- Page 1 Hi-Wall Split Air Conditioners ( J Series & D Series - T3 Fixed Speed Cool Only) User’s Manual...
- Page 2 CEO, Blue Star International FZCO. Blue Star International FZCO is a wholly owned subsidiary of Blue Star Limited, India. While due care has been taken to avoid errors or misinterpretation, Blue Star Limited or Blue Star International FZCO is neither liable nor responsible for consequence of any action taken on the basis of this publication.
-
Page 3: Table Of Contents
User’s Manual Table of Contents Letter from the CEO ..................4 Safety Instructions ....................5 Preparation Before Use ........................6 Safety Precautions ..........................7 Identification of Parts Indoor Unit ..............................8 Outdoor Unit ..............................8 Display Introduction..........................9 Maintenance .............................. 11 Protection ..............................12 Troubleshooting ............................13 Installation Instructions Installation Diagram ..........................14 Select the Installation Location ....................15... -
Page 4: Letter From The Ceo
In the unlikely event of your product running into a problem, kindly first check the Troubleshooting Chart contained in this manual. There may be a simple solution to the problem. If this does not help, please contact your nearest Blue Star dealer for expert assistance. You can also reach us on globalexpertservice@bluestarindia.com for any assistance. -
Page 5: Safety Instructions
User’s Manual Safety Instructions To guarantee the unit works normally, please read the manual carefully before installation, and try to install strictly according to this manual. Do not let air enter the refrigeration system or discharge refrigerant when moving the air conditioner. -
Page 6: Preparation Before Use
Hi-Wall Split Air Conditioner Preparation before use Before using the air conditioner, be sure to check and preset as the following. Remote Controller presetting Each time after the remote control is replaced with new batteries or is energized, remote control auto presetting heat pump. If the air conditioner you purchased is a Cooling Only one, heat pump remote controller can also be used. -
Page 7: Safety Precautions
User’s Manual Safety Precautions Symbols in this manual are interpretated as shown below. fire may break out to let the air flow be deflected to entire speeds, this may cause an injury room Keep the power supply circuit breaker or plug away from dirt. Connect the power supply cord to it firmly and correctly. -
Page 8: Identification Of Parts
Hi-Wall Split Air Conditioner Identification of parts Front Panel Air Intake Display Panel Emergency Panel Air Outlet Vertical Adjustment Louver Horizontal Adjustment Louver Air Filter Remote Controller Air Intake Pipes and Power Connection Cord Drain Hose Note: Condensate water drains at COOLING or DRY operation. - Page 9 User’s Manual DA Series...
-
Page 10: Display Introduction
Hi-Wall Split Air Conditioner Display introduction DJ Series Emergency button To let the AC run or stop by pressing the button. ON/OFF The symbols may be different from these models, but the functions are similar. -
Page 11: Maintenance
User’s Manual Maintenance Front panel maintenance Cut off the power supply Grasp position "a" and pull Turn off the appliance first outward to remove the before disconnecting from front panel. power supply. Never use volatile substance Wipe with a soft such as gasoline or polishing and dry cloth. -
Page 12: Protection
Hi-Wall Split Air Conditioner Protection Operating condition The protective device may trip and stop the appliance in the cases listed below: Outdoor air temperature is over 55 COOLING Room temperature is below 21 Room temperature is below 18 The temperature of some products is allowed beyond this range. In specific situation, please consult the merchant. If the air conditioner runs in COOLING or DRY mode with door or window opened for a long time when relative humidity is above 80%, dew may drip down from the outlet. -
Page 13: Troubleshooting
User’s Manual Troubleshooting The following cases may not always be a malfunction, please check it before asking for service. Trouble Analysis If the protector trips or fuse is blown, please wait for 3 minutes and start again, the protector device may be preventing the unit to work. Does not run If batteries in the remote controller are exhausted. -
Page 14: Installation Instructions
Hi-Wall Split Air Conditioner Installation instructions Installation diagram Distance from ceiling should be over 200 mm Distance from wall should be over 50mm Distance from the wall should be over 50mm Distance from floor should be over 2500mm. Air intake distance from the wall should be over 250mm Air intake distance from the wall should be... -
Page 15: Select The Installation Location
User’s Manual Installation instructions Location for Installing Indoor Unit Where there is no obstacle near the air outlet and air can be Indoor unit easily blown to every corner. Where piping and wall hole can be easily arranged. Keep the required space from the unit to the ceiling and wall Pipe length according to the installation diagram on previous page. -
Page 16: Indoor Unit Installation
Hi-Wall Split Air Conditioner Installation instructions Indoor unit installation 1. Installing the Mounting Plate Decide an installing location for the mounting plate according to the indoor unit location and piping direction. Keep the mounting plate horizontally with a horizontal ruler or dropping line. Drill holes of 32mm in depth on the wall for fixing the plate. - Page 17 User’s Manual Installation instructions Piping Joints Thermal Insulation: Wrap the piping joints with thermal insulation materials and then wrap with a vinyl tape. wrapped with vinyl type Thermal insulation Piping Thermal Insulation: Large pipe Thermal insulation Insulation material uses polythene foam over 6mm in thickness. tube Place the drain hose under the piping.
