Pneumatic seeders
DsF1600 | DsF2200
EN - Original manual
AGRISEM INTERNATIONAL S.A
535 Rue Pierre Levasseur
CS 60263
44158 ANCENIS
FRANCE
Tel.: +33 (0)2.51.14.14.40
Fax: +33 (0)2.40.96.32.36
NOTT-GB-705-A
29/03/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSF1600 and is the answer not in the manual?

Questions and answers

Related Manuals for Agrisem DSF1600

Summary of Contents for Agrisem DSF1600

  • Page 1 Pneumatic seeders DsF1600 | DsF2200 EN - Original manual AGRISEM INTERNATIONAL S.A 535 Rue Pierre Levasseur CS 60263 44158 ANCENIS FRANCE Tel.: +33 (0)2.51.14.14.40 Fax: +33 (0)2.40.96.32.36 NOTT-GB-705-A 29/03/2018...

  • Page 3: Table Of Contents

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Contents FOREWORD ........................5 1. Introduction ........................6 1.1. Purpose of the user manual ........................6 1.2. Using the manual ..........................6 1.3. Ordering the manual ..........................7 1.4. Interpreting the version of the manual ....................7 1.5.
  • Page 4 User manual - Pneumatic seeders - DSF1600 | DSF2200 7.3. Customer configuration ........................73 7.4. Product database ..........................77 7.5. 1 and 2 motor seed rate test ......................84 7.6. Tramlining ............................90 7.7. Manual adjustment of application rate....................97 7.8. Sown area information ........................98 7.9. Bout marker (solenoid valve option) ....................100 7.10.

  • Page 5: Foreword

    User manual - Pneumatic seeders - DSF1600 | DSF2200 FOREWORD We thank you for the confidence you have shown in AGRISEM INTERNATIONAL by purchasing this item of equipment. This manual is provided with your machine to enable you to make optimum use of your equipment, in particular under safe working conditions.

  • Page 6: Introduction

    1. Introduction 1.1. Purpose of the user manual You have just taken ownership of your AGRISEM INTERNATIONAL machine. It has been designed to give complete satisfaction. The equipment has been carefully designed using the latest technological solutions to reduce usage costs.

  • Page 7: Ordering The Manual

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Introduction 1.3. Ordering the manual You can order the user manual by sending a request to: AGRISEM INTERNATIONAL S.A. 535 Rue Pierre Levasseur CS 60263 44158 ANCENIS - France Tel.: 33 (0)2.51.14.14.40 – Fax: 33 (0)2.40.96.32.36 1.4.
  • Page 8 User manual - Pneumatic seeders - DSF1600 | DSF2200 Introduction NOTE This pictogram provides advice. Consequences: more efficient use. BARRED BIN Indicates that waste must not be disposed of in a conventional dustbin but collected through special channels. MOEBIUS LOOP The universal recycling symbol.

  • Page 9: Presentation Of The Machine

    The DSF1600 and DSF 2200 front-mounted hoppers are designed and adapted for hitching onto the front link arm of a tractor for the purpose of:...

  • Page 10: General View Of The Machine

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Presentation of the machine 2.2. General view of the machine NOTT-0001 Fig. 1 Description Hopper Hitching frame Parking stand Signal lights Pipeline Radar NOTT-GB-705-A 29/03/2018...

  • Page 11: Identification

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Identification 3. Identification 3.1. Validity of the user manual This user manual is valid for the following machines. Serial number Machine Type From Pneumatic seeders DSF1600 18S1600105 Pneumatic seeders DSF2200 18S2200101...

  • Page 12: Identification Of The Machine

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Identification The serial number is made up as follows. Description Year of manufacture S = pneumatic seeder Hopper capacity in litres Incremental number 17 S 1600 120 NOTT-0053 Fig. 4 3.3. Identification of the machine...

  • Page 13: Warranty

    The parts alleged to be faulty must be returned to the Company's address for expert inspection: AGRISEM INTERNATIONAL S.A. – 535 Rue Pierre Levasseur – CS 60263 – 44158 ANCENIS - France Tel.: +33 (0)2.51.14.14.40 – Fax: +33 (0)2.40.96.32.36 The following shall be considered to constitute proof of the date of delivery of the equipment: the date of the delivery slip and the purchaser’s invoice.
  • Page 14 If the machine is used with protection and safety devices that are incorrectly fitted or not working. If the machine has been modified without prior written permission from AGRISEM INTERNATIONAL, or if spare parts, accessories or equipment have been fitted to the machine which were not recommended by AGRISEM INTERNATIONAL.
  • Page 15 1 - Returning by the dealer of the warranty certificate duly completed and signed by the dealer and the purchaser. 2 - Claims must be made without fail using an AGRISEM INTERNATIONAL "WARRANTY CLAIM FORM" (see appendix) and sent by registered letter with acknowledgement of receipt by the dealer to the company’s technical department within 10 days of the incident.

