  • Page 1 Operator's Manual N2 Series Versu...
  • Page 2 Find manuals at https://best-manuals.com...

  • Page 3: About This Manual

    About this manual This operator's manual is for Valtra N2 Series Versu tractors. The N2 Versu models are N122 V and N142 V. The manual is meant for agricultural tractors only. If the tractor is used for other applications, it is the owner's responsibility to ensure compliance with local regulations.

  • Page 4: Tractor Serial Numbers

    Tractor serial numbers When ordering spare parts or service, give the model indication and serial numbers and, in some cases, the engine, front axle, cab and transmission numbers. N142 V AC15.2 V12140 GUID-CC7D465F-65A4-4155-85EE-FB823433D27F 1. Type plate EEC • Model = model indication used by service/spare part department •...

  • Page 5: Table Of Contents

    2.11.2 Automatic air conditioning controls ..............39 2.12 Driver's seat.......................40 2.13 Air suspended driver's seat ................41 2.14 Valtra Evolution driver's seat................42 2.15 Controls on the rear mudguard................43 2.16 Controls on the bonnet..................43 2.17 Rear controls and connections outside the cab..........44 - 3 -...
  • Page 6 Running the tractor in..................45 Preparing for use....................45 3.2.1 Adjusting the driver's seat................45 3.2.2 Adjusting the air-suspended driver's seat............47 3.2.3 Adjusting the Valtra Evolution driver's seat............50 3.2.4 Adjusting the right-side armrest................54 3.2.5 Adjusting the steering wheel................55 3.2.6 Adjusting standard mirrors................56 3.2.7 Adjusting optional mirrors.................56...
  • Page 7 Contents 3.8.4 Adjusting the power shuttle engagement speed ..........86 3.8.5 Using the parking brake...................86 3.8.6 Using the clutch pedal..................88 3.8.7 Adjusting the clutch pedal engagement position..........89 3.8.8 Braking......................90 3.8.9 Using the emergency brake................90 3.8.10 Starting to drive....................91 3.8.11 Transmission system..................92 3.8.11.1 Speed matching................92 3.8.11.2...
  • Page 8 Contents 3.9.7 Changing parameters..................125 3.9.7.1 Activating and exiting the setting mode........125 3.9.7.2 Changing the parameter value..........126 3.9.7.3 Setting the display backlight level..........126 3.9.7.4 Setting the implement width............127 3.9.7.5 Changing the hour display............127 3.9.7.6 Changing the minute display............127 3.9.7.7 Changing the clock mode............128 3.9.7.8 Activating the direction indicator buzzer........128 3.9.7.9...
  • Page 9 Connecting an external hydraulic motor to the auxiliary hydraulics....188 3.15 Using the front linkage..................189 3.15.1 Setting front linkage lifting link positions............190 3.16 Using the Valtra front loader................191 3.16.1 Using the Valtra Quick front loader coupling plate.........192 3.16.2 Softdrive......................193 3.16.3 Locking the equipment...................193 3.16.4 Controlling the extra cylinder with the change valve........194...
  • Page 10 Cleaning polycarbonate windows..........245 Recommended fuel and lubricants..............246 4.4.1 Fuel........................246 4.4.1.1 Quality requirements for engine fuel.........246 4.4.1.2 Storing fuel................246 4.4.1.3 Fuel filter system...............247 4.4.1.4 Biodiesel fuel................247 4.4.2 Grease......................247 4.4.2.1 Valtra Grease - NLGI2 universal grease........248 - 8 - Find manuals at https://best-manuals.com...
  • Page 11 Contents 4.4.2.2 Valtra Calsium LF - NLGI2 calsium grease LF......248 4.4.2.3 Valtra Grease Moly - NLGI2 moly grease.........248 Storing the tractor....................248 4.5.1 Storing the tractor for a period shorter than two months........248 4.5.2 Storing the tractor for a period longer than two months.........249 Running the tractor in after storage..............249...
  • Page 12 Contents 4.7.5.1 Changing oil in the hydraulic system........283 4.7.5.2 Changing oil in the front axle differential........285 4.7.5.3 Changing oil in the front axle hubs...........287 4.7.5.4 Changing the cab ventilation air filter........287 4.7.5.5 Changing the recirculation filter..........288 4.7.5.6 Changing the fuel filter..............288 4.7.5.7 Changing the fuel prefilter............289 4.7.5.8...
  • Page 13 Contents 5 Faults and remedial actions...............328 Handling error situations..................328 Errors indicated by the indicator lights.............328 5.2.1 Cleaning the main engine air filter..............329 5.2.2 Identifying a blocked transmission or hydraulic system filter......330 Warning symbols on the Proline instrument panel display......332 5.3.1 Low fuel pressure warning................332 5.3.2 Hydraulic oil temperature warning..............333...
  • Page 14 Contents 6.13 Hydraulic system....................353 6.13.1 Low pressure circuit..................353 6.13.2 Steering hydraulic circuit................353 6.13.3 Working hydraulic circuit................353 6.13.3.1 Valves for auxiliary hydraulics..........354 6.13.3.2 Counter pressure when using the return connection for auxiliary hydraulics..............354 6.13.4 Rear linkage....................355 6.13.4.1 Maximum lifting force on the whole lifting area......355 6.13.4.2 Lifting range at the end of the lower links.........355 6.13.5...

