- Page 1 User manual BMP42 audac.eu...
- Page 2 This manual is put together with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ www.audac.eu. BMP42 - User manual...
-
Page 3: Table Of Contents
Installing the BMP42 � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �... -
Page 4: Introduction
All media information such as track and artist information can be retrieved from the BMP42 (if supported by the connected device, more info on P15: technical specifications), while playback control is possible from the connected device or remote control. -
Page 5: Precautions
—Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. BMP42 - User manual... - Page 6 The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The BMP42 module is designed to comply with the FCC statement.
-
Page 7: Connections And Connectors
Chapter 1 Connections and connectors CONNECTION STANDARDS The in- and output connections for AUDAC audio equipment are performed according to international wiring standards for professional audio equipment 3-Pin Terminal block: For unbalanced line output connections Left: Signal - (XLR Pin 3) -
Page 8: Overview Bmp42
Chapter 2 Overview BMP42 The BMP42 is a SourceCon™ compatible module featuring an (internal) board-edge connector which carries all signals for getting it connected to any supporting main unit. All external in & output connections shall be made using the available connectors on the panel. -
Page 9: Using The Bmp42
Using the BMP42 Since the BMP42 is a SourceCon™ module, it can be combined with a variation of supporting main units. The operating and configuration interface may differ depending on the device it is installed on, but the functionality offered is the same. Some devices will support control and configuration through a front panel graphical control interface on a display, while others are also supporting web-control. -
Page 10: Player Mode
Toggling between play and pause is done by pressing the play/pause button with (play) or (pause) symbols. Depending on the current mode, the displayed symbol on the icon will toggle. Return: (return) button gets you back to the main module screen of the BMP42. BMP42 - User manual... -
Page 11: Chapter 4 011
Gain: The gain is synchronized from the device connected to the BMP42. If it is not to the desired level, it can be adjusted on the BMP42. The gain can be adjusted within a range of 0 dB and -82 dB, allowing optimization of the output level according to the input sensitivity of the connected amplifier or pre-amplifier. - Page 12 Paired: 8 device ID’s of recently paired transmitters are stored as authorized devices and shown in this list. These authorized devices are allowed for direct pairing with the BMP42 without making it discoverable. (without pressing the button in the main module screen) Devices can be removed from this list by pressing the delete icon.
- Page 13 Chapter 5 Installing the BMP42 CAUTION Before installing the BMP42 to any SourceCon™ compatible device, make sure the power is switched off. Malfunctions or electrical shocks may occur otherwise. Step 1: Make sure that the slot whereto the module should be installed is open and ready for installation. Depending of the main unit, some module slots will be covered by blind panels when delivered.
- Page 14 Fasten the module into the slot using the included screws. Be aware that damage or malfunctions may occur if the module is not correctly fastened. Step 6: Once the module correctly installed, the system can be powered-on and the module functionality will be automatically discovered. BMP42 - User manual...
- Page 15 Compatible devices XMP44 MFA2XX Optional Accessories BAE100 Antenna extender kit NOTE The BMP42 supports media information retrieval (track, artist, album, ... information) from the transmitter. This function is only supported with AVRCP V1.3 (or higher) compatible transmitters. BMP42 - User manual...