  • Page 16: Exclusive Liability Clause

    Moreover, AGRISEM INTERNATIONAL cannot be held liable for injury to the owner or a third party or for the indirect consequences of such an injury, whether or not it results from a fault. You are reminded that a safe distance of 50 metres must be maintained around the machine.

  • Page 17: Safety Instructions

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Safety instructions 5. Safety instructions 5.1. Safety instructions 5.1.1. Introduction The instructions in this user manual must be read and understood before the machine is used for the first time. This user manual is published for wide circulation and the availability of the equipment indicated, whether on the basic machine or as accessories, may vary according to the region in which the machine is used.
  • Page 18 Fitting of spare parts, accessories or equipment on the machine which are not genuine or which have not been recommended by AGRISEM INTERNATIONAL. Spare parts are available via the online spare parts catalogue (accessible via http://parts.agrisem.com/) or through your approved customer service network.
  • Page 19 Ensure good compatibility of the tractor-to-machine hitching device. Only combine equipment that is compatible (machine and tractor). If in doubt, contact the AGRISEM INTERNATIONAL customer service network . Check that the tractor has the characteristics necessary to hitch the machine (see “Characteristics”, page 135.
  • Page 20 User manual - Pneumatic seeders - DSF1600 | DSF2200 Safety instructions Data needed for calculation NOTT-0222 Fig. 5 Unit Description Comment [kg] Empty weight of the tractor see the tractor's user manual or registration papers [kg] Front axle load on empty tractor...
  • Page 21 User manual - Pneumatic seeders - DSF1600 | DSF2200 Safety instructions Unit Description Comment Distance between the centre of the rear see the tractor's user manual or registration axle and the centre of the lower arms' papers or measurement hitch point...
  • Page 22 User manual - Pneumatic seeders - DSF1600 | DSF2200 Safety instructions Calculation of the actual total weight of the combined tractor and machine Enter the value for the calculated actual total weight and the authorised total tractor weight specified in the tractor user manual in the table on page 22.
  • Page 23 User manual - Pneumatic seeders - DSF1600 | DSF2200 Safety instructions NOTE Refer to the tractor's registration documents to obtain the authorised values for the total weight, axle loads and tyre load capacities. The calculated actual values must be less than or equal to (≤) the authorised values.
  • Page 24 DSA: Disc-O-Mulch / Maximulch / Actimulch DS500/200: Disc-O-Mulch / Maximulch / Actimulch AGRISEM INTERNATIONAL accepts no liability in the event of damage resulting from a combination of machines that has not been authorised in writing by AGRISEM INTERNATIONAL. Accidents linked to the failure of components during operation may result from unauthorised combinations of hitching equipment.
  • Page 25 User manual - Pneumatic seeders - DSF1600 | DSF2200 Safety instructions Chock the machine and take all of the necessary measures to avoid the accidental movement of the machine. The machine must only be hitched to the hitching points provided for this purpose and in accordance with the applicable rules.
  • Page 26 AGRISEM INTERNATIONAL rear signalling lights and panels may be removed when working. Check that this signalling equipment has been correctly refitted before driving on the road.
  • Page 27 The machine must be serviced and repaired only by competent persons who are familiar with the machine's features and operating procedures. The machine must only be repaired with original AGRISEM INTERNATIONAL parts. Protect bare metal parts using either thick grease or an anti-rust product that leaves a greasy film.
  • Page 28 When replacing hydraulic hoses, ensure that you only use hoses of the characteristics and quality recommended by the machine's manufacturer. If in doubt, contact the AGRISEM INTERNATIONAL customer service network Each time the machine is used, the hydraulic quick connectors' end fittings must be cleaned and the protective caps must be fitted afterwards.
  • Page 29 (e.g. turbine stopped) and the rear window of the tractor must be shut, the tractor switched off and the ignition keys removed. Ensure that no one is on or near the seeder when the seed is being loaded. The AGRISEM INTERNATIONAL walkway must only be used when the seeder is stationary.

