.2 INSTALLATION AND REMOVING GRAY parts are present ONLY on chart plotter WITH GPS INTERNAL Fig. 7.2 - P 8 XL/HD & C 8 XL/HD ANORAMIC OMPACT Fig. 7.2a - P 8 HD F & C 8 HD F ANORAMIC OMPACT User Manual... -
Page 131: External Wiring
7.3 EXTERNAL WIRING GRAY parts are present ONLY on chart plotter WITH GPS INTERNAL VIDEO INPUT (**) 1=GND COMMON CAM CONNECTORS 2=POWER+ (10-35Vdc) PIN-OUT 3=SIGNAL (ON UNIT) AUX-IN I/O CABLE (**) WIRE COLOR FUNCTION BLACK GND COMMON QUICK DISCONNECT BRACKET CABLE POWER OUTPUT+ (10-35 Vdc) WHITE INPUT 4+... -
Page 132: Typical Connections
BEACON POWER +10-35 Vdc RECEIVER BROWN GPS NMEA0183 OUTPUT+ FUNCTION GREEN GPS NMEA0183 INPUT+ WHITE RTCM 104 INPUT+ RTCM 104 OUTPUT+ BLACK/YELLOW/SHIELD GND/SIGNAL RETURN SIGNAL RETURN Fig. 7.4 - GPS Connection on Port 3 for PANORAMIC 8 XL/HD User Manual... - Page 133 Fig. 7.4a - GPS Connection on Port 3 F 8 HD F ANORAMIC QUICK DISCONNECT BRACKET CABLE WIRE COLOR DESCRIPTION FUNCTION BLACK POWER GND POWER SUPPLY GND POWER +10-35Vdc POWER SUPPLY+ WHITE INPUT1+ NMEA0183/C-COM GREEN SIGNAL RETURN- SIGNAL RETURN YELLOW OUTPUT1+ NMEA0183/180/180CDX/C-COM BROWN...
-
Page 134: Or Panoramic & Compact 8 Hd Fish
Fig. 7.4d - Autopilot Connection on Port 1 F 8 HD F OMPACT QUICK DISCONNECT BRACKET CABLE WIRE COLOR DESCRIPTION FUNCTION BLACK POWER GND POWER SUPPLY GND NMEA0183 POWER +10-35Vdc POWER SUPPLY+ DEVICE WHITE INPUT1+ NMEA0183/C-COM FUNCTION GREEN SIGNAL RETURN- SIGNAL RETURN YELLOW OUTPUT1+... -
Page 135: Troubleshooting
C-COM TX- YELLOW YELLOW OUTPUT1+ C-COM C-COM RX+ Fig. 7.4d - C-COM Connection on Port 1 for PANORAMIC 8 XL/HD 4 AUX IN I/O WITH CONNECTOR BUSY for PANORAMIC 8 HD F 7.5 TROUBLESHOOTING The following is a brief guide to some of the problems you may experience while using the chart plotter with common solutions. -
Page 136: Quick Reference Guide
7.5.2 QUICK REFERENCE GUIDE It is available an help on line to explain as the chart plotter works: 'MENU' + "HELP" + 'ENTER' Using 'ZOOM IN' and 'ZOOM OUT' select previous and next page respectly. 7.5.3 IF YOU NEED ASSISTANCE The list above should allow you to solve most of the operating problems you are likely to encounter. -
Page 137: Ram Menu
problems with your chart plotter, the extended auto-test should help determine the problem. Make sure the chart plotter is turned Off. While pressing and holding any other key, turn the chart plotter On. A new menu will appear on the display: Software name XXXX V. -
Page 138: Cartridges
instead of to left it will increase brightness. Backlight To set the backlight. Operates in similar mode as Contrast. 7.6.3 CARTRIDGES To check the C-CARD and its connector. Background ROM To test the WorldWideBackground. If there is not a malfunction, the code of the Background and the message "OK"... -
Page 139: Modem Test
If the data displayed on the screen is unrecognizable, you may have selected the wrong input parameters for your particular receiver. Check your receiver manual to be sure that you have selected the proper interface format. If the screen is blank, you may have a broken connection and no data is being received. - Page 140 User Manual...
-
Page 141: Terms
Terms This section explains the terms that may be unfamiliar to the reader. Advanced Mode The chart plotter can operate in two different modes: Basic Mode and Advanced Mode. In Advanced Mode it is possible to have more available functions, for example it is possible to handle Waypoints. AIS = Automatic Identification System It has been introduced to improve the safety of navigation by assisting in the efficient operation of ship- to ship, ship reporting and VTS applications. - Page 142 BRG = Bearing Angle between the North (True or Magnetic) and a destination. It represents the direction to follow. Chain Selects the preferred chain. The Loran chains are groups of transmitting stations that use timed radio pulse transmissions. In each of these chains there is a master station and two or more slave or secondary stations. Stations belonging to a same chain transmit pulses in timing groups: a different time base identifies each chain.