  • Page 15: Safety Precautions

    1. Safety precautions Safety precautions Always follow the safety precautions given when working with the tractor. The regulations given do not release the operator from statutory and other national regulations as regards traffic safety and occupational health and safety. In addition to the precautions given in this manual, always follow the safety regulations applicable to different types of working sites and existing road traffic laws.

  • Page 16: Maintaining Hardware Safety

    Lock the brake pedals together whenever individual wheel brakes are not required and always when driving on the road. • Extensive repairs to the braking system should be undertaken only by an authorised Valtra workshop. • When implements or ballast weights are front-end mounted, the rear axle loading is decreased: •...

  • Page 17: Using Tractor Safety Features

    1. Safety precautions 1.2.3 Using tractor safety features The tractor has several features that contribute to the operator's safety. • Steering wheel and safety handles WARNING: Hold on to the steering wheel or safety handles in the cab if the tractor tips over. Never try to jump out. •...
  • Page 18 1. Safety precautions • Avoid carbon monoxide poisoning. WARNING: To avoid carbon monoxide poisoning, do not start the engine or run it indoors with the doors closed unless the exhaust is vented to the outside. • Note the function of the auxiliary hydraulics on/off push button. ON/OFF GUID-81F9EA69-748F-4BF4-9F22-D3E06167959A 1.

  • Page 19: Driving On Public Roads

    1. Safety precautions • Front loader WARNING: The programmable features of the joystick or other controls MUST NOT be used to operate a loader. In order to prevent involuntary loader motion, the loader joystick controller must be of a self-neutralising type. When the operator releases his grip on the joystick, the joystick must return to a non-operational neutral position - except for float detent position in the loader lower direction.

  • Page 20: Controlling The Driving Speed

    1. Safety precautions 1.2.4.3 Controlling the driving speed Adjust the driving speed to suit the driving surface, visibility and load. IMPORTANT: Do not alter the maximum driving speed of the tractor. The maximum reverse driving speed is 20 km/h. • Avoid any sudden increase or reduction (braking) in the driving speed.

  • Page 21: Using Ballast Weights

    1. Safety precautions • Use the prescribed safety devices and ensure that they are in good condition. • Follow the directions given by the implement or machine manufacturer. 1.2.4.7 Using ballast weights Use ballast weights according to the instructions when needed. WARNING: When driving on the road, at least 20% of the gross weight of the tractor must be on the front axle.