  • Page 30: Safety Symbols On The Machine

    AGRISEM INTERNATIONAL. The user shall acknowledge receipt of the machine and the official documents once handed-over by the dealer. To do this, go to https://my.agrisem.com and follow the instruction given on the web site. 5.1.13. The user's workstation The machine must be operated by one person only, from the tractor driver's seat. Before each use, check the area around the machine, no-one must be within 50 metres of the machine.
  • Page 31 User manual - Pneumatic seeders - DSF1600 | DSF2200 Safety instructions Reference Symbol Meaning WARNING: DANGER ETIQ01-603 Read the instruction manual and safety instructions before starting up the machine and abide by them during operation. WARNING: DANGER ETIQ01-611 Caution: never exceed a maximum air pressure indicated in the manual at the risk of damaging the turbine.
  • Page 32 User manual - Pneumatic seeders - DSF1600 | DSF2200 Safety instructions Reference Symbol Meaning RISK OF INFECTION BY INJECTION IN THE BODY ETIQ01-641 Follow the servicing and maintenance instructions in the user manual. RISK OF CUTS ETIQ01-647 Do not open or remove the protective guards while the engine is running.
  • Page 33 User manual - Pneumatic seeders - DSF1600 | DSF2200 Safety instructions Reference Symbol Meaning RISK OF CRUSHING BETWEEN THE TRACTOR AND THE MACHINE ETIQ01-607 Always remain outside the working area of the three-point linkage when using remote control. RISK OF CRUSHING / CUTS...

  • Page 34: Operation

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 6. Operation 6.1. Location and description of controls 6.1.1. Hitch NOTT-0007 Fig. 11 Description Top link coupling pin Lower link coupling pin Fixed top link pin position Floating top link pin position...
  • Page 35 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 6.1.2. Hopper NOTT-0008 Fig. 12 Description Hopper cover handle Cover lock rubber Lock retention pin NOTT-GB-705-A 29/03/2018...
  • Page 36 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 6.1.3. Distribution unit NOTT-0009 Fig. 13 Description Distribution unit transmission chain tensioner Distribution unit element opening/closing flaps Fluted distribution shaft Feed cup opening lever Shutter flap Electric drive motor Distribution unit manual activation control...
  • Page 37 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 6.1.4. Ventilation NOTT-0010 Fig. 14 Description Turbine speed controller NOTT-GB-705-A 29/03/2018...

