Electristove Hologram Genesis Electric Stove
Electristove Hologram Genesis - B-1033765 - ESEHG0RE
Packing Checklist - Pack 1 of 1
Electric Stove
Remote Control Handset* with wall mounting bracket
Log Set
Instruction Manual
*THIS PRODUCT REQUIRES 3 X AAA BATTERIES FOR USE IN THE HANDSET (NOT SUPPLIED)
IMPORTANT
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE
INSTALLATION AND USE OF THIS ELECTRIC STOVE AND
RETAIN FOR FUTURE REFERENCE.
Children of less than 3 years should be kept away unless continuously supervised.
Children aged from 3 years and less than 8 years shall only switch on/off the stove
provided that it has been placed or installed in its intended normal operating position and
they have been given supervision or instruction concerning use of the stove in a safe
way and understand the hazards involved. Children aged from 3 years and less than 8
years shall not plug in, regulate and clean the stove or perform user
maintenance.
This stove is not intended for use by persons (including children) with reduced
physical, sensory or learning disabilities, or lack of experience and knowledge, unless
given supervision or instruction concerning use of.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
Advertisement
Table of Contents
Related Manuals for Celsi B-1033765
Summary of Contents for Celsi B-1033765
- Page 1 Electristove Hologram Genesis Electric Stove Electristove Hologram Genesis - B-1033765 - ESEHG0RE Packing Checklist - Pack 1 of 1 Electric Stove Remote Control Handset* with wall mounting bracket Log Set Instruction Manual *THIS PRODUCT REQUIRES 3 X AAA BATTERIES FOR USE IN THE HANDSET (NOT SUPPLIED)
- Page 2 IMPORTANT SAFETY ADVICE WHEN USING AN ELECTRICAL STOVE, BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSONS, INCLUDING THE FOLLOWING IMPORTANT SAFETY ADVICE. DO NOT cover the heater, to avoid overheating of the product. DO NOT leave the heater unattended while it is in use.
- Page 3 PRODUCT TECHNICAL DATA SHEET Supplier Name / Trademark Celsi Supplier Model Identifier B-1033765 Electristove Hologram Genesis Voltage 230v AC 50HZ Fuse 13 Amp Nominal Heat Output (Measured) 2.0kW Minimum Heat Output (Indicative) 1.0kW Maximum Continuous Heat Output 2.0kW Auxilliary Electrical Consumption...
-
Page 4: Choosing A Suitable Location
Unpacking Remove and discard the plastic bag. Be responsible when handling the packing materials. Keep the original packaging for future transportation and/or storage. Check all accessories are removed from the packaging before storing it away for future use. KEEP PLASTIC BAGS AWAY FROM CHILDREN! Choosing a Suitable Location The stove must have a minimum clearance of 15mm to combustible material on all sides. - Page 5 Fitting the Logs Take care when unpacking the Logs supplied with your stove. Open the door on the stove then remove the top panel via the two screws at the front and the screws at the rear as indicated below in figure 2 & 3. Fig.
- Page 6 Fig. 4 Front LED strip retaining screws Remove the screws as indicated to allow the fuel-bed log set to be fitted, carefully relocate the LED strip temporarily towards the rear of the stove to allow access to fit the fuel-bed matrix and 2 off loose logs as shown below in figure 5 & 6, this will provide the layout from the front view as displayed in figure 7 below.
-
Page 7: Operating The Stove
Manual Control using the controls on the stove Remote Control using the included remote-control handset Celsi App Control voice control using Alexa or Google Assistant Manual Control This stove can be operated manually using the control panel as shown below in figure 8. -
Page 8: Remote Control
Remote Control Remove the battery cover on the rear and insert 3 x AAA batteries ensuring the batteries are fitted correctly. Refit the cover. Please ensure old batteries are disposed of responsibly by contacting your local authority about recycling schemes. Ensure that the ON / OFF Power Switch on the stove is in the ON position. -
Page 9: Clock Setting
o use the remote handset ensure it is pointed directly towards the stove and press the appropriate button to operate the stove. Operating the Stove and Child Lock mode Use the On/Off button to switch the stove On and Off. Holding the button in for 5 seconds will enable the Child Lock mode (a padlock will appear on the handset display). -
Page 10: Adaptive Mode
Celsi App Control The Celsi app can be downloaded from the IOS App Store or the Google Play Store by either searching for Celsi or by scanning the QR code using a smart phone or tablet. Page 9 of 18... -
Page 11: App Setup
The Celsi app can be used alongside the remote handset and provides additional feature of 7 day Timer function. ** During the initial set up of the App, the fire needs to be in pairing mode ** Pairing Mode With the stove off and in Standby mode press and hold the Standby button on the fire to hear a beep and continue holding for 5 seconds to observe a red flashing light on the rear screen. - Page 12 Connection to Alexa Once you have set up your Celsi account and successfully paired your device you can now also connect to Alexa. Fig. 11 Fig. 12 To connect, open the Alexa App and select the “More” tab in the bottom right hand corner as shown in figure 11 above.
- Page 13 Then click the “search” icon in the top right hand corner as shown below in figure 13, then search for the “smart life” skill by typing “smart life” into the search box as shown below in figure 14. Fig. 13 Fig.
- Page 14 This will prompt you for your e-mail address and password that you used when registering the Celsi APP as shown below, enter the e-mail address and tick the user agreement box as indicated below in figure 17. Complete the verification puzzle as prompted, then enter your password and complete a second verification puzzle as requested.
- Page 15 Connection to Google Assistant Once you have set up your Celsi account and successfully paired your device you can now also connect to Google Assistant. Fig. 19 Fig. 20 To connect, open the Google Assistant App and select the “Device” tab on the left hand side as shown above in figure 19, then click the “add devices”...
- Page 16 Select the “link a smart home device” tab as indicated below in figure 21 Fig. 21 Fig. 22 Click the “search” icon in the top right hand corner as shown figure 22 above, then enter “smart life” as the searched for as shown in figure 23. Select the “smart life icon as shown in figure 24 below.
- Page 17 This will prompt you for your e-mail address and password that you used when registering the Celsi APP as shown below, enter the e-mail address and tick the user agreement box as indicated below in figure 25. Fig. 25 The product should then operate from voice activation, open the google assistant app, click then click the microphone logo at the bottom centre and give instruction i.e.
-
Page 18: Maintenance Instructions
IMPORTANT This stove is fitted with an automatic thermal cut-out safety feature to reduce the risk of damage to stove due to overheating. If the stove overheats the heater element will cut out whilst the fan will still continue to run to allow the fire to cool down sufficiently. Once the stove has cooled down the thermal cut-out will reset itself and switch the heater back on. -
Page 19: Warranty
Warranty Congratulations on the purchase of your electric stove. This stove by BFM Europe Ltd is guaranteed for 5 years from the date of purchase against faulty materials or workmanship. Please note the 5 year guarantee comprises of 24 months of parts and labour with an extended 36 months of parts only.