  • Page 22: Ensuring Personal Safety Of Other People

    1. Safety precautions 1.2.4.9 Ensuring personal safety of other people Avoid hazards for other people when using the tractor. DANGER: Do not allow children in the cab or near the tractor or an attached implement while the engine is running. DANGER: If the tractor engine is running, do not leave anybody in the cab without supervision, as the push buttons are easily operated.

  • Page 23: Instruments And Controls

    2. Instruments and controls Instruments and controls Pedals The tractor pedals are positioned as follows: GUID-B9DB5C5F-FE87-4414-8461-21CBE5754B55 1. Clutch pedal 2. Locking pedal for steering wheel inclination 3. Latch for brake pedals 4. Brake pedals 5. Accelerator pedal - 21 -...

  • Page 24: Dashboard

    2. Instruments and controls Dashboard GUID-5F1247BB-4AFE-4B0B-8FFC-60D3175EC97E 1. Power shuttle lever 2. Powershift preprogramming push button 3. Proline instrument panel 4. Main switch (extra equipment) 5. Hazard warning flasher switch 6. Light switch 7. Proline instrument panel display change-over switch 8. Proline instrument panel display setting switch 9.

  • Page 25: Symbols On The Proline Instrument Panel Display

    2. Instruments and controls GUID-FC2CD6B7-89CF-4206-B450-F2A852212AB7 1. Fuel gauge 2. Coolant thermometer 3. Indicator lights for direction indicator 4. Tachometer 5. Speedometer 6. Indicator light for the main beam 7. Proline instrument panel display The fuel gauge shows the amount of fuel left in the tank. The coolant thermometer indicates the engine temperature.

  • Page 26: Indicator Lights On The Left Side Of The Display

    2. Instruments and controls Symbol Function Rear power take-off (PTO) speed (rpm) Front power take-off (PTO) speed (rpm) Engine speed (rpm) Immediate fuel consumption (ha, acre) Average fuel consumption (ha, acre) Immediate fuel consumption Average fuel consumption Fuel consumption Lower link position (%, 0-100) Lifting link position of front linkage (%, 0-100) Gearbox temperature (C/F) Travel distance (m/km/miles)

  • Page 27: Indicator Lights On The Right Side Of The Display

    2. Instruments and controls Indicator light Indication The exclamation mark is lit together with other indicator lights (yellow) GUID-8D5CD1CF-666F-46C9-9211-2B B777A73D4E Glow indicator light GUID-9DD75249-0CC3-461D-84EC- The light (yellow) is lit when the ignition key is in position and the engine is cold. C9937C947DB9 Parking brake indicator light The light (red) is lit to indicate that the power shuttle lever is in the parking brake position.

  • Page 28: Controls On The Right-Hand Side

    2. Instruments and controls Indicator light Indication Rear linkage indicator light The light is on (yellow) to indicate that the lift/stop/lower switch is in lift position. GUID-39523C54- CBE4-40C9-98E5-3128D0 E9D502 Cruise control indicator light The light is on (yellow) to indicate that cruise control is engaged (constant driving speed/ constant engine speed chosen).

  • Page 29: Driving Controls

    2. Instruments and controls 2.3.2 Driving controls GUID-FAAE4207-5CC0-46C5-ACA4-28BC6A3095D8 1. Change switch for A-pillar display views 2. Activation/recording switch for U-Pilot 3. Switches for cruise control 4. Switch for four-wheel drive (4WD) 5. Switch for differential lock 6. Switch for front suspension (alternative equipment) 7.

  • Page 30: Linkage

    2. Instruments and controls 2.3.3 Linkage Rear linkage GUID-82DDBCD8-450A-40D6-A7B1-C669CD96B983 1. Diagnose light 2. Lowering speed selector 3. Lifting height selector 4. Draft control selector 5. Drive balance control, including slip control system 6. Lift/lower push buttons 7. Lift/lower indicator lights 8.

  • Page 31: Power Take-Off