  • Page 38: Start-Up

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 6.1.5. Front packer NOTT-0011 Fig. 15 Description Front packer parallelism adjustment rod 6.1.6. A-Manager terminal See separate Müller A-Manager terminal manual 6.1.7. A-Touch terminal See separate Müller A-Touch terminal manual 6.2.
  • Page 39 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 6.2.2. Tractor/machine compatibility NOTE The information listed below is given for information only and is not in any way a substitute for an installation instruction manual, contact the after sales network.
  • Page 40 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation NOTE The authorised values for the total weight, the axle loads and the tyre load capacities can be found in the tractor's registration papers and user manual. 6.2.4. Hopper Check that grills are correctly installed in the bottom of the hopper (1).
  • Page 41 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Description ½” oil supply hose to be connected to a hydraulic control valve on the tractor side ¾” oil return hose to be connected to a pressure-free return on the tractor side NOTT-0013 Fig.
  • Page 42 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Hydraulic free wheel (oil return when turbine is stopped to avoid sudden shut-down) Connection of drain to Flow controller pressure-free return Non-return valve If the 2 hoses are connected in reverse, the...
  • Page 43 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Turbine motor start-up CAUTION Hydraulic motor protection Always ensure that the flow controller is set to mark 3 when starting-up the turbine. 1 - Check that the controller is set to mark 3.
  • Page 44 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation The maximum working speed depends on: The working width of the machine, The desired seed rate per hectare, The maximum deliverable flow rate (varies according to configuration). The formula for determining the maximum working speed without saturating the distribution unit is as follows:...
  • Page 45 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation For sowing one type of seed with a 2 x Ø 70 cm distribution unit: Large capacity Hopper NOTT-0027 Distribution Seed type 1 2 x Ø 70 cm [(1200 / seed drill width) / quantity per ha] X 10 = max speed NOTT-0020 For sowing two seed types and/or fertilisers with a 1 x Ø...
  • Page 46 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation NOTT-0009 Fig. 24 Description Comment Distribution unit transmission chain tensioner Distribution unit opening/closing flaps Fluted distribution shaft Feed cup opening handle Shutter flap Electric drive motor 15 tooth drive pinion Distribution/drive ratio 1.8...
  • Page 47 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation NOTT-0173 Fig. 25 The fluting configuration is as follows: 3 large fluted wheels (coarse seeds) (1), 3 small fluted wheels (fine seeds) (2), Option of 4 large fluted wheels (coarse seeds) by replacing the 3 small fluted wheels with 1 large fluted wheel.
  • Page 48 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Opening flaps The flaps open or close the distribution unit. In sowing mode, the flaps must be open. Position Inside view of the distribution unit View of flaps Flaps closed...
  • Page 49 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Feed cup opening adjustment NOTT-0015 Fig. 32 Description Minimum opening position (closed) Maximum opening position Feed cups NOTT-GB-705-A 29/03/2018...
  • Page 50 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation NOTT-0016 Fig. 33 Depending on the type of seed used, the working width considered, as well as the desired seed density (kg/ha), refer to the metering table below. This defines the flutes to be used, as well as the feed cup opening lever setting position. The finer the seed, the higher the lever needs to be placed (closed position).
  • Page 51 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Description Adjustment screw The metering unit comprises feed cups. The 2 feed cups of the distribution unit are installed on the same shaft. They are controlled by the same device.
  • Page 52 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Screw turning direction Action on the feed cup Comment Tightening the adjustment screw, feed cup opened. NOTT-0183 NOTT-0185 Fig. 37 Fig. 38 Loosening the adjustment screw, feed cup closed. NOTT-0184 NOTT-0186 Fig.
  • Page 53 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Checking feed cup adjustment The correct positioning of the feed cups is checked simply by moving the feed cup opening lever to position (2). The feed cups should lightly press against the flutes as shown in the photograph “Fig.
  • Page 54 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Choosing the fluted wheels in operation NOTT-0190 Fig. 44 Description Engagement/disengagement screw The fluted wheels in operation are to be selected to suit the type of seed use (see “Specification”, page 43).
  • Page 55 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation NOTT-0191 NOTT-0192 Fig. 45 Fig. 46 Fluted wheel engagement/disengagement NOTE The example described below shows the engagement/disengagement of the small flute wheels. Proceed in the same way for large fluted wheels.
  • Page 56 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Illustration Comment Disengage the desired number of fluted wheels unscrewing their coupling screw until it comes into contact with the closing flap (see photograph opposite). NOTT-0197 NOTT-0198 Fig. 51 Fig. 52...
  • Page 57 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Illustration Comment Blocking of fluted wheels NOTT-0202 Fig. 56 Changing fluted wheels The fluting kit for each distribution unit comprises: the shaft, 2 bearings, 8 shim ring washers, 4 small fluted wheels, 2 medium fluted wheels, 2 large fluted wheels.
  • Page 58 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 1 - To change the fluted wheels, first unscrew the screws of the bearings then remove the set of fluted wheels from the distribution unit. Set the fluted wheels down on a flat surface to facilitate the wheel changing operation.
  • Page 59 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 4 - Disengage and remove the 1st small fluted wheel from the distribution shaft. NOTE Do not fully unscrew the coupling screw. NOTT-0207 Fig. 61 5 - Repeat the operation for all the other fluted wheels and shim rings.
  • Page 60 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 8 - Tighten the screw of the 1st medium fluted wheel in the 1st groove of the distribution shaft. NOTT-0210 Fig. 64 9 - Insert the 2nd medium fluted wheel. Make sure it is fitted in the correct direction, the clamping screw should be on the same side as the first.
  • Page 61 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 13 - Insert the shim ring washers after the 1st large fluted wheel. 14 - Insert the 2nd large fluted wheel. 15 - Tighten the screw of the 2nd large fluted wheel in the corresponding groove of the distribution shaft.
  • Page 62 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 20 - Insert the shim ring washers according to the clearance in the distribution unit. 21 - Refit the bearing and screw the 2 screws of the bearing onto the shaft.

  • Page 63: Distribution Head

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 6.3. Distribution head Each distribution head can feed 10, 16 or 24 outlets arranged along the seeding ramp. According to the working width, 4 returns have been incorporated within these heads to enable recycling of unused outlets.
  • Page 64 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation CAUTION In the case of a partitioned hopper, this operation must be carried out for each compartment of the hopper. Implementation 1 - Open the shutter flaps. NOTT-0219 Fig. 73 2 - Place the weighing hopper or box.

  • Page 65: Tables Of Delivery Flow Rate According To Working Width

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 6.5. Tables of delivery flow rate according to working width Débit Maxi (Kg) en fonction de la largeur pour une distribution 2x Ø70 (600Kg/H) 6.5.1. Maximum flow rate (kg) according to width for a 2x Ø70 distribution unit (600 kg/h) with a partitioned hopper These flow rates are given for a specific average seed weight with wiring of all outlets of a 24 outlet distribution head.
  • Page 66 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 6.5.2. Maximum flow rate(kg) according to width for a 2x Ø70 distribution unit (600 kg/h) with a non-partitioned hopper Débit Maxi (Kg) en fonction de la largeur pour une distribution 2x Ø70 (600Kg/H) These flow rates are given for a specific average seed weight with wiring of all outlets of a 24 outlet distribution head.
  • Page 67 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Débit Maxi (Kg) en fonction de la largeur pour une distribution Ø90 (500Kg/H) 6.5.3. Maximum flow rate (kg) according to width for a Ø90 distribution unit (500 kg/h) with a partitioned hopper These flow rates are given for a specific average seed weight with wiring of all outlets of a 24 outlet distribution head.
  • Page 68 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation Débit Maxi (Kg) en fonction de la largeur pour une distribution Ø90 (500Kg/H) 6.5.4. Maximum flow rate (kg) according to width for a Ø90 distribution unit (500 kg/h) with a non-partitioned hopper These flow rates are given for a specific average seed weight with wiring of all outlets of a 24 outlet distribution head.
  • Page 69 User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation 6.5.5. Seeding ramp The front-mounted hopper can incorporate a seeding ramp. This spreads the seeds onto the surface of the soil by means of a number of spreaders mounted on a manually folding metal ramp. The seeding ramp is recommended for cover crop seeding, conventional seeding and fertilisers.

