Philips FC 9012 Service Manual

Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
- Colour
- Maximum air displacement
- Maximum vacuum water column
- Power consumption (IEC) 230 V
- Duststorage capacity
- Type number dustbag
- Cord length (depends on version) : 7 metres
- Filter system
- Dimensions of cleaner
- Dimensions of packaging
- Net weight
- Gross weight
OPTIONAL
- FC 8021 S-bags
- FC 8030 AFS-fi lter
- FC 8031 HEPA Air Filter
- FC 8034 Upgrate kit Active Carbon Filter
- HR 6988 Turbo brush nozzle
- HR 8040 Polishing nozzle

SERVICE INFORMATION

- Open the appliance, fi rst remove the exhaust fi lter grille
(item 20), and then remove the 2 screws - C of the switch
control panel (item 15).
C 2x
C 9x
Published by Philips Domestic Appliances and Personal Care
4322 277 00617
01/04
Universe
: Fresh blue
: 37 l/sec.
: 310 cm
: 1400 W
: 3 L
: FC 8021
: Paper dustbag
: Exhaust AFS air fi lter
: Motor inlet fi lter
: 460 x 315 x 270 mm
: 595 x 395 x 295 mm
: 5.88 kg
: 9.135 kg
14a + b
Printed in the Netherlands

Vacuum cleaner

- To remove the the panel, pos 14a + b must be removed by using
a screwdriver to separate the two covers from the panel as shown
in the picture.
- Undo and remove the 9 screws - C in the upper housing (item 8).
You will require a screwdriver with a 14.5 cm-long shank for this.
Srewdriver 9965 000 08332 can be used.
- The component confi guration shown in the exploded view
may differ in case of specifi c versions. The components are
distinguished by means of code numbers.
- When the repair is fi nished, check whether all functions of the
appliance work properly.
- Item 4, cotton dustbag, is used in countries in which paper
dustbags are not available.
- To disassemble the cord winder, use TORX screwdriver no.T15,
which is one of a set consisting of T20; T15; T10; T9; T8; T7 and T6
(code number 4822 395 50145).
- If the reel half spring unit is replaced, shaft A must be lubricated
with silicone grease. Do not apply any silicone grease to or spill
any grease on terminals (43) or conductors (42).
- Item 40 is provided with a long cord-winder spring, but both long
and short cords can be used in combination with this spring.
(L = 9.3 m)
- Depending on the original cord, the spare cord must be shortened
to the length of the original cord.
- The cord winder spring must be tensioned to the maximum level
and then be rewound approx. 1.5 turn
- Item 13, air valve, opens to cool the motor if the air displacement
is too low or if the airfl ow is blocked.
- If the function of the electronic control unit (item 12) is not
required, the Triac must be short-circuited in the manner shown
in the circuit diagram.
- When the vacuum cleaner is used to suck up fi ne dust the pores
of the dustbag may become clogged, causing the passage of
air through the dustbag to become obstructed. As a result, the
dustbag-full indicator will indicate that the dustbag needs to be
replaced, eventhough the dustbag is not full at all.
© Copyright reserved
FC 9012
Subject to modification
