- Page 1 Concrete Spraying Machine - SSB 05.2 Series User Manual Concrete Spraying Machine SSB 05.1 DUO SSB 05.2 COM-F , s. r. o. PRODUCER: FILAMOS Hate 546, 261 01 Pribram, Czech Republic Tel: + 420 318 637 763, Fax: + 420 318 624 181...
-
Page 2: Table Of Contents
Concrete Spraying Machine – SSB 05.1 CONTENT PAGE Preface ..................3 Use ....................3 III. Machine Operating ................3 Description ..................6 Technical Data ................8 Accessories ................. 10 VII. Material ..................10 VIII. Executions................... 10 Markings ..................11 Testing ..................11 Delivery ..................12 XII. -
Page 3: Preface
This user manual is necessary to get basic information about safety use of concrete spraying machine SSB 05.2 (further only machine), made by producer FILAMOS, s.r.o., Hate 546, 261 01 Pribram, Czech Republic. Other information, recommendations and technical parameters are mentioned in the Operating and maintenance instructions made by producer. - Page 4 Concrete Spraying Machine – SSB 05.1 against cement dust, convenient work clothes and shoes, work gloves). Workmen are obliged to do daily notes into the operating diary. Safety instruction concerning: Assembly and the installation – Assembly of the machine is carried out at the producer and the transport to the client is performed in already assembled form of the machine.
- Page 5 Concrete Spraying Machine – SSB 05.1 Disposal – Disposal of the machine is comprised of decomposition of the parts to: - Steel material polluted by the dangerous substances - Colour metals - Plastics, rubber and the parts polluted by the dangerous substances must be disposed off in accordance to the Act about the liquidation of the dangerous substances Training Instructions...
-
Page 6: Description
Concrete Spraying Machine – SSB 05.1 IV. Description The Machine comprises the following main parts: the Machine drive (electromotor, gearbox, speed variator, if any) basic frame dosing drum (rotor) with wearing plates the Machine head with upper sealing plate, lower sealing plate and exhauster, feeder and vibrator, rippling equipment, tightening bolts,... - Page 7 Concrete Spraying Machine – SSB 05.1 Machine head (primary (upper) air), to the exhauster (secondary (bottom) air), to clean the Machine and control the pneumatic vibrator. The controlling cocks for the air intake to the head (primary (upper) air) and to the exhauster (secondary (bottom) air) are equipped with manometers.
-
Page 8: Technical Data
The output is changed by means of the invertor V. Technical Data SSB 05.1 DUO : 4/6 poles electric motor 2,6/1,87 kW. Rotor revolutions: 8/12 rpms/min. Performance parameter... - Page 9 The compressed air must be always dry! Principal dimensions SSB 05.2 COM-F Parameter 1540 Length [mm] Width [mm] 1230 Height [mm] Weight (with no accessories) [kg] SSB 05.1 DUO Parameter Length [mm] 1370 Width [mm] 1230 Height [mm] Weight (with no accessories) [kg]...
-
Page 10: Accessories
Concrete Spraying Machine – SSB 05.1 VI. Accessories The machine is delivered with optional accessories set corresponding with required output. Each type of accessories set differs from each other by an inner diameter of transport hose. Marking DN xx (e.g. DN 40 = transport hose with an inner diameter 40 mm). -
Page 11: Markings
Concrete Spraying Machine – SSB 05.1 Metal-coating parts performed accordance with manufacturing documentation and standards CSN EN 12 329. Before assembly, the coreless parts were treated with primer on contact surfaces. Welds were performed in accordance with blue-prints and standards CSN EN ISO 9692-1. -
Page 12: Delivery
Concrete Spraying Machine – SSB 05.1 XI. Delivery Each product is delivered assembled with the following documentation: User manual Operating and maintenance instructions Report of initial control of electric equipment Certificate of quality and completeness – Warranty certificate Spare parts catalogue XII. -
Page 13: Storing
ČSN ISO 2768-1, ČSN EN 60204-1, ČSN EN 12329, ČSN EN ISO 9692-1 and ČSN ISO 3864. XVIII. Supplements Appendix No. 1: Machine Assembly The End Pribram – November 2006 Prepared by: Ing. Jiri Labuda Company: FILAMOS, s.r.o., Hate 546, 261 01 Pribram, Czech Republic... - Page 14 Concrete Spraying Machine – SSB 05.1 Appendix No. 1: Machine Assembly SSB 05.2 (COM-F) Tightening bolts Dosing drum Blower Eyes for lifting-up with the crane Gearbox Lower air regulation Vibrator regulation Upper air regulation Water separator Electromagnetic valve Main Air source Automatic lubrication system Electric energy connection Remote control connection...