  • Page 70: Front Packer

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Operation NOTT-0028 Fig. 77 6.6. Front packer Check the tyre pressures (see Maintenance – Tyre pressure). Check the parallelism of the front packer axle. Lengths (a) and (b) should be identical. Take the...

  • Page 71: Terminal

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 7. Terminal 7.1. Characteristics of the A-Manager terminal Description Navigation knob Keys Function keys On/Off switch Turn the selection knob: Move the cursor up and down. Change parameter value. Press the selection knob: NOTT-0054 Click on the selected line.

  • Page 72: Characteristics Of The A-Touch Terminal

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 7.2. Characteristics of the A-Touch terminal Description On/Off switch Screen lock or USB screen capture keys Function keys NOTT-0056 Fig. 81 Description Option GSM antenna connection - Only in the...

  • Page 73: Customer Configuration

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 7.3. Customer configuration 7.3.1. Radar calibration 1 - To calibrate the radar, accurately mark out a distance of 100 metres in the field. 2 - Place the machine in the working position.
  • Page 74 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 5 - Press key 9 (a 3rd time). NOTT-0061 Fig. 86 6 - Now press key 2. NOTT-0062 Fig. 87 7 - Select the speed source. • Key 1 tractor •...
  • Page 75 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 8 - Validate the source with key 6. NOTT-0064 Fig. 89 9 - Now press key 2. NOTT-0065 Fig. 90 10 - Now press key 7. NOTT-0066 Fig. 91 NOTT-GB-705-A...
  • Page 76 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 11 - Press key 8. NOTT-0067 Fig. 92 12 - Press key 8 and start driving the 100 metre distance with the tractor. NOTT-0068 Fig. 93 13 - Now press key 6 to confirm.

  • Page 77: Product Database

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 14 - The monitor will return to this page, press key 10. NOTT-0070 Fig. 95 15 - On the home page, check the speed by comparing with the tractor. If the difference in speed is too great, repeat the operation.
  • Page 78 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 2 - Press key 9 a second time. NOTT-0073 Fig. 98 3 - Press key 7. NOTT-0074 Fig. 99 4 - Use the knob to select “Product” and press on the knob to confirm.
  • Page 79 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 5 - Use the knob to select the product assigned number 003 for example. NOTT-0076 Fig. 101 6 - Select “Rename” with the knob. NOTT-0077 Fig. 102 7 - Select the letters with the knob and validate each letter by pressing the knob, then OK when the correct name is entered.
  • Page 80 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 8 - Select “Product type” to define it. NOTT-0078 Fig. 104 9 - Use the knob to select the desired product. NOTT-0079 Fig. 105 10 - Press key 8. NOTT-0080 Fig.
  • Page 81 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 11 - Check that the transmission ratio is 1/1 via the selection knob. NOTT-0081 Fig. 107 12 - Use the knob to change the speed setpoint to 4500 rpm. NOTT-0082 Fig.
  • Page 82 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 14 - Press key 10 once the changes have been made. NOTT-0084 Fig. 110 15 - Use the knob to select hopper 1 or 2. NOTT-0085 Fig. 111 16 - Once the hopper is selected, press the knob.
  • Page 83 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 17 - Use the knob to select the assigned product. NOTT-0087 Fig. 113 18 - Select the desired product by pressing the knob (e.g. WHEAT). NOTT-0088 Fig. 114 19 - The configuration has been successfully entered.

  • Page 84: And 2 Motor Seed Rate Test

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 20 - Press key 10 to open the working page. NOTT-0090 Fig. 116 7.5. 1 and 2 motor seed rate test 1 - Press key 6 on the main screen.
  • Page 85 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 3 - Press the knob to select the metering unit. NOTT-0094 Fig. 119 4 - If there are 2 metering units - Select metering unit 1 or 2 and press the knob.
  • Page 86 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 6 - Enter the quantity by scrolling with the knob then press the knob to validate. NOTT-0097 Fig. 122 7 - Press key 3. NOTT-0098 Fig. 123 8 - Select the working speed by pressing the knob.
  • Page 87 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 9 - Choose the speed with the knob then press the knob to validate. NOTT-0100 Fig. 125 10 - Select the target rate value if it is 0. NOTT-0101 Fig. 126...
  • Page 88 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 12 - Select CALIB. FACT (calibration factor) if it is set to 0. NOTT-0101 Fig. 128 13 - Set CALIB. FACT to 150 g/rev with the knob then press the knob to validate.
  • Page 89 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 15 - The monitor will switch this screen. The calibration button needs to be pressed. NOTT-0103 Fig. 131 16 - Press on the knob and enter the weight obtained. NOTT-0104 Fig.