- Page 143 Depth Lines Imaginary lines connecting points of equal water depth. DGPS = Differential GPS Provides even greater positioning accuracy than standard GPS. DSC = Digital Selective Calling Method of establishing a VHF radio call; it is used to announce urgent maritime safety information broadcasts.
- Page 144 MOBILARM Automated crew monitoring system dedicated to monitoring onboard crew by maintaining a constant link between the crew member and the boat. The instant a man over-board event happens, an automatic alarm is sounded, and the vessels position is logged. Natural Features Any topographic feature formed by the action of natural processes: coastlines, relief, glaciers, ..
- Page 145 Speed Current velocity at which you are travelling, relative to a ground location. Spot Sounding Depth of the water in a specific and charted position STR = Steering Difference between COG and CTS. If COG is 25° and CTS is 30°, then STR is 5° Right. Target In order to tag on the chart the point, towards which the ship is Heading, you can use a special mark, called Target.
- Page 146 0 to 0.1 kn Yellow 0.2 to 1.0 kn - Yellow 1.1 to 2.0 kn - Orange 2.1 to 3.0 kn - Orange 3.1 to 9.9 kn - Fig. A.1b - Tides & Currents table When the chart plotter receives a valid position fix, the Tide icons are shown on the charts on the basis of the current date and time: the screen displays and changes arrows as date/time changes.
- Page 147 WGS-84 = World Geodetic System 1984 Coordinates System or Datum developed by the Defense Mapping Agency (DMA). Zoom-In Shows more detail in a smaller area. Zoom-Out Operates similarly to zoom -in, but in the reverse, showing a wider but less detailed view. XTE = Cross Track Error Distance from the ship's present position to the closest point on a line between the origin and destinations Waypoints of the navigation leg being traveled.
- Page 148 User Manual...
-
Page 149: Smart Dgps Waas Receiver
Smart DGPS WAAS Receiver B.1 INSTALLING Choose a location for the antenna that has a clear view of the sky. Ensure there are no major obstructions or fixtures in the immediate proximity to the an- tenna. The antenna relies on direct “line of sight” satellite reception. If you are un- sure that the chosen location is suitable it may be advisable to mount the antenna in a temporary manner to verify correct operation. -
Page 150: Dimensions
2. Then, following template instruction, drill a 1" (25mm) hole and three 0.13" (3.2mm) holes. Fig.B.1a - Installing GPS Antenna (II) 3. Remove the template and let the cable go through the central hole. 4. Apply a small coat of RTV to the underside of the antenna. 5. -
Page 151: Analytical Index
Analytical Index 3D Navigation Data ......16 Background Charts ......138 Background ROM ....... 140 A-B-C-D Function ....16, 43, 78 BACKLIGHT ......... 21 A-B-C-D points ........22 backlight ......21, 23, 31, 139 A-Scope ........18, 115 Backlight Timeout ......... 90 About Page ........ - Page 152 cartridges ..........29 Data Bits ..........140 Caution Notice pages ......23 Data Entry ..........31 Chain ..........92, 144 Data Features ........45 Changing Fuel ........72 Data Safety Indicator ......49 Changing Speed ........72 data storage cartridge ......29 Chart - Fish Finder .......
- Page 153 Distress Call ........104 Fish Finder transmission ....114 DSC ........16, 103, 145 Fish Finder Zoom ......16, 120 DSC Directory ........106 Fish Symbols ........126 DSC Menu .......... 105 Fishes ..........116 DSI ............49 Fix ............90 Dual Frequency page ......
- Page 154 Info Function ......... 58 Mark ... 22, 29, 41, 74, 76, 77, 90, 145 info on Event ......... 77 Marker Zoom ........122 Info on Lakes ........56 Master ........... 84 info on Mark .......... 76 MAX ............45 info on Route ........71 Max Depth ..........
- Page 155 Off-line redraw ........46 Radar ........16, 42, 112 Official data source ....... 45 Radar pages ......... 22 Operating Frequency ......116 RAM Clear ......... 138, 139 opto-isolated ........... 4 RAM Test ..........139 Orientation Resolution ......93 Range ..........123 OSGB ........
- Page 156 Selecting destination ......65 Tide & Currents ..... 15, 45, 52, 147 Selecting distance ........ 80 Tide Graph ..........59 Selecting Route ......70, 71 Tide Info ........58, 147 Selecting time ........81 Tide Stations ......... 60 Selecting track Color ......80 Tides Preview ........
- Page 157 voltage ......... 23, 137 WPL ............72 VTG ............40 Wrecks ........... 54, 60 WAAS ......... 41, 146, 151 XTE ........ 34, 40, 95, 149 Warning Message ......114 XTE Alarm ........17, 95 Water Temperature ....115, 126 Waypoint ..22, 29, 63, 71, 76, 77, 83, 90, 146 Zoom ......
