Service Manual
PRODUCT INFORMATION
Safety
• This product meets the requirements regarding
interference suppression on radio and TV.
• After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
• Colour
• Input Power
• Suction Power
• Noise level
• Duststorage capacity
• Action radius
• Cord length
• Filter system
Outlet
• Power control
• Coupling
• Dimensions
of the appliance
• Weight
Published by Philips Consumer Lifestyle
15/02 Version 1.2
: Deep Black
: 750 W
: 210 W
: 79 dB
: 1,7 liter
: 9 m
: 6 m
: EPA 10 filter
: Microfilter
: Electronic on appliance
: Conical
: 33,5 x 54 x 32,5 cm
: 6 kg
Printed in the Netherlands
Vacuum cleaner
ACCESSORIES
• Standard nozzle
: Tri-Active+ nozzle
• Additional nozzle
: Alma HF nozzle
• Tubes
: Aluminium 2-pieces telescopic
tube
• Accessories
: Crevice nozzle, Small nozzle and
Long reach tool
• Accessory storage
: Clip on Tube
• Bend
: Curved Bend with airslide
REPAIR INSTRUCTION
• No specific issues
OPTIONAL (accessories)
• FC8058 : Replacement Filter set
© Copyright reserved
FC9522/09
Subject to modification
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Philips FC9522/09
Summary of Contents for Philips FC9522/09
- Page 1 : Electronic on appliance • Coupling : Conical • Dimensions : 33,5 x 54 x 32,5 cm of the appliance • Weight : 6 kg Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification 15/02 Version 1.2...
- Page 2 DISASSEMBLY- AND RE-ASSEMBLY ADVISE FC9522/09 • To open the appliance, first remove the bucket by • To remove the Turning knob (11) & Potmeter PCBA (18): pushing the dislock-button and lifting the bucket Turn the Upper housing upside down and remove the straight upwards, and remove the Exhaust grille and 2 screws (C).
-
Page 3: Circuit Diagram
CIRCUIT DIAGRAM FC9522/09 4.7V 220µF 22nF ½W 27-¼W 1N4007 220 - 240V 0.47µF 275V 50Hz Motor 10M-¼W 10M-¼W 3-10... -
Page 4: Parts List
PARTS LIST FC9522/09 Service code Description Remark 9965 100 62286 9965 100 62295 Bucket assy 4322 004 93801 HEPA fi lter Buff alo - Mistral 4322 004 93811 Sponge Buff alo - Mistral 9965 100 62285 Exhaust grille assy 4322 004 93821... - Page 5 EXPLODED VIEW FC9522/09 5-10...
- Page 6 EXPLODED VIEW FC9522/09 6-10...
- Page 7 EXPLODED VIEW FC9522/09 7-10...
- Page 8 EXPLODED VIEW FC9522/09 8-10...
- Page 9 EXPLODED VIEW FC9522/09 9-10...
- Page 10 FC9522/09 Version history Version 1.1 : FC9522/09 initial release. Version 1.2 : On page 1 under Accessories Added Alma HF nozzle. In Parts List and Exploded view: Added Pos. 32: 4322 004 26061 Alma HF nozzle Conical 35 mm KC Deep black.