  • Page 90: Tramlining

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 18 - Then press key 8 to confirm. NOTT-0106 Fig. 134 19 - The calibration factor is changed after each test according to the result obtained. The operation must be repeated as long as the weight obtained is not close to the theoretical weight (error of less than 5 %).
  • Page 91 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 2 - Press key 4 to programme the tramlines. NOTT-0109 Fig. 137 3 - Press the knob. NOTT-0110 Fig. 138 4 - Use the knob to scroll in this screen and press the knob to validate.
  • Page 92 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 2 - Perform the following calculation: Working width of the sprayer divided by working width of the seeder e.g.: 12 : 3 = 4; 15 : 3 = 5; 20 : 3= 6.67 The following results are possible: •...
  • Page 93 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 4 - Press key 10 to return to the main menu. NOTT-0114 Fig. 142 5 - The tramline valves are actuated at the 4th pass. NOTT-0115 Fig. 143 Description 3 m seeder with a 15 m sprayer...
  • Page 94 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 7.6.3. Example 2: sprayer pass straddling 2 seeder passes 1 - Repeat steps 1 to 4 page 90. For this example, we consider a 24 m sprayer and a 3 m seeder (24/3 = 8 passes). In this case, only one valve will be activated.
  • Page 95 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 4 - Press key 10 to return to the main screen. NOTT-0120 Fig. 148 5 - The left-hand valve will be activated a first time on the 4th pass. NOTT-0121 Fig.
  • Page 96 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 7.6.4. Operation Screen key 2 gives access to the tramline parameter settings. NOTT-0123 Fig. 151 Key 7 allows you manually to add a pass. NOTT-0124 Fig. 152 Key 8 allows you manually to remove a pass.

  • Page 97: Manual Adjustment Of Application Rate

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal Key 9 blocks the pass in progress (in the event of several raise/lower operations during the same pass). NOTT-0126 Fig. 154 7.7. Manual adjustment of application rate Screen key 7 gives access to the temporary application rate adjustment settings.

  • Page 98: Sown Area Information

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal Key 2 and/or 3 temporarily reduce(s) the application rate by 10 % with each push. NOTT-0129 Fig. 157 Key 1 restores the application rate top its normal value. NOTT-0130 Fig. 158 7.8.
  • Page 99 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 2 - The seeder is only activated after completing this initial step. NOTT-0132 Fig. 160 3 - Key 1 gives access to an information screen. NOTT-0133 Fig. 161 4 - This screen shows the area sown since the last reset.

  • Page 100: Bout Marker (Solenoid Valve Option)

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 5 - The area has been reset to 0. Press key 5 to see the total surface area. NOTT-0135 Fig. 163 6 - This screen displays the totals according to different criteria and cannot be reset to zero.
  • Page 101 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 2 - Press key 8. NOTT-0138 Fig. 166 3 - Press key 6. NOTT-0139 Fig. 167 4 - Press key 8 to activate the bout markers. NOTT-0140 Fig. 168 NOTT-GB-705-A...

  • Page 102: Light (Standard)

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 5 - The bout marker are activated. Function Left-hand bout marker activated, no left- to-right changeover at headlands Deactivate bout markers Obstacle mode, only the bout marker is controlled by the user...

  • Page 103: Diagnostic Mode

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 3 - Press the desired key. Function Activate working light Activate hopper light Activate beacon NOTT-0144 Fig. 172 7.11. Diagnostic mode 1 - To enter diagnostic mode, press key 9 on the main screen.
  • Page 104 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 3 - Press key 9 (a 3rd time). NOTT-0147 Fig. 175 4 - Press key 6 to enter diagnostic mode. NOTT-0148 Fig. 176 5 - Press key 9 to navigate through the pages.
  • Page 105 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal Page 1 Function Version number Reset to zero Next page Description MA28 Motor 2 MA39 Motor 2 NOTE NOTT-0150 To test the motor, set the LS output value to 50%. The motor should Fig.
  • Page 106 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal Page 7 Function Version number Reset to zero Next page Description MA38 Distribution sensor 2 NOTT-0153 Fig. 181 Page 8 Function Version number Reset to zero Next page Description MA37...
  • Page 107 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal Page 27 Function Version number Reset to zero Next page Description Hopper lower level sensor 1 NOTT-0156 Fig. 184 Page 28 Function Version number Reset to zero Next page Description...
  • Page 108 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal Page 30 Function Version number Reset to zero Next page Description MA41 Hopper upper level sensor 2 NOTT-0159 Fig. 187 Page 31 Function Version number Reset to zero Next page...

