- Page 1 Concrete Spraying Machine - SSB 14 line User manual Concrete Spraying Machine SSB 14 STANDARD SSB 14 DUO SSB 14 COM – F , s.r.o. PRODUCER: FILAMOS Hate 546, 261 01 Pribram, Czech Republic Tel: + 420 318 637 763, Fax: + 420 318 624 181...
-
Page 2: Table Of Contents
Concrete Spraying Machine - SSB 14 Content Page Preface ..................3 Use ....................3 III. Machine operating .................3 Description ..................6 Technical parameters ..............9 Standard accessories ..............11 VII. Material ..................11 VIII. Executions................... 11 Markings ..................12 Testing ..................12 Delivery ..................12 XII. -
Page 3: Preface
I. Preface This user manual is necessary to get basic information about safety use of gunite machine SSB 14 (further only machine), made by producer FILAMOS, s.r.o., Hate 546, 261 01 Pribram, Czech Republic. Other information, recommendations and technical parameters are mentioned in the Operating and maintance instructions made by producer. - Page 4 Concrete Spraying Machine - SSB 14 Workmen are obliged to use personal protective equipment stated in Operating and maintenance instructions (crash helmet, ocular protection and respirator against cement dust, convenient work clothes and shoes, work gloves). Workmen are obliged to do daily notes into the operating diary. Safety instruction concerning: Assembly and the installation –...
- Page 5 Concrete Spraying Machine - SSB 14 - Steel material polluted by the dangerous substances - Colour metals, - Plastics, rubber and the parts polluted by the dangerous substances must be disposed off in accordance to the Act about the liquidation of the dangerous substances.
-
Page 6: Description
Concrete Spraying Machine - SSB 14 IV. Description The machine consists of the following main parts: machine drive (electric motor and slide-on gearbox) base frame with bearing part [1] dosing drums I and II [8] machine head with sealing plate [5] and blower [4] loading hopper [6] with vibrator and adapter fitted with a screen and saw to cut the sacks [7] rippling... - Page 7 Concrete Spraying Machine - SSB 14 The electric motor is fitted with a stepped pulley and connected by one V-belt with the slide-on gearbox The bearing part of the dosing drum, the machine drive and the air distribution system are fitted to the rear self-supporting frame. The bantam wheels are screwed to the sides of the base frame.
- Page 8 Concrete Spraying Machine - SSB 14 Working principle The mixture to be sprayed or conveyed is poured into the loading hopper to fill the pockets of the dosing drum. The dosing drum is filled continually. From the pockets of the dosing drum is blown by compressed air to the blower and from there into the transport hoses, at the end of which a spraying gun is mounted.
-
Page 9: Technical Parameters
Concrete Spraying Machine - SSB 14 V. Technical parameters SSB 14 STANDARD: 6 poles electric motor with variable pulley 1,5 kW (11 – 16 rpms/min.) Dosing drum Drum volume /dm Drum rpm Theoretical performance m SSB 14 DUO: 4/6 poles electric motor 1,87/1,35 kW (11/16 rpms/min.) - Page 10 Concrete Spraying Machine - SSB 14 Technical parameters 2 – 5 m Air consumption (transport distance 40 m) x min 0,5 – 0,6 MPa Air pressure Performance of electric motor 1,5; 1,35/1,87 kW 3 NPE ~ 50 Hz, Voltage system 3 x 400/230 V / TN-S ±...
-
Page 11: Standard Accessories
Concrete Spraying Machine - SSB 14 VI. Standard accessories extension hose – 20 m end hose with spraying gun – 20 m water hose – 20 m sealing plates – 3 pcs. nozzle ending – 2 pcs. This is a standard mix of spare parts supplied. Each customer is entitled to change required spare parts and its quantity. -
Page 12: Markings
Concrete Spraying Machine - SSB 14 IX. Markings The machine has a rating plate with the following data: Name and residence of manufacturer, CE mark – declaration of conformity, manufacturer’s number and year of production, rated air pressure, rated water pressure, input, rated voltage, weight of machine. -
Page 13: Warranty
Concrete Spraying Machine - SSB 14 XII. Warranty The warranty period is 12 months from the date of the machine delivery. Otherwise according to conditions in purchase contract. The manufacturer provides no warranty: If the product is used for purposes or in a manner other than specified in the User manual and Operating and Maintenance Instructions, If the product is not being given proper care (poor storage, assembly, incorrect operating),... -
Page 14: Servicing
EN 60204-1, CSN EN 12329, CSN EN ISO 9692-1,CSN ISO 3864. XVIII. Supplements Appendix No. 1: Machine assembly + binding plan + lubricating plan The End Pribram, Czech Republic - April 2004 Made by: Jiri Labuda Producer : FILAMOS, s.r.o., Hate 546, 261 01 Pribram, Czech Republic... - Page 15 Concrete Spraying Machine - SSB 14 Appendix No. 1: Machine assembly + binding plan A: T-A4 grease: every operating hour B: T-A4 grease: 0,1 kg yearly C: PP 90 oil - firstly after 200 operating hours, then after 2500 operating hours – 1,1 l 1.
