Relay insert
Relay insert
Order no.: 8512 12 0x
Operating instructions
1.
Safety instructions
Electrical equipment may only be installed and assembled by a qualified electrician in
accordance with the relevant installation standards, guidelines, regulations, directives,
safety and accident prevention regulations of the country.
Failure to comply with these instructions may result in damage to the device, fire or other
hazards.
Hazard due to electric shock. Do not operate device without application module.
Hazard of fire. During operation with inductive transformers, protect each transformer on
the primary side according to manufacturer's data. Use safety transformers that comply
with EN 61558-2-6 (VDE 0570 Part 2-6) only.
These instructions are an integral component of the product and must be retained by the
end user.
2.
Design and layout of the device
(1) Switch insert
(2) Frames
(3) Application module
(4) Screw for dismantling protection (not R.1/R.3)
(5) Button design cover
(6) Connecting terminals
07/2012
(2)
(3)
(4)
(5)
Figure 1: Switch insert
(1)
(6)
1/4
Advertisement
Table of Contents
Related Manuals for Berker 8512 12 0 Series
Summary of Contents for Berker 8512 12 0 Series
- Page 1 Relay insert Relay insert Order no.: 8512 12 0x Operating instructions Safety instructions Electrical equipment may only be installed and assembled by a qualified electrician in accordance with the relevant installation standards, guidelines, regulations, directives, safety and accident prevention regulations of the country. Failure to comply with these instructions may result in damage to the device, fire or other hazards.
- Page 2 Relay insert Function Correct use – Only suitable for use in indoor areas with no drip and no spray water. – Switching of incandescent lamps, HV halogen lamps, fluorescent lamps, compact fluorescent lamps, dimmable energy-saving lamps, 230 V LED lamps and electronic or inductive transformers with low voltage halogen lamps –...
- Page 3 Relay insert 5031 µ to additional extension units Figure 3: Circuiting diagram with extension unit A MCB max. 10 A has been installed as device protection. Circuit switch insert and optional extension units according to the circuiting diagram (Figure 3 or 4). Mount the switch insert into a wall box.
- Page 4 Relay insert Contact minimum load approx. 15 W Standby current consumption < 0.3 W Carry out loading of conventional and electronic transformers according to manufacturer's instructions. The performance data including transformer power dissipation are 20 % for inductive transformers and 10 % for electronic transformers. 6.2 Troubleshooting Device switches on and can no more be switched off.