  • Page 109: Installation Mode - Junction Box Table

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 7.12. Installation mode - junction box table Junction box 30285100 - Connectors Upper Middle Lower (level 2) (level 1) (ground) 12VE GNDE 12VE GNDE 12VE GNDE 12VE GNDE 12VE GNDE...
  • Page 110 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal English English Number A (1) (White) B (2) (Brown) C (3) (Green) GNDL/earth Left bout marker Right bout marker GNDL/earth Calibration switch/ Position within section unloading switch sensor GNDL/earth Left pre-emergence...
  • Page 111 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal Turbine sensor attachment NOTT-0162 Fig. 190 Motor harness wiring 1 and 2 = + (blue) 3 = 0 VE (brown) 4 = 12 VE (white) 5 and 6 = - (red)
  • Page 112 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal For wiring a single motor, place the red wire on wire no. 1 and the blue wire on wire no. 15. NOTT-0164 Fig. 192 Check that the 10 A fuse is compliant. This fuse serves to protect the motor.
  • Page 113 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal Pairing-up of hopper bottom sensors Description Upper level sensors Lower level sensors NOTT-0166 Fig. 194 7.12.2. Dual motor ISOBUS wire connection table English English Number A (1) (White) B (2) (Brown)
  • Page 114 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal English English Number A (1) (White) B (2) (Brown) C (3) (Green) GNDE 12VE Shaft speed sensor 1 MA36 GNDE 12VE Radar sensor MA37 GNDE 12VE Shaft speed sensor 2...
  • Page 115 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal 2 motor harness wiring 1 and 2 = + (blue) 3 = 0 VE (brown) 4 = 12 VE (white) 5 and 6 = - (red) 7 = Signal (green) NOTT-0163 Fig.

  • Page 116: Error Messages

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal Description Upper level no. 1 sensors Upper level no. 2 sensors Lower level no. 1 sensors Lower level no. 2 sensors NOTT-0169 Fig. 199 7.13. Error messages Message Possible cause...
  • Page 117 User manual - Pneumatic seeders - DSF1600 | DSF2200 Terminal Message Possible cause Remedial solution Hopper tank level too low There is too little seed or fertiliser Fill the hopper. in the hopper. Empty hopper There is no seed or fertiliser in the Fill the hopper.

  • Page 118: Winter Storage - Handling - Transport

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Winter Storage - Handling - Transport 8. Winter Storage - Handling - Transport 8.1. Storage If the machine is not going to be used for an extended period: Perform the machine cleaning maintenance operation Store the machine away from moisture and bad weather.

  • Page 119: Handling

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Winter Storage - Handling - Transport 8.2. Handling CAUTION Never stand in the handling area as this could result in serious or fatal injury. CAUTION The lifting points must be used simultaneously for the safety of handling.

  • Page 120: Transport

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Winter Storage - Handling - Transport 8.3. Transport CAUTION Firmly secure the machine on the flat-bed using straps that are compliant and have been checked in accordance with the applicable regulations.

  • Page 121: Servicing - Maintenance

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Servicing - Maintenance 9. Servicing - Maintenance 9.1. Maintenance tips 9.1.1. Introduction Comply with the safety instructions regarding servicing and maintenance. The machine has been designed and built for maximum yield, profitability and comfort under many different usage conditions. It has been checked at the factory and by the dealer before its delivery to ensure that the machine is received in perfect condition.
  • Page 122 Go around the machine looking for any external damage and checking the condition of the protection devices. The protection devices must be clean, legible and in good condition. If this is not the case, contact the AGRISEM INTERNATIONAL customer service department in order to replace them.
  • Page 123 User manual - Pneumatic seeders - DSF1600 | DSF2200 Servicing - Maintenance 9.1.8. Hydraulic system The machine is powered by pressurised hydraulic energy. Working on a pressurised circuit may give rise to risks of injury by contamination. All operations must be carried out by professionals trained to handle hydraulic technical equipment.
  • Page 124 User manual - Pneumatic seeders - DSF1600 | DSF2200 Servicing - Maintenance NOTE Hydraulic hoses must not be used for more than six years, including a possible storage time of two years maximum. Even under appropriate storage and usage conditions in line with permissible stresses, it is completely normal for hoses and connectors to age, which is why they have a limited storage time and service life.