- Page 18 Hi-Wall Split Air Conditioner Installation instructions 4. Connecting of the Cable Front panel Terminal (inside) Indoor Unit Connect the power connecting cord to the indoor unit by connecting the wires to the terminals on the control board individually in accordance with the outdoor unit Cabinet connection.
- Page 19 User’s Manual Installation instructions Wiring Diagram Warning: Before obtaining access to terminals, all supply circuits must be disconnected. Note: All the wires may be different colors. The indicators ‘1L 2L 3L’ may be ‘4 5 6’ or others. And the terminal may be defferent from the material object. CJRRA &...
- Page 20 Hi-Wall Split Air Conditioner Installation instructions Wiring Diagram Warning: Before obtaining access to terminals, all supply circuits must be disconnected. Note: All the wires may be different colors. The indicators ‘1L 2L 3L’ may be ‘4 5 6’ or others. And the terminal may be defferent from the material object.
-
Page 21: Outdoor Unit Installation
User’s Manual Installation instructions Outdoor unit installation 1. Install Drain Port and Drain Hose (for heat-pump model only) Rubber pad (optional) Place under the leg pedestal The condensate drains from the outdoor unit when the unit operates in heating mode. In order not to disturb your neighbor and protect the environment, install a drain port and a drain hose to direct the condensate water. -
Page 22: Air Purging
Hi-Wall Split Air Conditioner Installation instructions Air purging The air which contains moisture remaining in the refrigeration cycle may cause a malfunction on the compressor. After connecting the indoor and outdoor units, release air and moisture from the refrigerant cycle using a vacuum pump, as shown below. Note: To protect the environment, be sure not to discharge the refrigerant to the air directly. -
Page 23: Remote Controller
User’s Manual Remote controller Remote controller The remote controller transmits signals to the system. ON/OFF BUTTON The unit can be On / OFF by pressing this button. MODE BUTTON Press this button to select the operation mode. FAN BUTTON Used to select fan speed in sequence ON/OFF auto, high, medium or low. - Page 24 Hi-Wall Split Air Conditioner Remote controller Remote controller How to Insert the Batteries Remove the battery cover according to the arrow direction. Insert new batteries making sure that the (+) and (-) of battery are matched correctly. Reattach the cover by sliding it back into position. Note: Use 2 LR03 AAA(1.5volt) batteries.
- Page 25 User’s Manual Operation instructions Operation modes Selecting mode Each time MODE button is pressed, the operation mode is changed in sequence: COOLING FAN ONLY HEATING Heating mode is NOT available for cooling only air conditioner. FAN mode ON/OFF Each time the "FAN" button is pressed, the fan speed is changed in sequence: High Medium...
- Page 26 Hi-Wall Split Air Conditioner Operation instructions Airflow direction control Airflow direction control Vertical airflow(Horizontal airflow) is automatically adjusted to a certain angle in accordance with the operation mode after turning on the unit. ON/OFF The direction of airflow can be Operation mode Direction of airflow also adjusted to your own requirement by pressing the...
- Page 27 User’s Manual Operation instructions SMART mode Press the SMART button, the unit enters SMART mode(preset logic operation) directly. In this mode, temperature and fan speed are automatically set based on the actual room temperature. Operation mode and temperature are determined by indoor temperature Heat pump models Indoor temperature Operation mode...
- Page 28 Hi-Wall Split Air Conditioner Operation instructions Timer mode It is convenient to set the timer on with TIMER ON/OFF buttons when you go out in the morning to achieve a comfortable room temperature at the time you get home. You can also set timer off at night to enjoy a good sleep.
- Page 29 User’s Manual Operation instructions SLEEP mode SLEEP mode SLEEP mode can be set in COOLING, HEATING or DRYING operation mode. This OONN function gives you a more comfortable environment for sleep. In SLEEP mode, The appliance will stop operation automatically after operating for 8 hours. ON/OFF Fan speed is automatically set at low speed.
-
Page 30: Models Range
Hi-Wall Split Air Conditioner Models Range... -
Page 31: Customer Care
Customer Care Email : globalexpertservice@bluestarindia.com Website : www.bluestarindia.com Blue Star International FZCO Unit No 3E - 520, Building No 3E (East Side), Dubai Airport Free Zone, Dubai UAE PO Box No : 293719 Trade Licence No : 3331 Blue Star Limited... -
Page 32: Notes
Hi-Wall Split Air Conditioner Notes... -
Page 33: E-Waste Management
E-Waste Management Protect the Environment from E-Waste This product at its end of usable life should not be mixed with household domestic waste or any general waste. It must be stored separately and disposed of through an authorised recycler of electrical and electronic appliance waste.