  • Page 125: Maintenance Consumables

    / Grade NLG12 NOTE Only use the specified consumables. AGRISEM INTERNATIONAL may not be held liable if another type of grease is used. 9.3. Maintenance schedule NOTE The servicing frequency is determined by various factors. Different usage conditions, the weather, driving and working speeds, dust and the type of soil, etc.

  • Page 126: Maintenance Operations

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Servicing - Maintenance Maintenance operations to be carried out 50 hours or every 6 months Lubricate the joints with grease guns. Clean the soil off the machine. Maintenance operations to be carried out every 6 years Replace the hydraulic hoses.
  • Page 127 User manual - Pneumatic seeders - DSF1600 | DSF2200 Servicing - Maintenance • There is no crushing over short lengths. • There are no external mechanical stresses on the hydraulic hoses. • Avoid hoses rubbing against parts of the machine or against each other by arranging and attaching them correctly.
  • Page 128 User manual - Pneumatic seeders - DSF1600 | DSF2200 Servicing - Maintenance Always check that your lighting system is in full working order and clean before driving on the road. WARNING Never set out on the public highway if one of these elements is not in good condition.
  • Page 129 User manual - Pneumatic seeders - DSF1600 | DSF2200 Servicing - Maintenance 9.4.4. Check the tightness of the nuts and screws Refer to the table. ISO 272 ISO898-1 steel bolt quality class 10.9 12.9 d mm ISO mm mm 1.6** 0.35...
  • Page 130 User manual - Pneumatic seeders - DSF1600 | DSF2200 Servicing - Maintenance 9.4.7. Perform a complete diagnosis of the machine Carry out all the operations of the start-up section. Carry out all the maintenance operations to be performed prior to each use.
  • Page 131 User manual - Pneumatic seeders - DSF1600 | DSF2200 Servicing - Maintenance Apply grease to the 2 transmission chains of the distribution units with a brush. NOTT-0005 Fig. 208 Lubricate the distribution unit bearings with a grease pump. NOTT-0029 Fig. 209 CAUTION The machine must be lubricated regularly and after each pressure wash.
  • Page 132 User manual - Pneumatic seeders - DSF1600 | DSF2200 Servicing - Maintenance 9.4.11. Wearing bushings Some joints on AGRISEM INTERNATIONAL tools have wear bushings. These must be changed at the first sign of lateral play. NOTT-0006 Fig. 211 9.4.12. Tyre pressures...

  • Page 133: Failures

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Failures 10. Failures 10.1. Causes and remedies Problem Point to be checked Remedial solution Incorrect volume / Ha Feed cup adjustment and position Check the correct operation of the feed cups as well as the calibration of the feed cup springs.

  • Page 134: Fuses

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Failures 10.2. Fuses The machine is equipped with one or two electric motors that turn the distribution units. In order to “electrically” protect them and according to the configuration, the machine carries one or two protection fuses. These are located inside the electric panel situated at the rear right-hand side of the hopper (see below).

  • Page 135: Characteristics

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Characteristics 11. Characteristics Characteristics of DSF 1600 Hopper volume 1,600 l Type of tank Steel Stainless steel Distribution heads 2 x 70 mm 4 x 10 outlets 2 x 16 outlets...

  • Page 136: Technical Terms And Abbreviations

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Technical terms and abbreviations 12. Technical terms and abbreviations Term Meaning ampere - unit of intensity of electrical current bar - unit of pressure centimetre - unit of length Cubic centimetre - unit of volume...

  • Page 137: Appendices

    User manual - Pneumatic seeders - DSF1600 | DSF2200 Appendices 13. Appendices DECLARATION OF CONFORMITY WITH THE “MACHINERY” DIRECTIVE The manufacturer referred to above certifies that the new equipment described below: PNEUMATIC SEEDERS Complies with the provisions of the amended "Machinery" directive (Directive 2006/42/EC) and with the applicable national legislation.
  • Page 138 User manual - Pneumatic seeders - DSF1600 | DSF2200 Appendices NOTT-GB-705-A 29/03/2018...
  • Page 139 We acknowledge that we have read the whole of the user manual and the warranty terms to which we adhere. AGRISEM INTERNATIONAL SA - 535 rue Pierre Levasseur - CS 60263 - 44158 ANCENIS - FRANCE Tel.: +33 (0)2.51.14.14.40 - Fax: +33 (0)2.40.96.32.36...
  • Page 141 Freight costs payable by the sender Result of assessment AGRISEM INTERNATIONAL Comments Date Signature Technical manager agrisem@agrisem.com AGRISEM INTERNATIONAL SA - 535 rue Pierre Levasseur - CS 60263 - 44158 ANCENIS - FRANCE Tel.: +33 (0)2.51.14.14.40 - Fax: +33 (0)2.40.96.32.36...

This manual is also suitable for:

Dsf2200

Table of Contents
